2MP 16X LightHunter Network PTZ Dome Camera IPC6412LR-X16-VG

2MP 16X LightHunter Network PTZ Dome Camera IPC6412LR-X16-VG — view 1

2MP 16X LightHunter Network PTZ Dome Camera IPC6412LR-X16-VG — view 2

Uniview (UNV) · PTZ CameraLightHunter · PTZ Dome

2MP 16X LightHunter Network PTZ Dome Camera

IPC6412LR-X16-VG

Name: IPC6412LR-X16-VG
Brand: Uniview
SKU: IPC6412LR-X16-VG

16x optical zoom (5–80 mm) reaches out to 124.1 m identify-level detail, while LightHunter low-light imaging and 100 m Smart IR keep color and clarity around the clock. Auto-tracking locks onto people and vehicles automatically.

5–80 mm · 16x optical zoom lens1920×1080 · main stream @30fpsAuto-Track · human / vehicle classification0.003 Lux · LightHunter color low-lightPoE+ · IEEE 802.3at or DC 12V512 GB · MicroSD edge storage

Get Best Price on WhatsApp

Lead time · In stock: at your forwarder’s China warehouse 3 days after payment · Not in stock: 7–15 working days · Then air 5–10 days / sea 25–45 days to your port

Terms · Sample orders welcome · Quotation / PI fixes models, prices, Incoterms (typically FOB Shenzhen), lead time and T/T payment · Defective units: free spare units agreed per order (quantity depends on order size) and written into the quotation · Warranty: up to 5 years on Zhongxin Shutong industrial switches, manufacturer warranty on other brands · Full terms, warranty & RMA

Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your forwarder's warehouse in China after payment · Out-of-stock: 7–15 working days · then air 5–10 days or sea 25–45 days to your port

Sample quantities are welcome — testing one or two units first is the normal way to start.

Compliance:ONVIF Profile SONVIF Profile GONVIF Profile T

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

2 MP1920×1080 @30fps main stream

16×Optical zoom (5-80 mm)

100 mSmart IR distance

IP66Outdoor housing protection

The IPC6412LR-X16-VG is a 2MP network PTZ dome camera with a 16x optical zoom lens (5-80 mm, F1.7-F2.8) and 1/2.8-inch CMOS sensor delivering 1920x1080 @30fps. LightHunter low-light technology reaches 0.003 Lux color (0 Lux with IR), backed by 100 m Smart IR, auto-tracking with human / non-motor vehicle / vehicle classification, smart intrusion prevention with false-alarm filtering, and people counting with crowd-density monitoring. It is powered by PoE+ (IEEE 802.3at) or DC 12V, rated IP66 with a -40 °C to 65 °C operating range.

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

Perimeter & industrial yardsSmart intrusion prevention (cross line, intrusion, enter/leave area) with false-alarm filtering and human/non-motor/vehicle classification watches an open boundary without constant manual PTZ control.

Roadways & vehicle gatesAuto-tracking classifies human, non-motor vehicle and vehicle targets; the 16x optical zoom (5-80 mm) closes in on distant plates up to the 124.1 m identify-level DORI distance.

Public squares & crowd flowPeople counting supports flow statistics and crowd-density monitoring, suitable for different statistical scenarios per the datasheet — useful for gates, plazas and event entrances.

Low-light & nighttime sitesLightHunter imaging reaches 0.003 Lux color (0 Lux with IR on); when it gets fully dark, 100 m Smart IR takes over, backed by heatwave reduction and digital defog for hazy nights.

Wide-area patrol with presets1024 presets with 16 preset patrols (up to 64 presets each) and 16 route/recorded patrols let one PTZ cover many fixed points on a schedule instead of staffing multiple fixed cameras.

Outdoor pole & wall mountsIP66 sealing, -40 °C to 65 °C operation, 6 kV surge protection, a reset button and heater support keep the camera working through cold winters and hot summers on an outdoor pole.

Not the right pick if you need…

No audio at all — Audio I/O, built-in mic, built-in speaker and video output are all N/A on this model. If you need two-way audio or alarm I/O, pick a different model.
No serial port and no WiFi — network connection is 1x RJ45 10M/100M only, and multi-target simultaneous detection is not supported.
IP66 rated, not IP67 — and no IK-rating is stated in the datasheet. For submersion-rated or heavily vandalism-prone sites, look at a ruggedized housing model instead.

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

Verified Project PriceDistributor, integrator or end user with a real project? Send the BOQ — project pricing plus free system design. Partner projects are protected: we never quote your end customer behind you

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Key Features

Complete list from the official datasheet.

