UniviewS3-P Series · 1× SATA HDD · Built-in PoE

1-HDD PoE Network Video Recorder · S3-P Series

NVR301-04S3-P4 / 08S3-P8

Name: Uniview NVR301-04S3-P4 / 08S3-P8
Brand: Uniview

4 / 8-channel network video recorder with built-in PoE ports — Ultra 265 compression, 4K HDMI output, records cameras up to 8MP, no separate PoE switch needed.

8MP · max recordingUltra 265 · low storage4K HDMI · + VGA simultaneousBuilt-in PoE · 4 / 8 ports by model1× SATA · up to 10 TB21 languages · local interface

CHOOSE YOUR SIZE — TWO MODELS ON THIS PAGE

Rule of thumb: count your PoE cameras, then leave room to grow — a shop with 3 cameras runs happily on the 04S3-P4; pick the 08S3-P8 if you may add cameras later or need more total PoE power budget (54 W vs 75 W). Highlighted rows in the spec table below show every difference between the two.

Get Best Price on WhatsApp Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your designated warehouse after payment · Out-of-stock or insufficient stock: 7–15 working days

Sample quantities are welcome — testing one or two units first is the normal way to start.

Certified:CEFCCULRoHSWEEE

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

4/8Channel options

64 MbpsIncoming bandwidth

10 TBMax HDD capacity

4KHDMI output

Is this the right recorder for you?

Plain-language guide for buyers and installers — based only on what this recorder actually does.

Small shops & homesThe 4-ch 04S3-P4 plus four PoE cameras is a complete kit — no separate PoE switch, no extra power bricks at each camera, one disk, done.

Growing businessesBuy channels you don't use yet: the 08S3-P8 lets you add PoE cameras later without replacing the recorder or buying a bigger switch.

One-cable installsEach PoE port carries power and video over a single Ethernet cable — no electrical outlet needed at the camera position.

Remote viewing on phoneP2P protocol built in — the owner checks the shop from a phone app without a fixed IP or network skills.

Local-language interface21 GUI languages including Spanish (Latin America), Portuguese (Brazil) and French — your customer operates it in their own language.

Longer video retentionUltra 265 roughly halves file size versus H.264 — the same 10 TB disk keeps weeks more footage.

Not the right pick if you need…

A second hard disk or RAID — this series has a single SATA bay
Gigabit uplink — the network port is 10/100M
Alarm in/out wiring for sirens or sensors — this series has no physical alarm terminals
Audio input — it has an RCA audio output only (camera-side mics still record)
High-power PoE devices beyond budget — each port is capped at 30 W, and total PoE budget is 54 W (04S3-P4) or 75 W (08S3-P8)

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

End-User Project PriceEnd user with a real project? Send your requirements / BOQ — best price, plus professional system design & planning advice

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Saves your disk. Catches what matters.

Two real capabilities from the datasheet that matter every day: storage efficiency and smart detection.

ULTRA 265

Half the storage, same image

Ultra 265 compression cuts recording size dramatically versus H.264 — on the same 10 TB disk you keep footage for weeks longer, or record more cameras at higher resolution.

SMART DETECTION

Catches intrusions, not just motion

Built-in Face Detection plus SIP smart rules (Intrusion Detection, Cross Line Detection, Enter/Leave Area) and Ultra Motion Detection on up to 4 channels — backed by Face Snapshot Search and Behavior Search to jump straight to the right clip.

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Highlighted rows differ between the three models:NVR301-04S3-P4 · 4-chNVR301-08S3-P8 · 8-ch

Decoding

Decoding Format	Ultra 265, H.265, H.264
Decoding Capability	04S3-P4 · 1×4K@30, 4×5MP@25, 4×4MP@25, 4×3MP@2508S3-P8 · 1×4K@30, 4×5MP@25, 4×4MP@25, 4×3MP@25, 6×1080P@30, 8×720P@30
Decoding Capability Description	The resolution of each channel cannot exceed 4000 pixels in length and 3000 pixels in width
Audio Compression	G.711A, G.711U

Network

Incoming Bandwidth	64 Mbps
Outgoing Bandwidth	48 Mbps
Remote Users	128
Protocols	TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP, RTSP, IPv4
Browser (Plugin)	IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+

Video/Audio Input

IP Video Input

04S3-P4 · 4-ch08S3-P8 · 8-ch

Video/Audio Output

HDMI Output	4K (3840×2160)/30 Hz, 1920×1080/60 Hz, 1920×1080/50 Hz, 1600×1200/60 Hz, 1280×1024/60 Hz, 1280×720/60 Hz, 1024×768/60 Hz
VGA Output	1920×1080/60 Hz, 1920×1080/50 Hz, 1600×1200/60 Hz, 1280×1024/60 Hz, 1280×720/60 Hz, 1024×768/60 Hz
RCA Audio Output	1-ch
Liveview Display	04S3-P4 · 1/408S3-P8 · 1/4/6/8/9
Corridor Mode Screen	04S3-P4 · 3/408S3-P8 · 3/4/5/7/9
Snapshot	FTP/Schedule/Event Snapshot; 1-ch snapshot (max. D1 (720×576) video resolution, with D1 snapshot resolution)

Recording

Recording Resolution	8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080P / 960P / 720P / D1 / 2CIF / CIF
Synchronous Playback in Local	04S3-P4 · 4-ch08S3-P8 · 8-ch

Smart

VCA Detection by IPC	Face Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Ultra Motion Detection (UMD)
Smart by IPC	Total 4-ch (Face Detection, SIP, UMD)
VCA Search	Face Snapshot Search, Behavior Search

Alarm

General Alarm	Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection
Alert Alarm	IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal

GUI Language

21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian

Hard Disk

SATA	1 SATA Interface
Capacity	Up to 10 TB for each HDD (the maximum HDD capacity varies with environment temperature and hard disk size)

External Interface

Network Interface	1 RJ45 10 M/100 M self-adaptive Ethernet Interface
USB	Rear panel: 2 × USB 2.0
RS485	N/A
RS232	N/A
Alarm In	N/A
Alarm Out	N/A
Power Supply	04S3-P4 · DC 48 V / 1.35 A08S3-P8 · DC 52 V / 1.8 A

PoE

PoE Interface	04S3-P4 · 4 × RJ45 10 M/100 M self-adaptive Ethernet Interface08S3-P8 · 8 × RJ45 10 M/100 M self-adaptive Ethernet Interface
Max Power	04S3-P4 · Max 30 W for single port, Max 54 W in total08S3-P8 · Max 30 W for single port, Max 75 W in total
Supported Standard	IEEE 802.3at, IEEE 802.3af

Working Environment

Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity	≤ 90% RH (non-condensing)
Power Consumption (without HDD)	≤ 9 W

Dimensions

Weight (without HDD)	≤ 1.1 kg (2.43 lb)
Dimensions	260 mm × 240 mm × 46 mm (10.2" × 9.4" × 1.8")

Certification

Certification	CE; FCC; UL; RoHS; WEEE
CE	EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035
FCC	Part15 Subpart B
