接入路由器
产品描述
ISG 200系列盒式接入路由器集路由、交换、无线、安全和VPN于一体，采用高性能多核CPU，为用户快速搭建智能、高效、灵活、可靠、易维的IT网络。ISG 200系列盒式接入路由器包括210、230、260、280以及230(G+)、230(SG+)等5G路由器多个系列，可灵活应用于企业分支、中小型企业、SOHO型企业以及移动站点。
关键特性
- 1机多能
- 2种接入
- 3大特性,高校，安全，简捷
技术规格
| ISG 210 | ISG 230 | ISG 260 | ISG 280 | |
| 转发性能 | 2Mpps | 1Mpps | 2Mpps | 280：2Mpps |
| 280(X)：3Mpps | ||||
| 固定接口 | 2*GE电+2*GE光 | 4*GE电 + 1*GE电 + 1*GE光 | 8*GE电 + 2*GE电 + 2*GE光 | 280: 4*GE电 + 4*GE光 |
| LAN/WAN可配置 | LAN/WAN可配置 | LAN/WAN可配置 | 280(X): 2*10GE光+ 2*GE光 + 4*GE电 | |
| 3G/LTE | 不支持 | 可选支持 | 可选支持 | 不支持 |
| Wi-Fi | 不支持 | 可选支持，双频802.11a/b/g/n/ac | 可选支持，双频802.11a/b/g/n/ac | 不支持 |
| 内存 | 2GB | 2GB | 2GB | 2GB |
| Flash | 1GB | 1GB | 1GB | 1GB |
| USB | 1 | 1 | 1 | 无 |
| Console口 | 1 | 1 | 1 | 1 |
| 设备尺寸 H x W x D mm |
44 x 280 x 183 | 44 x 220 x 151 | 44 x 280 x 183 | 44 x 380 x 200 |
| 电源 | AC 输入电压： 100 ~ 240 VAC 频率：50 ~ 60 Hz 额定功率：24W |
电源适配器，输出电压12V，最大负载2A 适配器输入电压：100 ~ 240 VAC 频率：50 ~ 60 Hz 额定功率：24W |
AC 输入电压：100 ~ 240 VAC 频率：50 ~ 60 Hz 额定功率：30W |
AC或DC 支持双电源冗余 AC，输入电压： 100V~ 240 V AC，频率：50 Hz ~60 Hz DC，- 48V 额定功率：30 W |
| 工作环境 | 工作温度：0℃ ~ 45℃ | |||
| 存储温度：-40℃～70℃ | ||||
| 环境相对湿度：5 ~ 95%（无凝结） | ||||
| 基础协议 | 二层：MAC管理，VLAN，QinQ，SuperVLAN，Smartgroup，PPP，PPPOE，802.1x； | |||
| IPv4/IPv6：静态路由，RIP，RIPng，OSPF，OSPFv3，IS-IS，IS-ISv6，BGPv4，BGP4+； | ||||
| 组播：静态组播，IGMPv1/v2/v3，IGMP Snooping，PIM-DM，PIM-SM，PIM-SSM，MSDP，MLDv1/v2，MLD Snooping； | ||||
| DHCP：DHCPv4/v6 Server / Relay / Client，DHCPv4/v6 Snooping； | ||||
| NAT：静态NAT，动态NAT，PAT，NAT多出口，NAT ALG，NAT日志 | ||||
| 3G/LTE | LTE FDD：B1，B3 | |||
| LTE TDD：B38，B39，B40，B41 | ||||
| WCDMA：B1 | ||||
| TD SCDMA：B34，B39 | ||||
| GSM：B3，B8 | ||||
| CDMA EVDO/1X：800M | ||||
| Wi-Fi | IEEE 802.11 b/g/n，2.4Ghz | |||
| IEEE 802.11 ac，5Ghz | ||||
| VPN | GRE，IPSec VPN，DMVPN，GETVPN，L2TP，MPLS L2 VPN，MPLS L3 VPN，6VPE | |||
| MPLS | 静态LSP，LDP，MPLS-TE，RSVP-TE，LDP FRR，TE FRR，MPLS L2 VPN，MPLS L3 VPN，6VPE | |||
| IPv6 过渡 | 6in4，6to4，4in6，6 over 4，6PE，NAT64，6rd，ISATAP | |||
| QoS | H-QOS，基于时间段的QoS，流分类，标记，优先级继承和映射，流量整形，流量限速，PQ，WFQ，CBWFQ，LLQ和基于物理端口的流量调度 | |||
| 安全 | 控制平面安全，IPSec，IKE，RADIUS / TACACS+认证，802.1x认证，ACL，端口镜像，URPF，SSH，国密算法 (SM1，SM2，SM3，SM4) | |||
| 可靠性 | BFD for everything，VRRP，链路捆绑，FRR，SDC智能拨号，链路冗余备份 | |||
