Unmanaged Ethernet Switch(PoE)
产品描述
非网管型以太网交换机（PoE）
端口类型：16 个 100Mbps PoE 端口 (RJ45) + 1 个 1000Mbps 千兆以太网端口 + 1 个 1000Mbps 组合端口
交换容量：7.2 Gbps
转发性能：5.36Mpps
MAC 地址：16K
数据包缓冲区：4 Mbit
前置端口：1 至 8
标准：IEEE802.3、IEEE802.3u、IEEE802.3az、IEEE802.3x、IEEE802.3af、IEEE802.3at
尺寸（宽×深×高）：440 × 189.8 × 44 mm
工作模式：默认（正常模式）：所有端口均可相互通信；扩展（监控模式）：传输距离最远可达 250 米
关键特性
- ● 多种工作模式满足您的业务需求：普通模式、安全模式和监控模式
- ● 支持端口流量控制
- ● 支持安全模式，所有下行端口仅可与上行端口通信
- ● 监控模式下传输距离可达 250 米
- ● 支持缓冲区优化
- ● 全金属外壳，安全可靠
技术规格
| Model | SW-2218-LP |
| Hardware Specification | |
| Ports Type | 16×100Mbps PoE ports (RJ45)+ 1×1000Mbps GigaEthernet ports +1×1000Mbps Combo ports |
| Switching capacity | 7.2 Gbps |
| Power Supply | AC: 100 to 240V, 50/60Hz |
| Forwarding performance | 5.36Mpps |
| MAC | 16K |
| Packet Buffer | 4 M bit |
| PoE Mode | ModeA (1236), ModeB (4578) |
| Max.PoE Power | Max capacity:150W |
| Max capacity for single port: 30W | |
| Prior Ports | 1 to 8 |
| Standards | IEEE802.3, IEEE802.3u, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at |
| Cooling Fans | 0 |
| Max.Power | 165W |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Operating Humidity | 10% to 90% (noncondensing) |
| Indicator | POWER: |
| Steady on: AC input is normal | |
| Off: No AC input | |
| PoE: | |
| Off: No PoE power supply | |
| Steady on: PoE power supply is normal | |
| PoE-MAX： | |
| off ：The POE power supply power of the whole machine is less than 80% of the specification | |
| Steady on : The POE power supply power of the whole machine is greater than 85% of the specification | |
| LINK/ACT： | |
| Off: No link | |
| Steady on: Linked | |
| Flashing: Transmitting data | |
| Dimensions (W×D×H) | 440 × 189.8 × 44 mm |
| Weight | 1.99KG |
| Working Mode | Default (Normal mode) : All ports can communicate with each other, EXTEND (Surveillance mode): Transmission distance up to 250 meters |
| Compliance | |
| NDAA Compliant | Support |
