Uniview · PTZ CameraLightHunter · Active Deterrence

5MP Active Deterrence Mini PTZ · 5× Auto-Tracking

IPC6325LFW-AX5C-VG

Name: IPC6325LFW-AX5C-VG
Brand: Uniview

A compact PTZ that zooms 5× into any corner of the yard and speaks up when something is wrong: built-in mic and speaker back the smart intrusion alarm, while LightHunter low-light imaging keeps color detail after dark.

2880×1620 · main stream @30fpsAuto Tracking · human-only filteringActive Deterrence · built-in mic + speakerIP66 · weatherproof housingPoE · IEEE 802.3at / DC 12V512 GB · MicroSD edge storage

Get Best Price on WhatsApp Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your designated warehouse after payment · Out-of-stock or insufficient stock: 7–15 working days

Sample quantities are welcome — testing one or two units first is the normal way to start.

Compliance:ONVIF Profile SONVIF Profile GONVIF Profile TONVIF Profile M

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

5 MPResolution, 1/2.7" CMOS

5×Optical zoom, 2.7-13.5 mm

50 mSmart IR (+15 m warm light)

120 dBWDR, wide dynamic range

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

Small business perimeterCross line, intrusion and enter/leave-area detection with human/non-motor/vehicle classification and false-alarm filtering; the built-in speaker plays a voice warning the moment someone crosses the line.

Parking lots & driveways5× optical zoom (2.7-13.5 mm) lets one pole check a plate at the far end of the lot; auto tracking keeps a moving person centered once selected.

Retail entrancesBuilt-in mic and two-way audio let staff talk to a visitor directly from the camera; LightHunter keeps skin tones and signage colors readable at 0.005 Lux.

Warehouse yards & loading docksIP66 housing and -30 °C to 60 °C operation cover open yards in most climates; at 1.32 kg the mini PTZ mounts on a wall bracket or junction box without a heavy pole arm.

Gated communitiesPeople counting and crowd density monitoring track foot traffic at a gate, and auto tracking filters for human targets only — it won't chase every car or pet that passes.

Night watch on dim corridorsICR day/night switching plus Smart IR to 50 m and 15 m of warm light keep a walkway visible after dark, with digital defog and 2D/3D DNR for damp or low-contrast nights.

Not the right pick if you need…

No face recognition or face database on this model — the Intelligent feature set here covers tracking, intrusion detection and people counting only. If face ID matters, pick a model whose datasheet lists a face database.
This is a single-channel zoom PTZ, not a panorama-plus-detail linkage unit — it won't give you a simultaneous full-scene overview and a zoomed-in view. For that, look at our panoramic-linkage PTZ models.
Smart IR reaches 50 m and warm light 15 m — modest ranges for a PTZ. For long, open perimeters beyond 100 m at night, a longer-throw IR or laser PTZ is the better fit.

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

End-User Project PriceEnd user with a real project? Send your requirements / BOQ — best price, plus professional system design & planning advice

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Camera

Sensor	1/2.7" CMOS
Max Resolution	5 MP
Min. Illumination	Color: 0.005 Lux (F1.2, AGC ON), 0 Lux with IR
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 to 1/100000 s
WDR	120 dB
S/N	> 56 dB

Lens & Field of View

Focal Length	2.7 to 13.5 mm
Optical Zoom	5×
Iris	F1.2
Field of View (H)	106.9° to 30.6°
Field of View (V)	56° to 17.7°
Field of View (D)	131.5° to 36.1°

Illuminator

Light On/Off Control	Auto/Manual
Wavelength	850 nm
Illumination Distance (IR)	50 m (164.0 ft.)
Illumination Distance (Warm Light)	15 m (49.2 ft.)


White Balance	Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2
Digital Noise Reduction	2D/3D DNR
Flip	Normal, Flip vertical, Flip horizontal, 180°
HLC	Support
BLC	Support
Smart IR	Support
Defog	Digital defog

Video

Privacy Mask	Up to 4 areas
Video Compression	Ultra 265, H.265, H.264, MJPEG
Main Stream	5 MP (2880 × 1620), max. 30 fps
Sub Stream	720P (1280 × 720), max. 30 fps
Third Stream	D1 (720 × 576), max. 30 fps
Video Bit Rate	128 Kbps to 16 Mbps
U-code	Support
ROI	Support
Video Stream	Triple streams
OSD	Up to 8 OSDs

Intelligent

Auto Tracking	Support, target filtering: human only
Smart Intrusion Prevention	Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting	Support people flow counting and crowd density monitoring
Exception Detection	Object removed, Object Left Behind, Scene change, Defocus detection

Audio

Audio Compression	G.711U, G.711A
Audio Bitrate	128 Kbps
Two-way Audio	Support
Suppression	Support
Sampling Rate	16 kHz

Storage

Edge Storage	MicroSD, up to 512 GB
Network Storage	ANR, NAS (NFS)

Events

Basic Detection	Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind, Scene change, Defocus detection
General Function	Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication

PTZ

Number of Presets	1024
Preset Patrol	16 patrols, up to 64 presets for each patrol
Patrol Stay Time	120 s to 1800 s
Home Position	Support
Pan Range	0° to 345°
Tilt Range	-10° to 100°
Pan Speed	1°/s to 50°/s
Tilt Speed	1°/s to 40°/s

Network & Security

Protocols	TLS1.3, SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible Integration	ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK
Security	Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client	EZStation, UNV-Link, UNV-Link Pro
Web Browser	Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
Web Client Language	22 languages

Interface

Audio I/O	1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
Alarm I/O	1/1
Built-in Mic	Support
Built-in Speaker	Support
Network	1 × RJ45 10 M/100 M Base-TX Ethernet

Certification

EMC	CE-EMC (EN 55032: 2015+A11: 2020+A1: 2020, EN 50130-4: 2011+A1: 2014, EN 61000-3-3: 2013+A1: 2019+A2: 2021, EN IEC 61000-3-2: 2019+A1: 2021)
Safety	CE LVD (EN 62368-1: 2020+A11: 2020); UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment	CE-ROHS (2011/65/EU; (EU) 2015/863)
Protection	IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)

General

Power Consumption	18 W
Power Interface	Ø5.5 mm coaxial power plug
Storage Environment	-40 °C to 70 °C (-40 °F to 158 °F), ≤95% RH non-condensing
Surge Protection	2 KV
Reset Button	Support
Heater	Support
Configurable P/N	Support

Dimensions	185 mm × 133 mm × 286 mm (7.3" × 5.2" × 11.3") (L × W × H)
Weight	1.32 kg (2.91 lb.)
Power	DC 12 V (±25%), PoE (IEEE 802.3at)
Working Environment	-30 °C to 60 °C (-22 °F to 140 °F), ≤95% RH non-condensing
Protection	IP66

IPC6325LFW-AX5C-VG

Is this the right camera for you?

Worried about counterfeits? Order under your own company name.

Using your own freight forwarder? No problem.

Key Features

Two Things It Does Well: Zoom-In Detail + Active Deterrence

5× optical zoom (2.7-13.5 mm) with human-only auto tracking and DORI Detect distance up to 247.5 m at full telephoto

Smart intrusion prevention with classification and false-alarm filtering, backed by a built-in mic and speaker for on-the-spot two-way audio warnings

How far can it see? (DORI — Optical Channel)
