Uniview · PTZ CameraLightHunter · Dual-lens PTZ

2MP+2MP Dual-lens PTZ · Fixed+PTZ Linkage Tracking

IPC9312LFW-AF28-2X4

Name: IPC9312LFW-AF28-2X4
Brand: Uniview

One fixed 2.8 mm channel watches the whole scene while a 4× optical-zoom PTZ channel automatically zooms in and tracks whatever trips the intrusion alarm — both streams from a single IP address.

1920×1080 · main stream @25fps4× · PTZ optical zoomAuto-Link Tracking · triggered by fixed channelDual-mic · + speaker, two-way audioIP66 · weatherproof housingPoE+ · 802.3at or DC 12 V

One unit, two channels

Both channels stream simultaneously from a single IP address — the spec table below shows Panorama and Detail values side by side.

Get Best Price on WhatsApp Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your designated warehouse after payment · Out-of-stock or insufficient stock: 7–15 working days

Sample quantities are welcome — testing one or two units first is the normal way to start.

Compliance:ONVIF Profile SONVIF Profile GONVIF Profile M

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

2MP+2MPDual-lens: fixed panorama + PTZ detail

4×Optical zoom, PTZ detail channel

50 mIR distance (+10 m warm light)

120 dBOptical WDR, both channels

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

Entrances & access pointsThe fixed channel covers the whole gate or lane at 102.4° while the PTZ channel zooms 4× for a closer look at faces and plates — one pole, two jobs.

Perimeter with auto-link trackingSmart intrusion prevention on the fixed channel — cross line, area enter/leave, with person/vehicle classification — automatically triggers the PTZ channel to zoom in and track the target.

Warehouse yards & loading docksOne overall view of the yard plus 256 presets and 16 patrols on the PTZ channel let a single camera watch gates, docks and stacking areas in sequence.

Low light & night operationLightHunter sensors hold color down to 0.002 lux on both channels; when it gets fully dark, 50 m IR and a 10 m warm light on the PTZ channel take over for full-color evidence.

On-site voice deterrenceBuilt-in dual microphones and a high-power speaker support two-way audio, so guards can talk down an intruder the moment the intrusion alarm fires — no separate horn needed.

Flexible wall or ceiling installBoth wall-mount and ceiling-mount forms ship with the unit; IP66 sealing and a -20 °C to 60 °C working range cover most eave, corridor and covered-yard mounting spots.

Not the right pick if you need…

No zoom on the fixed panorama channel — it is locked at 2.8 mm. If you need to zoom into any part of the wide view (not only the linked target), a full multi-sensor panoramic model is a better fit.
Only IP66 sealing and no IK-rated impact resistance is listed — not the choice for high-vandalism sites; pick an IK10-rated model instead.
Pan range is 0° to 345° and tilt -10° to 100° — not a continuously rotating dome. If you need endless 360° pan, choose a different PTZ series.
Detail-channel zoom tops out at 4× (2.8-12 mm) — for long-range (150 m+) identification tasks, a higher-zoom PTZ camera will serve better.

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

End-User Project PriceEnd user with a real project? Send your requirements / BOQ — best price, plus professional system design & planning advice

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Key Features

Complete list from the official datasheet.

Fixed camera and PTZ camera integration, dual-channel with one IP, provides overall view and detailed view at the same time

High quality image with 1080P, 1/2.8" CMOS sensor

1920 × 1080 @25 fps in the main stream

Ultra 265, H.265, H.264, MJPEG

4X optical zoom of PTZ channel allows for closer viewing of subjects

Smart intrusion prevention, supports false alarm filtering, including cross line, intrusion, enter area, leave area detection

PTZ channel can be linked to fixed channel's smart intrusion prevention to track the objects triggering the rule

LightHunter technology ensures ultra-high image quality in low illumination environment

Up to 120 dB optical WDR (wide dynamic range)

Built-in dual-mic and high-power speaker, supports two-way audio, has better sound performance

Supports ceiling mount and wall mount

IR and warm light illumination to deal with different scenes and achieve full-color illumination

DC 12 V, PoE+ (IEEE 802.3at) power supply

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Highlighted rows are channel-specific:PANORAMA = Channel 1 · fixed 2.8 mmDETAIL = Channel 2 · 4× PTZ zoom

Camera

Sensor	1/2.8" CMOS
Min. Illumination	PANORAMA · Color: 0.002 Lux (F1.6, AGC ON), 0 lux with IRDETAIL · Color: 0.002 Lux (F1.6, AGC ON), 0 Lux with IR/Warm light
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 to 1/100000 s
WDR	120 dB
S/N	> 52 dB