1080P image quality, 1/2.8" CMOS sensor — 1920×1080 @30fps in the main stream

Ultra 265, H.265, H.264, MJPEG video compression

16x optical zoom (5-80 mm, F1.7-F2.8) allows closer viewing of subjects

Smart intrusion prevention with false-alarm filtering — cross line, intrusion, enter area, leave area detection, classification of human, non-motor vehicle and vehicle

Auto tracking with target filtering: human, non-motor vehicle and vehicle

People counting: people flow counting and crowd density monitoring, suitable for different statistical scenarios

LightHunter technology ensures ultra-high image quality in low-illumination environments

Smart IR up to 100 m (328 ft.) distance

MicroSD edge storage up to 512 GB, plus ANR and NAS (NFS) network storage

DC 12V±25%, PoE+ (IEEE 802.3at) power, IP66 ingress protection

Two Things This Camera Does Best

16x optical zoom to reach out, LightHunter and Smart IR to see in the dark.

16X OPTICAL ZOOM

5-80 mm lens reaches identify-level detail up to 124.1 m away

F1.7-F2.8 iris, 1024 presets and 16 preset patrols let one camera cover many points and zoom in on demand.

LIGHTHUNTER & SMART IR

0.003 Lux color imaging, 0 Lux with IR, plus 100 m Smart IR

Color detail late into the night, then automatic Smart IR hand-off once it gets fully dark.

How far can it see? (DORI Standard)

DORI (EN 62676-4) is the industry standard for what a camera can do at distance. Values below are shown at full 16x telephoto zoom (80 mm); at the wide end (5 mm) distances are shorter — see the full range in the spec table below.

Detectsomething is there

1241.4 m4072.8 ft

Observewhat is happening

496.6 m1629.1 ft

Recognizesomeone you know

248.3 m814.6 ft

Identifybeyond doubt

124.1 m407.3 ft

How wide a view at each distance

Scene width covered at typical mounting distances — the number you need to work out how many cameras a wall, yard or aisle takes.

Distance	51.7° wide	4.9° tele
5 m16 ft	4.8 m15.9 ft	0.4 m1.4 ft
10 m33 ft	9.7 m31.8 ft	0.9 m2.8 ft
15 m49 ft	14.5 m47.7 ft	1.3 m4.2 ft
20 m66 ft	19.4 m63.6 ft	1.7 m5.6 ft
30 m98 ft	29.1 m95.4 ft	2.6 m8.4 ft

Calculated from the horizontal field of view in the specifications below: width = 2 × distance × tan(FOV ÷ 2). Lens distortion and mounting angle are not included.

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Camera

Sensor	1/2.8" CMOS
Min. Illumination	Color: 0.003 Lux (F1.7, AGC ON), 0 Lux with IR
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 ~ 1/100000s
WDR	120 dB
S/N	>52 dB

Lens & Field of View

Focal Length	5 to 80 mm
Optical Zoom	16X
Iris	F1.7 to F2.8
Field of View (H)	51.70° to 4.89°
Field of View (V)	30.49° to 2.75°
Field of View (D)	63.59° to 5.77°

DORI (EN 62676-4)

DORI Distance (Lens)	5 to 80 mm
DORI Distance (Detect)	77.6 m to 1241.4 m (254.5 ft. to 4072.8 ft.)
DORI Distance (Observe)	31.0 m to 496.6 m (101.8 ft. to 1629.1 ft.)
DORI Distance (Recognize)	15.5 m to 248.3 m (50.9 ft. to 814.6 ft.)
DORI Distance (Identify)	7.8 m to 124.1 m (25.5 ft. to 407.3 ft.)

Video

Privacy Mask	24 areas, up to 4 areas per scene
Video Compression	Ultra 265, H.265, H.264, MJPEG
Main Stream	1080P (1920×1080), max. 30 fps
Sub Stream	720P (1280×720), max. 30 fps
Third Stream	D1 (720×576), max. 30 fps
Video Bit Rate	128 Kbps to 16 Mbps
U-code	Support
ROI	Support
Video Stream	Triple streams
OSD	Up to 8 OSDs

Intelligent

Auto Tracking	Support, target filtering: human, non-motor vehicle and vehicle
Multi-target Detection	N/A
Smart Intrusion Prevention	Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting	Support people flow counting and crowd density monitoring
Exception Detection	Object removed, Object Left Behind


White Balance	Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2
Digital Noise Reduction	2D/3D DNR
Flip	Normal, Flip vertical, Flip horizontal, 180°
HLC	Support
BLC	Support
Smart IR	Support
Defog	Digital defog
Heatwave Reduction	Support

Events

Basic Detection	Motion detection, Tampering alarm, Object removed, Object Left Behind
General Function	Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication

Storage

Edge Storage	MicroSD, up to 512 GB
Network Storage	ANR, NAS (NFS)

Illuminator

IR On/Off Control	Auto/Manual
Wavelength	850 nm
Illumination Distance (IR)	100 m (328.1 ft.)

