PTZ Cameras › IPC6312LFW-AX5C-VG1
IPC6312LFW-AX5C-VG1
view 1
view 2
view 3
Uniview · PTZ CameraLightHunter · Active Deterrence
2MP LightHunter Mini PTZ · 5× Auto-Tracking

IPC6312LFW-AX5C-VG1

A compact 2MP PTZ dome that finds trouble and gets close: 5× optical zoom locks onto people with auto tracking, LightHunter imaging holds true color into near-darkness, and smart intrusion prevention filters out false alarms — in a PoE-powered housing rated -30 to 60 °C.

1920×1080 · main stream @30fpsF1.6 · 5× zoom, 2.7–13.5 mmAuto Tracking · human target filteringSmart IR · 50 m + 15 m warm lightIP66 · outdoor-rated housingPoE · IEEE 802.3at / DC 12 V
Get Best Price on WhatsApp Need the PDF datasheet? Get it on WhatsApp →
In-stock models: 3 days to your designated warehouse after payment · Out-of-stock or insufficient stock: 7–15 working days

Sample quantities are welcome — testing one or two units first is the normal way to start.

Compliance:ONVIF Profile SONVIF Profile GONVIF Profile T
Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.
2 MPMax resolution, 1/2.8" CMOS
5×Optical zoom, 2.7–13.5 mm
50 mIR distance (+15 m warm light)
120 dBWDR, wide dynamic range

The IPC6312LFW-AX5C-VG1 is a 2MP LightHunter mini PTZ dome camera built around a 1/2.8" CMOS sensor with a 2.7 to 13.5 mm, 5× optical-zoom lens (F1.6), delivering up to 120 dB WDR and color imaging down to 0.002 lux (AGC on). Smart intrusion prevention covers cross line, intrusion, enter-area and leave-area detection with false-alarm filtering and human/vehicle classification, while auto tracking automatically follows human targets and a built-in mic and speaker support two-way audio. Smart IR reaches 50 m plus a 15 m warm light, MicroSD storage takes cards up to 512 GB, and the IP66-rated housing runs on DC 12 V or PoE (IEEE 802.3at).

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

Small perimeters & yardsCross-line and intrusion detection cover the fence line, with false-alarm filtering and human/vehicle classification so a blowing bag or passing cat won't trigger the alert.
Entrances & loading baysAuto tracking locks onto a person the moment they enter frame and follows them, then the 5× zoom lens lets an operator pull in close on a face or bag without losing the wide view first.
Dim lots & covered walkwaysLightHunter imaging keeps color down to 0.002 lux with AGC on, and 120 dB WDR handles the bright-exit / dark-interior contrast typical of covered parking and stairwells.
Unlit yards after darkWhen it's fully dark, smart IR reaches 50 m for monochrome coverage, or switch to the 15 m warm light for full-color capture of faces and plates at closer range.
Sites needing an audible warningA built-in mic and speaker support two-way audio, so a remote operator can talk down an intruder directly from the monitoring station once the intrusion alert fires.
Standard outdoor poles & wallsIP66 sealing and DC 12 V / PoE (802.3at) power keep installation simple — one Ethernet cable for data and power, plus MicroSD edge storage up to 512 GB if the network drops.
Not the right pick if you need…
  • No wide panoramic view — this is a single-lens 5× zoom mini PTZ covering one area at a time, not a 360° or multi-sensor camera. Pair it with a fixed or panoramic camera if you need full-scene overview plus detail together.
  • The datasheet lists auto tracking with human-target filtering, not face recognition or a face database — it follows a person, it doesn't identify who they are. Choose a dedicated face-recognition camera if identity matching is the goal.
  • IP66 protection (not IP67/submersible) — fine for eaves, walls and typical outdoor poles, but not rated for direct water immersion or burial-level exposure.

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order
Note: manufacturer order registration (left) is available via the corporate purchase channel.
How to get a better price
Volume Discount50+ units of a single model
CONTACT US
Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit
BETTER
End-User Project PriceEnd user with a real project? Send your requirements / BOQ — best price, plus professional system design & planning advice
BEST
All discounts are quoted personally — message me on WhatsApp ↑

Key Features

Complete list from the official datasheet.

High quality image with 1080P, 1/2.8" CMOS sensor
Ultra 265, H.265, H.264, MJPEG
Smart intrusion prevention, supports false alarm filtering, including cross line, intrusion, enter area, leave area detection
LightHunter technology ensures ultra-high image quality in low illumination environment
Up to 120 dB WDR (wide dynamic range)
Built-in mic and speaker
Smart IR, up to 50 m (164.0 ft.) IR distance and 15 m (49.2 ft.) warm light distance
MicroSD, up to 512 GB
IP66 protection
DC 12 V, PoE (IEEE 802.3at) power supply

Two Capabilities Working Together

Auto tracking finds the target; the lens and low-light imaging bring it into clear view.

AUTO TRACKING + 5× ZOOM

5× zoom auto-tracking locks onto people in real time

A 2.7–13.5 mm, 5× optical-zoom lens (F1.6) pairs with auto tracking that filters for human targets only, so the PTZ head follows people without chasing vehicles or moving branches.

LIGHTHUNTER LOW-LIGHT

LightHunter imaging holds color into near-darkness

0.002 lux color sensitivity (F1.6, AGC on) plus 120 dB WDR keeps footage usable in dim lots and backlit doorways; once it's fully dark, 50 m IR and 15 m warm light take over.

How far can it see? (DORI)

DORI (EN 62676-4) is the industry standard for what a camera can do at distance. Values shown are at full 5× telephoto.