Lens & Field of View

Focal Length	PANORAMA · 2.8 mmDETAIL · 2.8 to 12 mm
Optical Zoom	PANORAMA · N/ADETAIL · 4X
Iris	F1.6
Field of View (H)	PANORAMA · 102.4°DETAIL · 106.6° to 30.6°
Field of View (V)	PANORAMA · 54.9°DETAIL · 56.5° to 17.4°
Field of View (D)	PANORAMA · 133.1°DETAIL · 138.6° to 37.6°

Illuminator

Light On/Off Control	Auto/Manual
Wavelength	850 nm
Illumination Distance (IR)	PANORAMA · 10 m (32.8 ft.)DETAIL · 50 m (164.0 ft.)
Illumination Distance (Warm Light)	PANORAMA · N/ADETAIL · 10 m (32.8 ft.)

Video

Privacy Mask	24 areas, up to 4 areas per scene
Frame Rate-Main Stream	1080P (1920×1080)@25 fps (default) · 1080P (1920×1080), max. 25 fps · 720P (1280×720), max. 25 fps
Frame Rate-Sub Stream	720P (1280×720), max. 25 fps · D1 (720×576), max. 25 fps · 640×360, max. 25 fps · 2CIF (704×288), max. 25 fps · CIF (325×288), max. 25 fps
Video Compression	Ultra 265, H.265, H.264, MJPEG
Video Bit Rate	128 Kbps to 16 Mbps
U-code	Support (main stream)
ROI	Support
Video Stream	Dual streams
OSD	Up to 4 OSDs

Intelligent

Linkage Function	Support. Triggered by fixed lens via smart intrusion prevention function to track target
Smart Intrusion Prevention	PANORAMA · Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)DETAIL · N/A


White Balance	Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2
Digital Noise Reduction	2D/3D DNR
Flip	Normal, Flip vertical, Flip horizontal, 180°
HLC	Support
BLC	Support
Smart IR	Support
Defog	Digital defog

Events

Basic Detection	Motion detection, Audio detection
General Function	Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication

Audio

Audio Compression	G.711U, G.711A
Audio Bitrate	128 Kbps
Two-way Audio	Support
Suppression	Support
Sampling Rate	16 KHz

Storage

Edge Storage	MicroSD, up to 512 GB
Network Storage	ANR, NAS (NFS)

Network & Security

Protocols	SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible Integration	ONVIF (Profile S, Profile G, Profile M), API, SDK
User/Host	Up to 32 users. 3 user levels: administrator, common user and operator
Security	TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client	EZStation, UNV-Link, UNV-Link Pro
Web Browser	Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+

PTZ

Number of Presets	PANORAMA · N/ADETAIL · 256
Preset Patrol	PANORAMA · N/ADETAIL · 16 patrols, up to 64 presets for each patrol
Patrol Stay Time	1000 s to 1800 s
Home Position	PANORAMA · N/ADETAIL · Support
Pan Range	PANORAMA · N/ADETAIL · 0° to 345°
Tilt Range	PANORAMA · 18°±5°DETAIL · -10° to 100°
Pan Speed	PANORAMA · N/ADETAIL · 1°/s to 40°/s
Tilt Speed	PANORAMA · N/ADETAIL · 2°/s to 50°/s

Interface

Built-in Mic	Built-in dual-mic
Built-in Speaker	Support
Network	1 × RJ45 10 M/100 M Base-TX Ethernet

Certification

EMC	CE-EMC (EN55032:2015; EN55024:2010+A1:2015; EN61000-3-2:2014; EN61000-3-3:2013) · FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Safety	CE LVD (EN 62368-1:2014+A11:2017; EN 62368-1:2014) · UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment	CE-RoHS (2011/65/EU)
Protection	IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)

General

Power Consumption	Max. 16 W
Power Interface	Ø5.5 mm coaxial power plug
Storage Environment	-30 °C to 70 °C (-22 °F to 158 °F), Humidity: ≤95% RH (non-condensing)
Surge Protection	2 KV
Reset Button	Support
Web Client Language	22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak

Dimensions	Wall Mount: 192 mm × 134 mm × 302 mm (7.6" × 5.3" × 11.9") Ceiling Mount: 154 mm × 134 mm × 363 mm (6.1" × 5.3" × 14.3")
Weight	1.03 kg (2.27 lb.)
Power	DC 12 V, PoE+ (IEEE 802.3at)
Working Environment	-20 °C to 60 °C (-4 °F to 140 °F), ≤95% RH non-condensing
Protection	IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)
