Uniview · PTZ CameraLightHunter IR Series

4MP X33 Lighthunter IR PTZ Camera · UNV Large-Model Auto Tracking

IPC6624SR-X33-VD2

Name: IPC6624SR-X33-VD2
Brand: Uniview

A 4MP intelligent network PTZ camera with 33× optical zoom and UNV Large-Model auto tracking — it locks onto and continuously follows vehicles, non-motor vehicles and pedestrians, even through occlusion or multi-target crossing, day or night out to 200 m.

4.5–148.5 mm · focal length120 dB · true WDRAuto Tracking · UNV Large ModelSmart Intrusion · cross line / area, classified1024 · presets · 16 patrolsPoE · IEEE 802.3at (or DC/AC 24V)

Get Best Price on WhatsApp Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your designated warehouse after payment · Out-of-stock or insufficient stock: 7–15 working days

Sample quantities are welcome — testing one or two units first is the normal way to start.

Compliance:ONVIF Profile SONVIF Profile GONVIF Profile T

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

4 MPMax resolution

33×Optical zoom (8× digital)

200 mIR illumination distance

IP67 · IK10Housing protection

The IPC6624SR-X33-VD2 is a 4MP intelligent network PTZ camera with 33× optical / 8× digital zoom (4.5–148.5 mm, F1.5–F4.0) and Wise-ISP low-light processing, backed by 120 dB true WDR and >56 dB S/N for high-contrast outdoor scenes. UNV LM-Auto Tracking accurately identifies and continuously tracks motor vehicles, non-motor vehicles and pedestrians — even through occlusion, multi-target crossing or high-speed motion — while Smart Intrusion Prevention covers cross-line, enter-area, leave-area and intrusion detection with classification-based false-alarm filtering, plus people-flow counting and crowd-density detection. IR illumination reaches 200 m, heatwave reduction and adaptive defog keep long-zoom images clear outdoors, and the IP67 / IK10 housing runs from -40 °C to 70 °C on DC 24 V, AC 24 V or PoE (IEEE 802.3at).

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

Shopping malls & commercial complexes33× zoom covers a wide atrium or car-park entrance from one pole and still reads a distant storefront; UNV LM-Auto Tracking follows a loitering or fast-moving subject across the plaza, and people counting / crowd density feed footfall analytics for mall operations.

Parking structures & entrancesAuto tracking classifies and follows vehicles as they enter, while adaptive highlight compensation (HLC) tames headlight glare at night so plates and faces near the barrier stay readable.

Perimeter & rooftop protectionSmart Intrusion Prevention covers cross-line, enter-area, leave-area and intrusion detection with false-alarm filtering by classifying human, non-motor vehicle and vehicle targets.

Open plazas & event spaces360° endless pan plus people-flow counting and crowd-density detection help operators watch attendance and spot congestion during busy events.

Long approach roads, night200 m IR illumination plus 33× telephoto reach targets far down an approach road; heatwave reduction and adaptive defog keep the long-zoom image usable in haze or summer heat shimmer.

Harsh-climate installationsIP67 sealing, IK10 vandal resistance, -40 °C to 70 °C operation and 6 kV surge protection, with the flexibility to run on DC 24 V, AC 24 V or PoE (IEEE 802.3at) depending on what's already at the pole.

Not the right pick if you need…

No fixed 360° panorama overview channel — this is a single classic PTZ head. If you need a fixed wide overview running alongside the zoom detail, choose a panoramic-linkage model instead.
If using PoE, it must be IEEE 802.3at (PoE+) to cover the max 20.90 W draw — a basic 802.3af (15.4 W) injector or switch port is not enough; otherwise plan DC 24 V or AC 24 V power instead.
No official dimensional drawing was published for this model — only the text figures (Ø227 mm × 390 mm, 5.21 kg) are available; request a drawing from us before finalizing bracket or enclosure cutouts.
No accessories list is published on this datasheet — confirm mounting bracket compatibility with us before ordering.

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

End-User Project PriceEnd user with a real project? Send your requirements / BOQ — best price, plus professional system design & planning advice

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Key Features

Complete list from the official datasheet.

Wise-ISP image processing engine, intelligent noise reduction, stunning visual effects in low-light conditions

Smart Intrusion Prevention (SIP): cross line, enter area, leave area and intrusion detection; detects and captures motor vehicles, non-motor vehicles and pedestrians and raises alarms

UNV LM-Auto Tracking: accurately identifies and continuously tracks motor vehicles, non-motor vehicles and pedestrians — even through occlusion, multi-target crossing or high-speed motion — with real-time adaptive bounding boxes

People counting: supports people-flow counting and crowd-density monitoring, applicable to various scenarios

Automatic selection of best snapshots; supports face detection masked area

120 dB true WDR meets the image requirements in high-contrast scenes

Heatwave reduction effectively mitigates the heatwave effect in high-temperature outdoor environments and ensures clear images

Adaptive defog automatically adjusts the defog level according to fog and haze intensity