| OAM | USB开局，短信开局，网管统一升级版本，温度监控，风扇自动调速，Eth OAM，MPLS OAM，SQA，NetFlow v5/v8/v9，WEB网管，SNMPv1/v2/v3，Telnet，SSHv1/v2，SYSLOG和EEM | |||
| SDN演进 | VXLAN，EVPN，NETCONF等 | |||
| ISG 210 | ISG 230 | ISG 260 | ISG 280 | |
| Forwarding performance | 2Mpps | 1Mpps | 2Mpps | 280：2Mpps |
| 280(X)：3Mpps | ||||
| Fixed interface | 2*GE electric + 2*GE optical | 4*GE power + 1*GE power + 1*GE optical fiber | 8*GE power + 2*GE power + 2*GE optical fiber | 280: 4*GE electric + 4*GE optical |
| LAN/WAN configurable | LAN/WAN configurable | LAN/WAN configurable | 280(X): 2*10GE light + 2*GE light + 4*GE electricity | |
| 3G/LTE | Not supported | Optional support | Optional support | Not supported |
| Wi-Fi | Not supported | Optional support: Dual-band 802.11a/b/g/n/ac | Optional support: Dual-band 802.11a/b/g/n/ac | Not supported |
| Memory | 2GB | 2GB | 2GB | 2GB |
| Flash | 1GB | 1GB | 1GB | 1GB |
| USB | 1 | 1 | 1 | none |
| Console port | 1 | 1 | 1 | 1 |
| Equipment Dimensions: H x W x D mm | 44 x 280 x 183 | 44 x 220 x 151 | 44 x 280 x 183 | 44 x 380 x 200 |
| power supply | AC input voltage： 100 ~ 240 VAC frequency：50 ~ 60 Hz Rated power：24W |
Power adapter, output voltage 12V, maximum load 2AAdapter input voltage：100 ~ 240 VAC frequency：50 ~ 60 Hz Rated power：24W |
AC input voltage：100 ~ 240 VAC frequency：50 ~ 60 HzRated power：30W |
AC or DC Supports dual power supply redundancy AC, Input voltage: 100V~240V AC, Frequency: 50Hz~60Hz DC, -48V Rated power: 30W |
| Work environment | Operating temperature：0℃ ~ 45℃ | |||
| Storage temperature：-40℃～70℃ | ||||
| Ambient relative humidity: 5 ~ 95% (non-condensing) | ||||
| Basic Protocol | Layer 2: MAC management, VLAN, QinQ, SuperVLAN, Smartgroup, PPP, PPPoE, 802.1x; | |||
| IPv4/IPv6: Static routing, RIP, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGPv4, BGP4+; | ||||
| Multicast: Static multicast,IGMPv1/v2/v3，IGMP Snooping，PIM-DM，PIM-SM，PIM-SSM，MSDP，MLDv1/v2，MLD Snooping； | ||||
| DHCP：DHCPv4/v6 Server / Relay / Client，DHCPv4/v6 Snooping； | ||||
| NAT: Static NAT, Dynamic NAT, PAT, NAT with multiple exits, NAT ALG, NAT logs | ||||
| 3G/LTE | LTE FDD：B1，B3 | |||
| LTE TDD：B38，B39，B40，B41 | ||||
| WCDMA：B1 | ||||
| TD SCDMA：B34，B39 | ||||
| GSM：B3，B8 | ||||
| CDMA EVDO/1X：800M | ||||
