Uniview · PTZ CameraLightHunter · 40X PTZ

4MP 40× LightHunter PTZ · Smart IR 250 m

IPC6854ER-X40-VF

Name: IPC6854ER-X40-VF
Brand: Uniview

A 4MP LightHunter network PTZ camera built for wide-area sites: 40× optical zoom reaches out to distant detail, Smart IR carries 250 m into total darkness, and smart intrusion prevention with person/vehicle classification watches the perimeter around the clock.

2688×1520 · main stream @30fps40× / 16× · optical / digital zoomIP66 · outdoor housing ratingPoE++ · or AC/DC 24 V power-40~70°C · wide operating range1024 · presets · 16 patrols

Get Best Price on WhatsApp Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your designated warehouse after payment · Out-of-stock or insufficient stock: 7–15 working days

Sample quantities are welcome — testing one or two units first is the normal way to start.

Compliance:ONVIF Profile SONVIF Profile GONVIF Profile TONVIF Profile M

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

4 MPMain stream (2688×1520)

40×Optical zoom (16× digital)

250 mSmart IR distance

120 dBWDR

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

Port terminals & container yards40× optical zoom (5.7-228 mm) reaches across a wide yard from a single pole — DORI Detect runs out to 3330.6 m on the datasheet, and 360° endless pan sweeps the full berth without a mechanical stop.

Airport perimeter fencing & apronSmart intrusion prevention (cross line, intrusion, enter/leave area) filters false alarms with person / non-motor / motor-vehicle classification along the fence line; heat-haze reduction keeps the image steady over sun-baked apron tarmac.

Border posts & coastline patrolLong DORI reach (Detect 3330.6 m, Identify 333.1 m) covers open ground between checkpoints, and a -40 °C to 70 °C rating plus IP66 sealing means the same unit keeps working from desert heat to arctic cold.

Highway interchanges & toll plazasPan speed up to 180°/s keeps fast-moving vehicles in frame across multiple lanes, while mixed-traffic classification tells cars, motorbikes and pedestrians apart for cleaner alarms at busy interchanges.

Large plazas & transit hubsPeople counting adds flow statistics and crowd-density monitoring for multiple statistical scenarios, and 1024 presets across 16 patrols (up to 128 actions each) automate a fixed sweep across gates, platforms and queues.

Extreme-climate remote sitesPoE++ (802.3bt) or AC/DC 24 V power flexibility simplifies cabling at remote poles, and heater support keeps the unit running across the full -40 °C to 70 °C rated range.

Not the right pick if you need…

Ethernet is 10M/100M Base-TX only, not Gigabit — plan bit rate and cable runs accordingly if streaming multiple high-resolution channels over a long distance.
Housing is rated IP66 with no IK impact rating stated — for street-level sites with high vandalism risk, pair it with a protective enclosure or choose an IK10-rated model instead.
No built-in microphone or speaker (both listed N/A) and no wiper — bring your own audio device for two-way audio, and expect standing water on the lens dome during heavy rain since there's no powered wiper.
9.69 kg on a Ø270 mm × 497 mm body — needs the dedicated pole / wall / ceiling brackets listed below, not a light camera arm.

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

End-User Project PriceEnd user with a real project? Send your requirements / BOQ — best price, plus professional system design & planning advice

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Camera

Sensor	1/1.8" CMOS
Min. Illumination	Color: 0.0005 Lux (F1.2, AGC ON), 0 Lux with IR
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 to 1/100000 s
WDR	120 dB
S/N	> 56 dB

Lens & Field of View

Focal Length	5.7 to 228 mm
Optical Zoom	40×
Digital Zoom	16×
Iris	F1.2 to F4.6
Field of View (H)	59.47° to 2.20°
Field of View (V)	35.62° to 1.24°
Field of View (D)	73.12° to 2.60°

Illuminator

Illumination Distance (IR)	250 m
IR On/Off Control	Auto/Manual
Wavelength	850 nm


White Balance	Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2
Digital Noise Reduction	2D/3D DNR
Flip	Normal, Flip vertical, Flip horizontal, 180°
HLC	Support
BLC	Support
Smart IR	Support
Defog	Digital defog, Optical defog
EIS	Support
Heatwave Reduction	Support
Image Stabilization	EIS (Gyroscope)

Video

Video Compression	Ultra 265, H.265, H.264, MJPEG
Main Stream	4 MP (2688×1520), max. 30 fps
Sub Stream	1080P (1920×1080), max. 30 fps
Third Stream	D1 (720×576), max. 30 fps
Video Bit Rate	128 Kbps to 16 Mbps
U-code	Support
ROI	Support
Video Stream	Triple streams
Privacy Mask	24 areas, up to 4 areas per scene
OSD	Up to 10 OSDs

Audio

Audio Compression	G.711U, G.711A
Audio Bitrate	128 Kbps
Two-way Audio	Support
Suppression	Support
Sampling Rate	16 KHz

Storage

Edge Storage	MicroSD, up to 512 GB
Network Storage	ANR, NAS (NFS)

Network

User/Host	Up to 32 users. 3 user levels: administrator, common user and operator
Protocols	SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible Integration	ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK
Security	TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client	EZStation, UNV-Link, UNV-Link Pro
Web Browser	Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+; Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+

Intelligent

Exception Detection	Object removed, Object Left Behind
Smart Intrusion Prevention	Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting	Support people flow counting and crowd density monitoring

PTZ

Route Patrol	16 patrols, up to 32 actions for each patrol
Recorded Patrol	16 patrols, up to 128 actions for each patrol
Number of Presets	1024
Preset Image Freeze	Support
Preset Patrol	16 patrols, up to 64 presets for each patrol
Patrol Stay Time	15 s to 1800 s
Home Position	Support
Pan Range	360° (endless)
Pan Speed	0.1°/s to 180°/s
Tilt Range	-15° to 90° (auto reverse)
Tilt Speed	0.1°/s to 180°/s

Events

Basic Detection	Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind
General Function	Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output

Interface

Audio I/O	1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
WIFI	N/A
Alarm I/O	7/2
Serial Port	1 × RS485
Built-in Mic	N/A
Built-in Speaker	N/A
Network	1 × RJ45 10 M/100 M Base-TX Ethernet
Video Output	1 BNC (for debugging)

Certification

EMC	CE-EMC (EN 55032:2015+A11:2020; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55035:2017+A11:2020)
Safety	CE LVD (EN 62368-1:2014+A11:2017); UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment	CE-ROHS (2011/65/EU; (EU)2015/863)
Protection	IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)

General

Power Consumption	Max. 61 W
Storage Environment	-40 °C to 70 °C (-40 °F to 158 °F), Humidity: ≤ 95% RH (non-condensing)
Surge Protection	6 KV
Reset Button	Support
Web Client Language	22 languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak

Dimensions	Ø270 mm × 497 mm (Ø10.6" × 19.6") (Ø × H)
Weight	9.69 kg (21.36 lb.)
Power	AC 24 V (±25%) / DC 24 V (±25%) / PoE++ (IEEE 802.3bt) · max. 61 W
Working Environment	-40 °C to 70 °C (-40 °F to 158 °F), ≤95% RH non-condensing
Protection	IP66 · 6 kV surge
Heater	[object Object]

IPC6854ER-X40-VF

Is this the right camera for you?

Worried about counterfeits? Order under your own company name.

Using your own freight forwarder? No problem.

Key Features

40× Zoom Meets Smart Detection

40× optical zoom, 5.7-228 mm lens

Classification-filtered intrusion prevention

How far can it see? (DORI)