Network

Protocols	SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible Integration	ONVIF (Profile S, Profile G, Profile T), API, SDK
User/Host	Up to 32 users. 3 user levels: administrator, common user and operator
Security	TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client	EZStation, UNV-Link, UNV-Link Pro
Web Browser	Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+

PTZ

Number of Presets	1024
Preset Patrol	16 patrols, up to 64 presets for each patrol
Route Patrol	16 patrols, up to 32 actions for each patrol
Recorded Patrol	16 patrols, up to 128 actions for each patrol
Patrol Stay Time	15 s to 1800 s
Preset Image Freeze	N/A
Home Position	Support
Pan Range	360° (endless)
Tilt Range	0.1°/s to 80°/s
Pan Speed	-15° to 90° (auto reverse)
Tilt Speed	0.1°/s to 80°/s

Interface

Audio I/O	N/A
Alarm I/O	N/A
Serial Port	N/A
Built-in Mic	N/A
Built-in Speaker	N/A
WIFI	N/A
Network	1 × RJ45 10 M/100 M Base-TX Ethernet
Video Output	N/A

Certification

EMC	CE-EMC (EN 55032: 2015+A1:2020, EN 61000-3-3: 2013+A1: 2019, EN IEC 61000-3-2: 2019+A1: 2021, EN 55035: 2017+A11:2020); FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Safety	CE LVD (EN 62368-1:2014+A11:2017); UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment	CE-ROHS (2011/65/EU; (EU)2015/863)
Protection	IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)

General

Power	DC 12 V (±25%,3 A), PoE+ (IEEE 802.3at)
Power Consumption	Max. 20 W
Power Interface	Ø5.5 mm coaxial power plug
Dimensions	Ø162 mm × 293 mm (Ø6.4" × 11.5") (Ø × H)
Weight	1.79 kg (3.95 lb.)
Working Environment	-40 °C to 65 °C (-40 °F to 149 °F), Humidity: ≤ 95% RH (non-condensing)
Storage Environment	-40 °C to 70 °C (-40 °F to 158 °F), Humidity: ≤ 95% RH (non-condensing)
Surge Protection	6 KV
Reset Button	Support
Heater	Support
Web Client Language	22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak
Configurable (P/N)	Support

Dimensions

Engineering drawing reproduced 1:1 from the official datasheet.

unit: mm (in.)

Dimensions	Ø162 mm × 293 mm (Ø6.4" × 11.5") (Ø × H)
Weight	1.79 kg (3.95 lb.)
Power	DC 12 V (±25%, 3 A), PoE+ (IEEE 802.3at)
Working Environment	-40 °C to 65 °C (-40 °F to 149 °F), ≤95% RH non-condensing
Protection	IP66 · 6 kV surge protection

16x Zoom PTZ Camera FAQ — IPC6412LR-X16-VG

How far can the IPC6412LR-X16-VG see with its 16x zoom?

The 5–80 mm 16x lens (F1.7–F2.8) delivers DORI figures of detect up to 1241.4 m, observe up to 496.6 m, recognize up to 248.3 m and identify up to 124.1 m at the tele end — enough to read a person at over 100 m on a fence line or open yard.

What is its night performance?

LightHunter imaging holds color down to 0.003 lux (F1.7, AGC on), so color detail lasts late into dusk. Once fully dark, Smart IR takes over automatically with a range up to 100 m, and Smart IR exposure control keeps nearby subjects from being overexposed.

What targets can it track automatically?

Auto tracking filters for humans, non-motor vehicles and vehicles, so it can follow a person, motorbike or car through the scene. Smart intrusion prevention adds cross-line, intrusion, enter-area and leave-area detection with false-alarm filtering, plus people flow counting and crowd density monitoring.

How is it powered?

The listing specifies PoE+, so one network cable from a PoE+ switch or NVR PoE port supplies both power and video. That avoids running separate mains power up the pole and keeps the installation to a single Cat5e/Cat6 run per camera.

Where does it store footage?

Besides streaming to your NVR, it records to a MicroSD card up to 512 GB at the edge, with ANR backfilling the recorder after network cuts so nothing is lost. NAS (NFS) network storage is supported too. Video is triple-stream, 1080p at up to 30 fps.