| Wi-Fi | IEEE 802.11 b/g/n，2.4Ghz | |||
| IEEE 802.11 ac，5Ghz | ||||
| VPN | GRE，IPSec VPN，DMVPN，GETVPN，L2TP，MPLS L2 VPN，MPLS L3 VPN，6VPE | |||
| MPLS | static LSP，LDP，MPLS-TE，RSVP-TE，LDP FRR，TE FRR，MPLS L2 VPN，MPLS L3 VPN，6VPE | |||
| IPv6 transition | 6in4，6to4，4in6，6 over 4，6PE，NAT64，6rd，ISATAP | |||
| QoS | H-QOS, time-based QoS, flow classification, labeling, priority inheritance and mapping, traffic shaping, traffic rate limiting, PQ, WFQ, CBWFQ, LLQ, and physical port-based traffic scheduling. | |||
| Safety | Control plane security, IPSec, IKE, RADIUS/TACACS+ authentication, 802.1x authentication, ACL, port mirroring, URPF, SSH, Chinese cryptographic algorithms (SM1, SM2, SM3, SM4) | |||
| reliability | BFD for everything, VRRP, link bonding, FRR, SDC smart dialing, link redundancy backup | |||
| OAM | USB initialization, SMS initialization, unified network management upgrade version, temperature monitoring, automatic fan speed control, Eth OAM, MPLS OAM, SQA, NetFlow v5/v8/v9, WEB network management, SNMPv1/v2/v3, Telnet, SSHv1/v2, SYSLOG and EEM | |||
| SDN Evolution | VXLAN, EVPN, NETCONF, etc. | |||
| 230(G+) | 230(GW+) | 230(XG+) | 230(XGW+) | |
| 转发性能 | 1Mpps | |||
| 固定接口 | 1xGE光 WAN + 4xGE 电 LAN，LAN/WAN可配置 | 1x10GE光 WAN + 4xGE 电 LAN，LAN/WAN可配置 | ||
| 其他接口 | 1个Console口，1个USB接口、1个RS485接口和1个RS232接口 | |||
| 4G/5G | 支持 | |||
| Wi-Fi | × | √ | × | √ |
| 内存 | 2GB | |||
| Flash | 1GB | |||
| 设备尺寸 H x W x D mm |
44 x 215 x 186 mm | |||
| 电源 | 电源适配器，输出电压12V，最大负载2A | |||
| 适配器输入电压：100 ~ 240 VAC | ||||
| 频率：50 ~ 60 Hz | ||||
| 额定功率：24W | ||||
| 工作环境 | 工作温度：0℃ ~ 45℃ | |||
| 存储温度：-40℃～70℃ | ||||
| 环境相对湿度：5 ~ 95%（无凝结） | ||||
| 3G/4G/5G工作频段 | 5G NR NSA：n38 / n41 / n77 / n78 / n79 | |||
| 5G NR SA：n1 / n2 / n3 / n5 / n7 / n8 / n12 / n20 / n25 / n28 / n38 / n40 / n41 / n48* / n66 / n71 / n77 / n78 / n79 | ||||
| LTE FDD：B1 / B2 / B3 / B4 / B5 / B7 / B8 / B12 / B13 / B14 / B17 / B18 / B19 / B20 / B25 / B26 / B28 / B29 / B30 / B32 / B66 / B71 | ||||
| LTE TDD：B34 / B38 / B39 / B40 / B41 / B42 / B43 / B48 | ||||
| LAA：B46 | ||||
| WCDMA：B1 / B2 / B3 / B4 / B5 / B8 / B19 | ||||
| GNSS：GPS / GLONASS / BeiDou(COMPASS) / Galileo / QZSS | ||||
| Wi-Fi | IEEE 802.11 b/g/n，2.4GHz | |||