200 m (656.2 ft) illumination distance, smart IR illumination, automatically adjusts image settings according to the scene, offering natural night-time images

Adaptive highlight compensation (HLC) automatically adjusts image brightness at night when moving vehicles are detected on the road

Advanced H.265 and SVC video compression technologies, higher compression efficiency, flexible application

ROI (region of interest) ensures image quality in areas of interest with low bandwidth; supports picture overlay and custom OSD

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Camera

Max Resolution	4 MP
Sensor	1/2.8" CMOS
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 to 1/100000 s
WDR	120 dB
S/N	> 56 dB
Min. Illumination	Color: 0.0005 Lux (F1.5, AGC ON), 0 Lux with IR
Case Type	PT

Lens & Field of View

Focal Length	4.5 to 148.5 mm
Optical Zoom	33×
Digital Zoom	8×
Iris	F1.5 to F4.0
Field of View (H)	53.61° to 2.68°
Field of View (V)	31.73° to 1.50°
Field of View (D)	63.26° to 3.30°

Illuminator

IR On/Off Control	Auto/Manual
Illumination Distance (IR)	200 m (656.2 ft.)


White Balance	Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2, Area white balance
Digital Noise Reduction	2D/3D DNR
BLC	Support
HLC	Support
Flip	Normal, Flip vertical, Flip horizontal, 180°
Defog	Digital defog
Low Illumination Characteristics	ColorHunter with Wise-ISP
Image Stabilization	DIS

Video

Video Compression	H.265, H.264, MJPEG, Ultra 265
Frame Rate	Main Stream Max: 4 MP (2688×1520), 30 fps · Main Stream Default: 4 MP (2560×1440), 25 fps · Sub Stream Max: 1080P (1920×1080), 30 fps · Third/Fourth/Fifth Stream Max: D1 (720×576), 30 fps
Video Bit Rate	128 Kbps to 16 Mbps
U-code	Support
Privacy Mask	24 areas, up to 8 areas per scene
ROI	Up to 8 areas
Video Stream	Five streams
OSD	Up to 10 OSDs

Audio

Audio Compression	G.711U, G.711A, AAC-LC
Two-way Audio	Support
Suppression	Support
Sampling Rate	8 kHz, 16 kHz

Storage

Edge Storage	MicroSD, up to 512 GB
Network Storage	NAS (NFS)

Intelligent

People Counting	Support people flow counting and crowd density detection
Exception Detection	Object removed, Object Left Behind
Auto Tracking	UNV Large Model
Smart Intrusion Prevention	Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)

PTZ

Preset Patrol	16 patrols, up to 64 presets for each patrol
Patrol Stay Time	15 s to 1800 s
Pan Range	360° (endless)
Pan Speed	0.1°/s to 288°/s
Tilt Range	-15° to 90° (auto flip)
Tilt Speed	0.1°/s to 288°/s
Number of Presets	1024
Preset Image Freeze	Support
Home Position	Support

Network & Security

Protocols	SSH, IGMP, RTP, RTMP, RTCP, IPv4, SSL/TLS, QoS, 802.1x, HTTPS, HTTP, UPnP, NTP, DDNS, DNS, RTSP, DHCP, UDP, TCP, ARP, ICMP, IPv6, SMTP, PPPoE, SNMP
Compatible Integration	SDK, API, ONVIF (Profile S, Profile G, Profile T, Profile M)
User/Host	Up to 32 users. 3 user levels: administrator, common user and operator
Security	Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF, TLS 1.3
Client	EZStation, UNV-Link, UNV-Link Pro
Web Browser	Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+; Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+

Events

General Function

Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output, HTTP authentication

Interface

Audio I/O	1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
Alarm I/O	2/1
Network	1 × RJ45 10 M/100 M Base-TX Ethernet
Serial Port	1 × RS485
Power Interface	Wires with cold-pressed terminal

Certification

Safety	UL (UL 62368-1) · CUL (CAN/CSA C22.2 No. 62368-1) · CE-LVD (EN IEC 62368-1)
EMC	CE-EMC (EN 55032; EN IEC 61000-3-2; EN 61000-3-3; EN 50130) · FCC SDoC (47 CFR Part 15; Subpart B)
Environment	CE-RoHS (2011/65/EU; (EU) 2015/863) · WEEE (2012/19/EU)
Protection	IP67 (IEC 60529) · IK10 (IEC 62262, Anti-Vandalism Except for the Front Window)

Configurable / Live View

P/N	Support
Reset Button	Support
3D Privacy Mask	Support

Dimensions	Ø227 mm × 390 mm (Ø8.9" × 15.4") (Ø × H)
Weight	5.21 kg (11.48 lb.)
Power	DC 24 V ±25%, AC 24 V ±25%, PoE (IEEE 802.3at)
Power Consumption	Max. 20.90 W
Working Environment	-40 °C to 70 °C (-40 °F to 158 °F), ≤95% RH non-condensing
Protection	IP67 (IEC 60529) · IK10 (IEC 62262, except front window)
Surge Protection	6 kV
