Uniview · Box Camera8MP · C/CS Lens Mount

8MP 4K Ultra-HD Box Camera · LightHunter WDR

IPC568EB-DGK-I0

Name: Uniview IPC568EB-DGK-I0
Brand: Uniview

8MP 4K Ultra-HD LightHunter WDR network box camera with C/CS lens mount — lens sold separately, ABF auto back focus, flexible PoE/DC/AC power, triple video streams.

8 MP · 3840×2160@30fpsUltra 265 · low bandwidthWDR · up to 120 dBC/CS · lens sold separatelyABF · auto back focusMulti-Power · PoE / DC12V / AC24V

LENS SOLD SEPARATELY

This is a bare box camera body with a C/CS lens mount — no lens is included in the box. Choose any compatible C-mount or CS-mount lens to match the focal length and field of view your installation needs, then rely on auto back focus (ABF) to fine-tune sharpness once it's attached.

Get Best Price on WhatsApp Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your designated warehouse after payment · Out-of-stock or insufficient stock: 7–15 working days

Sample quantities are welcome — testing one or two units first is the normal way to start.

Certified:CEFCCULRoHSWEEEONVIF

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

8 MP4K Ultra-HD resolution

120 dBOptical WDR

C/CSLens mount (lens not included)

512 GBMicroSD storage

The Uniview IPC568EB-DGK-I0 is an 8 MP (4K Ultra-HD) LightHunter WDR network box camera built around a C/CS lens mount instead of a built-in lens — it ships as a bare camera body, and you choose and purchase a compatible C-mount or CS-mount lens separately to match the focal length and field of view your project needs. Auto back focus (ABF) and support for high-precision motorized lenses make it straightforward to fine-tune sharpness once your chosen lens is attached, while up to 120 dB optical WDR and LightHunter low-light performance keep footage usable in difficult lighting. Power is flexible (PoE, DC 12 V or AC 24 V) and the camera adds triple video streams, smart intrusion detection and people counting — note that the bare body itself carries no weatherproof rating, so outdoor installations need one of the separate outdoor housings listed under Accessories.

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

Bank & ATM lobbiesPair it with a precise telephoto lens for reliable face capture at the counter — a fixed-lens camera can't be tuned this specifically for one spot.

Retail entrances & queuesBuilt-in people counting and crowd density monitoring track footfall and queue buildup without a separate sensor.

Perimeter & tripwire linesSmart intrusion prevention (cross line, intrusion, enter/leave area) filters out false alarms by classifying human, vehicle and non-motor traffic.

Parking & vehicle lanesTraffic monitoring captures a license plate image as a car crosses a tripwire, across up to 4 lanes in high- or low-pole mounting.

Integrator & OEM projectsA bare C/CS-mount body is easy to build into a third-party housing, existing enclosure, or a custom-branded product.

Low-light critical areasLightHunter sensor performance plus up to 120 dB optical WDR keep detail visible in dim rooms and high-contrast doorways alike.

Not the right pick if you need…

Ready to install out of the box — you must buy, attach and focus a compatible C/CS lens before it can capture any image
Outdoor weatherproofing built into the body — the bare camera has no IP rating; outdoor sites need one of the separate outdoor housings
Built-in microphone or speaker — audio in/out are terminal connections for external mic/speaker, nothing is built into the body
Wi-Fi — this is a wired camera (RJ45 + SFP fiber option), no wireless connectivity
A compact, discreet form factor — the box body plus lens plus housing is bulkier than a bullet or dome camera

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

End-User Project PriceEnd user with a real project? Send your requirements / BOQ — best price, plus professional system design & planning advice

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Key Features

Complete list from the official datasheet.