| IEEE 802.11 a/n/ac，5.8GHz | ||||
| 基础协议 | 二层：MAC管理，VLAN，QinQ，SuperVLAN，Smartgroup，PPP，PPPOE，802.1x； | |||
| IPv4/IPv6：静态路由，RIP，RIPng，OSPF，OSPFv3，IS-IS，IS-ISv6，BGPv4，BGP4+； | ||||
| 组播：静态组播，IGMPv1/v2/v3，IGMP Snooping，PIM-DM，PIM-SM，PIM-SSM，MSDP，MLDv1/v2，MLD Snooping； | ||||
| DHCP：DHCPv4/v6 Server / Relay / Client，DHCPv4/v6 Snooping； | ||||
| NAT：静态NAT，动态NAT，PAT，NAT多出口，NAT ALG，NAT日志 | ||||
| VPN | GRE，IPSec VPN，DMVPN，GETVPN，L2TP，MPLS VPN，6VPE | |||
| MPLS | 静态LSP，LDP，MPLS-TE，RSVP-TE，LDP FRR，TE FRR，MPLS L2 VPN，MPLS L3 VPN，6VPE | |||
| IPv6 过渡 | 6in4，6to4，4in6，6 over 4，6PE，NAT64，6rd，ISATAP | |||
| QoS | H-QOS，基于时间段的QoS，流分类，标记，优先级继承和映射，流量整形，流量限速，PQ，WFQ，CBWFQ，LLQ和基于物理端口的流量调度 | |||
| 安全 | 控制平面安全，IPSec，IKE，RADIUS / TACACS+认证，802.1x认证，ACL，端口镜像，URPF，SSH，国密算法 | |||
| 可靠性 | BFD for everything，VRRP，链路捆绑，FRR，SDC智能拨号，链路冗余备份 | |||
| OAM | USB开局，短信开局，网管统一升级版本，温度监控，Eth OAM，MPLS OAM，SQA，NetFlow v5/v8/v9，WEB网管，SNMPv1/v2/v3，Telnet，SSHv1/v2，SYSLOG和EEM | |||
| SDN演进 | VXLAN，EVPN，NETCONF、SR、SRv6等 | |||
| 230(G+) | 230(GW+) | 230(XG+) | 230(XGW+) | |
| Forwarding performance | 1Mpps | |||
| Fixed interface | 1xGE optical WAN + 4xGE electrical LAN, LAN/WAN configuration available. | 1x10GE optical WAN + 4xGE electrical LAN, LAN/WAN configuration available. | ||
| Other interfaces | One console port, one USB port, one RS485 port, and one RS232 port. | |||
| 4G/5G | support | |||
| Wi-Fi | × | √ | × | √ |
| Memory | 2GB | |||
| Flash | 1GB | |||
| Equipment dimensions: H x W x D mm | 44 x 215 x 186 mm | |||
| power supply | power supply | |||
| Adapter input voltage: 100 ~ 240 VAC | ||||
| Frequency: 50 ~ 60 Hz | ||||
| Rated power: 24W | ||||
| Work environment | Operating temperature: 0℃ ~ 45℃ | |||
| Storage temperature: -40℃～70℃ | ||||
| Ambient relative humidity: 5 ~ 95% (non-condensing) | ||||
| 3G/4G/5G operating frequency bands | 5G NR NSA：n38 / n41 / n77 / n78 / n79 | |||
| 5G NR SA：n1 / n2 / n3 / n5 / n7 / n8 / n12 / n20 / n25 / n28 / n38 / n40 / n41 / n48* / n66 / n71 / n77 / n78 / n79 | ||||
| LTE FDD：B1 / B2 / B3 / B4 / B5 / B7 / B8 / B12 / B13 / B14 / B17 / B18 / B19 / B20 / B25 / B26 / B28 / B29 / B30 / B32 / B66 / B71 | ||||
| LTE TDD：B34 / B38 / B39 / B40 / B41 / B42 / B43 / B48 | ||||
| LAA：B46 | ||||