Detectsomething is there
158.3 m519.3 ft
Observewhat is happening
63.3 m207.7 ft
Recognizesomeone you know
31.7 m103.9 ft
Identifybeyond doubt
15.8 m51.8 ft

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Camera

Max Resolution2 MP
Sensor1/2.8" CMOS
Min. IlluminationColor: 0.002 Lux (F1.6, AGC ON), 0 Lux with IR on
Day/NightIR-cut filter with auto switch (ICR)
ShutterAuto/Manual, 1 to 1/100000 s
WDR120 dB
S/N> 52 dB

Lens

Focal Length2.7 to 13.5 mm
Optical Zoom5X
IrisF1.6
Field of View (H)106.6° to 31.5°
Field of View (V)56.5° to 16.9°
Field of View (D)138.6° to 38.7°

Video

Privacy MaskUp to 4 areas
Video CompressionUltra 265, H.265, H.264, MJPEG
Frame RateMain Stream: 1080P (1920 × 1080) max. 30 fps; Sub Stream: 720P (1280 × 720), max. 30 fps
Video Bit Rate128 Kbps to 16 Mbps
U-codeSupport
ROISupport
Video StreamDual streams
OSDUp to 4 OSDs

Intelligent

Auto TrackingSupport, target filtering: human only
Smart Intrusion PreventionCross line detection, intrusion detection (support false alarm filtering and the classification of human and vehicle)


White BalanceAuto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2
Digital Noise Reduction2D/3D DNR
FlipNormal, Flip vertical, Flip horizontal, 180°
HLCSupport
BLCSupport
Smart IRSupport
DefogDigital defog

Illuminator

Light On/Off ControlAuto/Manual
Wavelength850 nm
Illumination Distance (IR)50 m (164.0 ft.)
Illumination Distance (Warm Light)15 m (49.2 ft.)

Events

Basic DetectionMotion detection, Tampering alarm, Audio detection
General FunctionWatermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication

Audio

Audio CompressionG.711U, G.711A
Audio Bitrate128 Kbps
Two-way AudioSupport
SuppressionSupport
Sampling Rate16KHZ

Storage

Edge StorageMicroSD, up to 512 GB
Network StorageANR, NAS (NFS)

PTZ

Number of Presets1024
Preset Patrol16 patrols, up to 64 presets for each patrol
Patrol Stay Time120 s to 1800 s
Home PositionSupport
Pan Range0° to 345°
Tilt Range-10° to 100°
Pan Speed1°/s to 40°/s
Tilt Speed1°/s to 30°/s

Network & Security

ProtocolsTLS1.3, SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible IntegrationONVIF (Profile S, Profile G, Profile T, Profile M), SDK, API
SecurityPassword Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
ClientEZStation, UNV-Link, UNV-Link Pro
Web BrowserPlug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above

Interface

Audio I/O1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
Alarm I/O1/1
Built-in MicSupport
Built-in SpeakerSupport
Network1 × RJ45 10 M/100 M Base-TX Ethernet

Certification

EMCCE-EMC (EN 55032: 2015+A11: 2020+A1: 2020, EN 50130-4: 2011+A1: 2014, EN 61000-3-3: 2013+A1: 2019+A2: 2021, EN IEC 61000-3-2: 2019+A1: 2021)
SafetyCE LVD (EN 62368-1: 2020+A11: 2020); UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
EnvironmentCE-ROHS (2011/65/EU;(EU)2015/863)
ProtectionIP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)

General

PowerDC 12 V (±25%), PoE (IEEE 802.3at)
Power Consumption18 W
Power InterfaceØ5.5 mm coaxial power plug
Dimensions133 mm × 185 mm × 286 mm (Ø5.2" × 7.3" × 11.3") (L × W × H)
Weight788 g (1.74 lb.)
Working Environment-30 °C to 60 °C (-22 °F to 140 °F), Humidity: ≤ 95% RH (non-condensing)
Storage Environment-40 °C to 70 °C (-40 °F to 158 °F), Humidity: ≤ 95% RH (non-condensing)
Surge Protection2 KV
Reset ButtonSupport
HeaterSupport
Web Client Language22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak
Configurable P/NSupport

Dimensions

Engineering drawing reproduced 1:1 from the official datasheet.

dimensions
unit: mm (in.)
Dimensions133 mm × 185 mm × 286 mm (Ø5.2" × 7.3" × 11.3") (L × W × H)
Weight788 g (1.74 lb.)
PowerDC 12 V (±25%), PoE (IEEE 802.3at)
Power Consumption18 W
Working Environment-30 °C to 60 °C (-22 °F to 140 °F), Humidity: ≤95% RH (non-condensing)
ProtectionIP66 · 2 KV surge

Optional Mounting Accessories

Order together with the camera to save shipping.

TR-JB07-D-INBullet junction box (support wiring from behind)
TR-UP06-B-INBullet pole mounting bracket
TR-CM06-DAlarm ball machine hoisting bracket
TR-UC08-CBullet & dome corner mounting bracket
TR-A01-INNPT 3/4'' waterproof cable gland
TR-UP06-C-INPole mounting bracket for bullet junction box only

Related Solutions & Products

Gas Station Security solution
Solution · Gas Station Security
A filling station: forecourt pumps, canopy, shop counter, tanker unloading bay. A mini PTZ like this one is the piece that does the looking.
Villa Security solution
Solution · Villa Security
A private villa: gate, driveway, garden, back door. A mini PTZ like this one is the piece that does the looking.
IPC6314LWH-AX5C-VG2
IPC6314LWH-AX5C-VG2 · 4MP
Same family, 4MP instead of 2MP — the resolution step that decides your storage bill.
NVR501-04B / NVR501-08B / NVR501-16B
