PTZ Cameras › IPC6652EL-X33-VF

2MP 33× lightHunter Laser IR PTZ Camera IPC6652EL-X33-VF

2MP 33× lightHunter Laser IR PTZ Camera IPC6652EL-X33-VF — view 1

2MP 33× lightHunter Laser IR PTZ Camera IPC6652EL-X33-VF — view 2

Uniview (UNV) · Laser PTZLightHunter · Laser IR

2MP 33× lightHunter Laser IR PTZ Camera

IPC6652EL-X33-VF

Name: IPC6652EL-X33-VF
Brand: Uniview
SKU: IPC6652EL-X33-VF

A laser PTZ camera built for long, dark distances: 33× optical zoom paired with a vari-focal laser that reaches 500 m and automatically matches whatever zoom position you're on, plus LightHunter low-light imaging that keeps color detail after dark.

1920×1080 · main stream @60fps4.5-148.5mm · 33x zoom focal length0.001 Lux · color min. illuminationSmart Intrusion · person/vehicle classificationIP66 · weatherproof housing-40~70°C · with heater for cold climates

Get Best Price on WhatsApp

Lead time · In stock: at your forwarder’s China warehouse 3 days after payment · Not in stock: 7–15 working days · Then air 5–10 days / sea 25–45 days to your port

Terms · Sample orders welcome · Quotation / PI fixes models, prices, Incoterms (typically FOB Shenzhen), lead time and T/T payment · Defective units: free spare units agreed per order (quantity depends on order size) and written into the quotation · Warranty: up to 5 years on Zhongxin Shutong industrial switches, manufacturer warranty on other brands · Full terms, warranty & RMA

Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your forwarder's warehouse in China after payment · Out-of-stock: 7–15 working days · then air 5–10 days or sea 25–45 days to your port

Sample quantities are welcome — testing one or two units first is the normal way to start.

Compliance:ONVIF Profile SONVIF Profile GONVIF Profile TONVIF Profile M

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

1080P1920×1080 @60fps main stream

33×Optical zoom (16× digital)

500 mVari-focal laser IR distance

IP66Ingress protection rating

The IPC6652EL-X33-VF is a 2MP laser IR PTZ camera built around a 1/2.8-inch CMOS sensor with 33× optical zoom (4.5-148.5 mm, 16× digital) and a vari-focal laser illuminator reaching up to 500 m — laser output is automatically proportional to the current optical zoom, so illumination always matches the field of view. LightHunter low-light processing keeps color detail at 0.001 Lux, while smart intrusion prevention (cross line, intrusion, enter/leave area) filters false alarms by classifying person, non-motor vehicle and vehicle, and people counting adds flow statistics with crowd-density monitoring. The camera runs on AC 24 V, DC 24 V or PoE, and its -40 °C to 70 °C IP66 housing includes a heater for cold climates.

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

Long perimeter fence lines33× optical zoom plus a 500 m vari-focal laser that automatically matches whatever zoom position you're on — smart intrusion detection (cross line, intrusion, enter/leave area) filters false alarms by classifying person, non-motor vehicle and vehicle.

Highways & open roads at nightLightHunter low-light processing keeps color detail down to 0.001 Lux, and the laser illuminator scales its output with zoom so distant vehicles at full telephoto still get proper illumination.

Ports & large industrial yards360° endless pan and -15° to 90° tilt cover a wide yard from one pole; 1024 presets and 16 route patrols (up to 32 actions each) let one operator cycle through many checkpoints automatically.

Extreme-climate installationsRated -40 °C to 70 °C with a built-in heater keeps the camera working through winter cold, while the IP66 housing and 6 kV surge protection handle rain, dust and power spikes on an exposed pole.

City crowd & pedestrian areasPeople counting adds flow statistics and crowd-density monitoring across multiple zones, useful for gauging occupancy at entrances, plazas or event sites without a separate sensor.

General perimeter patrolObject-removed and object-left-behind detection round out the event set, and false-alarm filtering by classification means fewer nuisance alerts from blowing leaves or small animals on route patrol.

Not the right pick if you need…

No built-in mic or speaker (both N/A) — two-way audio works only through the 1-in/1-out audio terminals with your own external mic and speaker, and there's no WiFi module on this model.
2MP (1920×1080) resolution — if the job needs 4K-level forensic detail at long range rather than laser-assisted zoom reach, a higher-megapixel PTZ is a better fit.
The datasheet lists IP66 ingress protection only — no IK10 vandal-resistance rating is documented for this model, unlike some heavier-duty PTZ housings.
Power options are AC 24 V, DC 24 V or PoE (PSE required) — plan the correct supply and PSE-compliant PoE injector/switch before ordering; a standard 802.3af/at port alone is not guaranteed to work.

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

Verified Project PriceDistributor, integrator or end user with a real project? Send the BOQ — project pricing plus free system design. Partner projects are protected: we never quote your end customer behind you

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Key Features

Complete list from the official datasheet.