| WCDMA：B1 / B2 / B3 / B4 / B5 / B8 / B19 | ||||
| GNSS：GPS / GLONASS / BeiDou(COMPASS) / Galileo / QZSS | ||||
| Wi-Fi | IEEE 802.11 b/g/n，2.4GHz | |||
| IEEE 802.11 a/n/ac，5.8GHz | ||||
| Basic Protocol | Layer 2: MAC management, VLAN, QinQ, SuperVLAN, Smartgroup, PPP, PPPoE, 802.1x; | |||
| IPv4/IPv6: Static routing, RIP, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGPv4, BGP4+; | ||||
| Multicast: Static multicast, IGMPv1/v2/v3, IGMP Snooping, PIM-DM, PIM-SM, PIM-SSM, MSDP, MLDv1/v2, MLD Snooping; | ||||
| DHCP：DHCPv4/v6 Server / Relay / Client，DHCPv4/v6 Snooping； | ||||
| NAT: Static NAT, Dynamic NAT, PAT, NAT with multiple exits, NAT ALG, NAT logs | ||||
| VPN | GRE，IPSec VPN，DMVPN，GETVPN，L2TP，MPLS VPN，6VPE | |||
| MPLS | static LSP，LDP，MPLS-TE，RSVP-TE，LDP FRR，TE FRR，MPLS L2 VPN，MPLS L3 VPN，6VPE | |||
| IPv6 transition | 6in4，6to4，4in6，6 over 4，6PE，NAT64，6rd，ISATAP | |||
| QoS | H-QOS, time-based QoS, flow classification, labeling, priority inheritance and mapping, traffic shaping, traffic rate limiting, PQ, WFQ, CBWFQ, LLQ, and physical port-based traffic scheduling. | |||
| Safety | Control plane security, IPSec, IKE, RADIUS/TACACS+ authentication, 802.1x authentication, ACL, port mirroring, URPF, SSH, Chinese cryptographic algorithms | |||
| reliability | BFD for everything, VRRP, link bonding, FRR, SDC smart dialing, link redundancy backup | |||
| OAM | USB initialization, SMS initialization, unified network management upgrade version, temperature monitoring, Eth OAM, MPLS OAM, SQA, NetFlow v5/v8/v9, WEB network management, SNMPv1/v2/v3, Telnet, SSHv1/v2, SYSLOG and EEM | |||
| SDN Evolution | VXLAN, EVPN, NETCONF, SR, SRv6, etc. | |||
| 230(SG+) | 230(SGW+) | 230(SXG+) | 230(SXGW+) | |
| 转发性能 | 1Mpps | |||
| 固定接口 | 1xGE光 WAN + 4xGE 电 LAN，LAN/WAN可配置 | 1x10GE光 WAN + 4xGE 电 LAN，LAN/WAN可配置 | ||
| 其他接口 | 1个Console口，1个USB接口、1个RS485接口和1个RS232接口 | |||
| 4G/5G | 支持 | |||
| Wi-Fi | × | √ | × | √ |
| 内存 | 2GB | |||
| Flash | 1GB | |||
| 设备尺寸 | 44（高） x 215（宽） x 186（深） mm | |||
| 电源 | 电源适配器，输出电压12V，最大负载2A | |||
| 适配器输入电压：100 ~ 240 VAC | ||||
| 频率：50 ~ 60 Hz | ||||
| 额定功率：24W | ||||
| 工作环境 | 工作温度：0℃ ~ 45℃ | |||
| 存储温度：-40℃～70℃ | ||||
| 环境相对湿度：5 ~ 95%（无凝结） | ||||