High quality image with 8 MP, 1/1.8" CMOS sensor

3840 × 2160@30 fps in the main stream

Ultra 265, H.265, H.264, MJPEG

Smart intrusion prevention, supports false alarm filtering, including cross line, intrusion, enter area, leave area detection

Automatic selection of best snapshots, supports face detection masked area

People counting, supports people flow counting and crowd density monitoring, suitable for different statistical scenarios

LightHunter technology ensures ultra-high image quality in low illumination environment

Up to 120 dB optical WDR (wide dynamic range)

Supports high-precision motorized lens for accurate zoom and focus

DC 12 V, AC 24 V, PoE (IEEE 802.3af) power supply

Alarm I/O: 2/1, audio I/O: 1/1

Supports optical interface and network interface serial connection, reduce the cost of wiring

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English). This is a lens-less box camera body — no focal length, field of view or DORI figures are listed because those depend entirely on the third-party C/CS lens you attach.

Camera

Sensor	1/1.8" CMOS
Min. Illumination	Color: 0.002 Lux (F1.2, AGC ON), BW: 0.0002 Lux (F1.2, AGC ON)
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 to 1/100000 s
WDR	120 dB
S/N	> 56 dB

Lens

ABF	Support
Lens Mount	C/CS
Iris Type	DC-iris/P-iris

Video

Video Compression	Ultra 265, H.265, H.264, MJPEG
Video Bit Rate	128 Kbps to 16 Mbps
U-code	Support
ROI	Support
Video Stream	Triple streams
Privacy Mask	Up to 4 areas
OSD	Up to 10 OSDs
Frame Rate-Main Stream	8 MP (3840 × 2160), max. 30 fps
Frame Rate-Sub Stream	720P (1280 × 720), max. 30 fps
Frame Rate-Third Stream	D1 (720 × 576), max. 30 fps

Intelligent

Exception Detection	Object removed, Object Left Behind, Scene change
Smart Intrusion Prevention	Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting	Support people flow counting and crowd density monitoring
Traffic Monitoring	Support capturing car license picture when the car passes tripwire, up to 4 lanes can be set, two types of application mode available: High/Low pole


White Balance	Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2
Digital Noise Reduction	2D/3D DNR
Flip	Normal, Flip vertical, Flip horizontal, 180°
HLC	Support
BLC	Support
Defog	Digital defog, Optical defog
Heatwave Reduction	N/A

Events

Basic Detection	Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind, Scene change
General Function	Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication, Alarm input, Alarm output

Audio

Audio Compression	G.711U, G.711A
Audio Bitrate	128 Kbps
Two-way Audio	Support
Suppression	Support
Sampling Rate	16 kHz

Storage

Edge Storage	MicroSD, up to 512 GB
Network Storage	ANR, NAS (NFS)

Network

Protocols	SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible Integration	ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK
User/Host	Up to 32 users. 3 user levels: administrator, common user and operator
Security	TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client	EZStation, UNV-Link, UNV-Link Pro
Web Browser	Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+

Interface

Audio I/O	1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
Alarm I/O	2/1
Serial Port	1 × RS485
Network	1 × RJ45 10 M/100 M/1000 M Base-TX Ethernet + 1 × 100 M/1000 M SFP
Video Output	1 BNC (for debugging)

Certification

EMC	CE-EMC (EN 55032: 2015+A1:2020, EN 61000-3-3: 2013+A1: 2019, EN IEC 61000-3-2: 2019+A1: 2021, EN 55035: 2017+A11:2020); FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Safety	CE LVD (EN 62368-1:2014+A11:2017); UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment	CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

General

Power	DC 12 V (±25%), AC 24 V (±25%), PoE (IEEE 802.3af)
Power Consumption	Max. 8 W
Power Interface	Two-core terminal block
Dimensions	152 mm × 71 mm × 65 mm (6.0" × 2.8" × 2.6") (L × W × H) (excluding the lens)
Weight	0.40 kg (0.88 lb.)
Working Environment	-20 °C to 60 °C (-4 °F to 140 °F), Humidity: ≤ 95% RH (non-condensing)
Storage Environment	-40 °C to 70 °C (-40 °F to 158 °F), Humidity: ≤ 95% RH (non-condensing)
Surge Protection	6 KV
Reset Button	Support
Web Client Language	22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak
Configurable P/N	Support