High-quality 1080P image on a 1/2.8-inch CMOS sensor — 1920×1080 @60fps in the main stream

Ultra 265, H.265, H.264, MJPEG video compression

33× optical zoom (4.5-148.5 mm), 16× digital zoom

Smart intrusion prevention with false-alarm filtering — cross line, intrusion, enter-area and leave-area detection

Automatic selection of best snapshots; supports face-detection masked area

People counting — people-flow counting and crowd-density monitoring for different statistical scenarios

LightHunter technology ensures ultra-high image quality in low-illumination environments

Vari-focal laser: up to 500 m (1640 ft), proportional to the camera module's optical zoom

AC 24 V±25%, DC 24 V±25%, or PoE (PSE required)

Alarm I/O: 2/1, audio I/O: 1/1

IP66 ingress protection

Long-Range Laser IR + 33× Optical Zoom

Two core capabilities from the official datasheet.

VARI-FOCAL LASER

Reaches up to 500 m (1640 ft), with output automatically proportional to the camera's current optical zoom position

undefined

SMART DETECTION

Cross line, intrusion, enter/leave-area detection with person / vehicle classification and false-alarm filtering, plus people counting and crowd-density monitoring

undefined

How far can it see? (DORI — Full Telephoto)

DORI (EN 62676-4) is the industry standard for what a camera can do at distance. Values shown are at full 33× telephoto (4.5-148.5 mm lens); the datasheet gives a range from wide end to tele end for each DORI level.

Detectsomething is there

2187.9 m7178.2 ft

Observewhat is happening

875.2 m2871.3 ft

Recognizesomeone you know

437.6 m1435.7 ft

Identifybeyond doubt

218.8 m717.8 ft

How wide a view at each distance

Scene width covered at typical mounting distances — the number you need to work out how many cameras a wall, yard or aisle takes.

Distance	56.2° wide	2.6° tele
5 m16 ft	5.3 m17.5 ft	0.2 m0.7 ft
10 m33 ft	10.7 m35.0 ft	0.5 m1.5 ft
15 m49 ft	16.0 m52.6 ft	0.7 m2.2 ft
20 m66 ft	21.4 m70.1 ft	0.9 m3.0 ft
30 m98 ft	32.0 m105 ft	1.4 m4.5 ft

Calculated from the horizontal field of view in the specifications below: width = 2 × distance × tan(FOV ÷ 2). Lens distortion and mounting angle are not included.

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Camera

Sensor	1/2.8" CMOS
Min. Illumination	Color: 0.001 Lux (F1.5, AGC ON), 0 Lux with IR
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 to 1/100000 s
WDR	120 dB
S/N	> 52 dB

Lens & Field of View

Focal Length	4.5 to 148.5 mm
Optical Zoom	33X
Digital Zoom	16X
Iris	F1.5 to F4.0
Field of View (H)	56.2° to 2.6°
Field of View (V)	33.5° to 1.4°
Field of View (D)	69.2° to 3.0°

Illuminator

Vari-focal Laser	Up to 500 m (1640.4 ft.), proportional to optical zoom
Light On/Off Control	Auto/Manual
Wavelength	850 nm

DORI Distance

DORI Distance (Lens)	4.5 to 148.5 mm
DORI Distance (Detect)	72.9 m to 2187.9 m (239.2 ft. to 7178.2 ft.)
DORI Distance (Observe)	29.2 m to 875.2 m (95.7 ft. to 2871.3 ft.)
DORI Distance (Recognize)	14.6 m to 437.6 m (47.9 ft. to 1435.7 ft.)
DORI Distance (Identify)	7.3 m to 218.8 m (24.0 ft. to 717.8 ft.)


White Balance	Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2
Digital Noise Reduction	2D/3D DNR
Flip	Normal, Flip vertical, Flip horizontal, 180°
HLC	Support
BLC	Support
Defog	Digital defog
Heatwave Reduction	Support

Video

Video Compression	Ultra 265, H.265, H.264, MJPEG
Frame Rate	Main Stream: 1080P (1920×1080), max. 60 fps · Sub Stream: 1080P (1920×1080), max. 60 fps · Third Stream: D1 (720×576), max. 60 fps
Video Bit Rate	128 Kbps to 16 Mbps
U-code	Support
ROI	Support
Video Stream	Triple streams
Privacy Mask	24 areas, up to 4 areas per scene
OSD	Up to 10 OSDs

Events

Basic Detection	Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind
General Function	Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output

Audio

Audio Compression	G.711U, G.711A
Audio Bitrate	128 Kbps
Two-way Audio	Support
Suppression	Support
Sampling Rate	16 KHZ

Storage

Edge Storage	MicroSD, up to 512 GB
Network Storage	ANR, NAS (NFS)

Intelligent

Exception Detection	Object removed, Object Left Behind
Smart Intrusion Prevention	Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting	Support people flow counting and crowd density monitoring