| 3G/4G/5G工作频段 | 5G工作频段 | |||
| 5G NR：3GPP Release 15 NSA/SA operation，Sub-6 GHz | ||||
| 5G NR NSA：n41/n78/n79 | ||||
| 5G NR SA：n1/n28/n41/n77/n78/n79 | ||||
| 下行4×4 MIMO：n1/n41/n77/n78/n79 | ||||
| 4G工作频段 | ||||
| LTE Category：下行 Cat 12，上行 Cat 13 | ||||
| LTE FDD：B1/B2/B3/B5/B7/B8/B20/B28 | ||||
| LTE TDD：B34/B38/B39/B40/B41 | ||||
| 下行 2×2 MIMO：B1/B2/B3/B5/B7/B8/B20/B28/B34/B38/B39/B40/B41 | ||||
| 3G工作频段 | ||||
| WCDMA：B1/B2/B5/B8 | ||||
| Wi-Fi | IEEE 802.11 b/g/n，2.4GHz | |||
| IEEE 802.11 a/n/ac，5.8GHz | ||||
| 基础协议 | 二层：MAC管理，VLAN，QinQ，SuperVLAN，Smartgroup，PPP，PPPOE，802.1x； | |||
| IPv4/IPv6：静态路由，RIP，RIPng，OSPF，OSPFv3，IS-IS，IS-ISv6，BGPv4，BGP4+； | ||||
| 组播：静态组播，IGMPv1/v2/v3，IGMP Snooping，PIM-DM，PIM-SM，PIM-SSM，MSDP，MLDv1/v2，MLD Snooping； | ||||
| DHCP：DHCPv4/v6 Server / Relay / Client，DHCPv4/v6 Snooping； | ||||
| NAT：静态NAT，动态NAT，PAT，NAT多出口，NAT ALG，NAT日志 | ||||
| VPN | GRE，IPSec VPN，DMVPN，GETVPN，L2TP，MPLS VPN，6VPE | |||
| MPLS | 静态LSP，LDP，MPLS-TE，RSVP-TE，LDP FRR，TE FRR，MPLS L2 VPN，MPLS L3 VPN，6VPE | |||
| IPv6 过渡 | 6in4，6to4，4in6，6 over 4，6PE，NAT64，6rd，ISATAP | |||
| QoS | H-QOS，基于时间段的QoS，流分类，标记，优先级继承和映射，流量整形，流量限速，PQ，WFQ，CBWFQ，LLQ和基于物理端口的流量调度 | |||
| 安全 | 控制平面安全，IPSec，IKE，RADIUS / TACACS+认证，802.1x认证，ACL，端口镜像，URPF，SSH，国密算法 | |||
| 可靠性 | BFD for everything，VRRP，链路捆绑，FRR，SDC智能拨号，链路冗余备份 | |||
| OAM | USB开局，短信开局，网管统一升级版本，温度监控，Eth OAM，MPLS OAM，SQA，NetFlow v5/v8/v9，WEB网管，SNMPv1/v2/v3，Telnet，SSHv1/v2，SYSLOG和EEM | |||
| SDN演进 | VXLAN，EVPN，NETCONF、SR、SRv6等 | |||
| 230(SG+) | 230(SGW+) | 230(SXG+) | 230(SXGW+) | |
| Forwarding performance | 1Mpps | |||
| Fixed interface | 1xGE optical WAN + 4xGE electrical LAN, LAN/WAN configuration available. | 1x10GE optical WAN + 4xGE electrical LAN, LAN/WAN configuration available. | ||
| Other interfaces | One console port, one USB port, one RS485 port, and one RS232 port. | |||
| 4G/5G | support | |||
| Wi-Fi | × | √ | × | √ |
| Memory | 2GB | |||
| Flash | 1GB | |||
| Equipment size | 44 (H) x 215 (W) x 186 (D) mm | |||
| power supply | Power adapter, output voltage 12V, maximum load 2A | |||
| Adapter input voltage: 100 ~ 240 VAC | ||||
| Frequency: 50 ~ 60 Hz | ||||
| Rated power: 24W | ||||
| Work environment | Operating temperature: 0℃ ~ 45℃ | |||
| Operating temperature: 0℃ ~ 45℃ | ||||
| Ambient relative humidity: 5 ~ 95% (non-condensing) | ||||
| 3G/4G/5G operating frequency bands | 5G operating frequency band | |||
| 5G NR：3GPP Release 15 NSA/SA operation，Sub-6 GHz | ||||
| 5G NR NSA：n41/n78/n79 | ||||
| 5G NR SA：n1/n28/n41/n77/n78/n79 | ||||
| Downlink 4×4 MIMO: n1/n41/n77/n78/n79 | ||||
| 4G operating frequency band | ||||
| LTE Category: Downlink Cat 12, Uplink Cat 13 | ||||
| LTE FDD：B1/B2/B3/B5/B7/B8/B20/B28 | ||||
| LTE TDD：B34/B38/B39/B40/B41 | ||||
| Downlink 2×2 MIMO: B1/B2/B3/B5/B7/B8/B20/B28/B34/B38/B39/B40/B41 | ||||
| 3G operating frequency band | ||||
| WCDMA：B1/B2/B5/B8 | ||||
| Wi-Fi | IEEE 802.11 b/g/n，2.4GHz | |||
| IEEE 802.11 a/n/ac，5.8GHz | ||||
| Basic Protocol | Layer 2: MAC management, VLAN, QinQ, SuperVLAN, Smartgroup, PPP, PPPoE, 802.1x; | |||
| IPv4/IPv6: Static routing, RIP, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGPv4, BGP4+; | ||||
| Multicast: Static multicast, IGMPv1/v2/v3, IGMP Snooping, PIM-DM, PIM-SM, PIM-SSM, MSDP, MLDv1/v2, MLD Snooping; | ||||
| DHCP：DHCPv4/v6 Server / Relay / Client，DHCPv4/v6 Snooping； | ||||
| NAT: Static NAT, Dynamic NAT, PAT, NAT with multiple exits, NAT ALG, NAT logs | ||||
| VPN | GRE，IPSec VPN，DMVPN，GETVPN，L2TP，MPLS VPN，6VPE | |||
| MPLS | static LSP，LDP，MPLS-TE，RSVP-TE，LDP FRR，TE FRR，MPLS L2 VPN，MPLS L3 VPN，6VPE | |||
| IPv6 transition | 6in4，6to4，4in6，6 over 4，6PE，NAT64，6rd，ISATAP | |||
| QoS | H-QOS, time-based QoS, flow classification, labeling, priority inheritance and mapping, traffic shaping, traffic rate limiting, PQ, WFQ, CBWFQ, LLQ, and physical port-based traffic scheduling. | |||
| Safety | Control plane security, IPSec, IKE, RADIUS/TACACS+ authentication, 802.1x authentication, ACL, port mirroring, URPF, SSH, Chinese cryptographic algorithms | |||
| reliability | BFD for everything, VRRP, link bonding, FRR, SDC smart dialing, link redundancy backup | |||
| OAM | USB initialization, SMS initialization, unified network management upgrade version, temperature monitoring, Eth OAM, MPLS OAM, SQA, NetFlow v5/v8/v9, WEB network management, SNMPv1/v2/v3, Telnet, SSHv1/v2, SYSLOG and EEM | |||
| SDN Evolution | VXLAN, EVPN, NETCONF, SR, SRv6, etc. | |||