PTZ

Route Patrol	16 patrols, up to 32 actions for each patrol
Recorded Patrol	16 patrols, up to 128 actions for each patrol
Number of Presets	1024
Preset Image Freeze	Support
Preset Patrol	16 patrols, up to 64 presets for each patrol
Patrol Stay Time	15 s to 1800 s
Home Position	Support
Pan Range	360° (endless)
Pan Speed	0.1°/s to 200°/s
Tilt Range	-15° to 90° (auto reverse)
Tilt Speed	0.1°/s to 200°/s

Network & Security

User/Host	Up to 32 users. 3 user levels: administrator, common user and operator
Protocols	SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible Integration	ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK
Security	TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client	EZStation, UNV-Link, UNV-Link Pro
Web Browser	Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+

Interface

Audio I/O	1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
WIFI	N/A
Alarm I/O	2/1
Serial Port	1 × RS485
Built-in Mic	N/A
Built-in Speaker	N/A
Network	1 × RJ45 10 M/100 M Base-TX Ethernet
Video Output	1 BNC (for debugging)

Certification

EMC	CE-EMC (EN 55032:2015; EN 55024:2010+A1:2015; EN 61000-3-2:2014; EN 61000-3-3:2013) · FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Environment	CE-ROHS (2011/65/EU; (EU)2015/863)
Protection	IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)

General

Power	AC 24 V±25%, DC 24 V±25%, PoE (PSE Required)
Power Consumption	Max. 53 W
Power Interface	Wires with cold-pressed terminal
Dimensions	Ø270 mm × 385 mm (Ø8.9" × 15.2") (Ø × H)
Weight	5.6 kg (12.35 lb.)
Working Environment	-40 °C to 70 °C (-40 °F to 158 °F), Humidity: ≤95% RH (non-condensing)
Storage Environment	-40 °C to 70 °C (-40 °F to 158 °F), Humidity: ≤95% RH (non-condensing)
Surge Protection	6 KV
Reset Button	Support
Web Client Language	22 languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak
Heater	Support

Dimensions

Engineering drawing reproduced 1:1 from the official datasheet.

unit: mm (in.)

Dimensions	Ø270 mm × 385 mm (Ø8.9" × 15.2") (Ø × H)
Weight	5.6 kg (12.35 lb.)
Power	AC 24 V±25%, DC 24 V±25%, PoE (PSE required) · max. 53 W
Working Environment	-40 °C to 70 °C (-40 °F to 158 °F), ≤95% RH non-condensing
Protection	IP66 · 6 kV surge
Heater	Support

Optional Mounting Accessories

Order together with the camera to save shipping.

TR-UF45-A-INDome indoor ceiling mounting pedestal

TR-SE45-A-INDome ceiling mounting pole 500

TR-SE45-INDome ceiling mounting pole 200

TR-CE45-INDome indoor ceiling mounting bracket

TR-WE45-INDome wall mounting bracket

TR-WE45-A-INLong wall mounting bracket for dome

TR-JB12-INDome junction box

TR-WE45-B-INDome gooseneck bracket

TR-UP08-A-INDome pole mounting bracket

TR-UP08-B-INAluminium alloy pole mounting bracket

TR-UC08-A-INDome corner mounting bracket

TR-UC08-B-INAluminium alloy corner mounting bracket

2MP 33x Laser PTZ Camera FAQ — IPC6652EL-X33-VF

How far does the laser IR reach at night?

The vari-focal laser illuminator reaches up to 500 m (1640 ft), adjusting in proportion to the optical zoom so the beam matches your field of view. Wavelength is 850 nm with auto or manual control, and the sensor sees 0.001 lux in color, 0 lux with IR.

At what distance can it detect and recognize a person?

With the 33x lens (4.5–148.5 mm), DORI figures at full telephoto are: detect 2187.9 m, observe 875.2 m, recognize 437.6 m and identify 218.8 m. That pairs the 500 m laser with enough optical reach for long fence lines and open compounds.

Why 2MP instead of 4MP or 8MP for this job?

This model trades pixel count for speed and sensitivity: the main and sub streams both run 1080p at up to 60 fps, which keeps fast-moving vehicles sharp, and the sensor works at 0.001 lux. Ultra 265 compression holds the bit rate between 128 Kbps and 16 Mbps.

Can it keep recording if the connection to the NVR fails?

Yes. It takes a MicroSD card up to 512 GB for edge recording, and ANR support lets footage captured during an outage be filled back to the recorder afterwards. NAS (NFS) network storage is also supported, and two-way audio works for gate intercom duty.

Does it survive desert heat and heavy rain?

Per the product data it is IP66 rated and works from -40 to 70 °C, so Sahel heat and coastal storms are within spec. Heatwave reduction cuts shimmer over hot ground at long zoom, and digital defog, HLC and BLC handle haze and glare.
