PTZ Cameras › IPC6424SR-X25-VF

4MP 25× LightHunter PTZ Dome Camera, Smart IR 100 m IPC6424SR-X25-VF

4MP 25× LightHunter PTZ Dome Camera, Smart IR 100 m IPC6424SR-X25-VF — view 1

4MP 25× LightHunter PTZ Dome Camera, Smart IR 100 m IPC6424SR-X25-VF — view 2

4MP 25× LightHunter PTZ Dome Camera, Smart IR 100 m IPC6424SR-X25-VF — view 3

Uniview (UNV) · PTZ CameraLightHunter · PTZ Dome

4MP 25× LightHunter PTZ Dome · Smart IR 100 m

IPC6424SR-X25-VF

Name: IPC6424SR-X25-VF
Brand: Uniview
SKU: IPC6424SR-X25-VF

A 4MP PTZ dome camera with 25× optical zoom (4.8–120 mm) that locks onto and tracks people and vehicles automatically — LightHunter low-light imaging and Smart IR to 100 m keep it working after dark, in an IP67/IK10 housing rated -40 °C to 70 °C.

2688×1520 · main stream @30fps4.8–120 mm · 25× optical / 16× digitalAuto-Track · human / non-motor / vehicleLightHunter · ultra-low-light imagingIP67 · IK10 · vandal-proof housingPoE+ · or DC 12 V, max. 21 W

Get Best Price on WhatsApp

Lead time · In stock: at your forwarder’s China warehouse 3 days after payment · Not in stock: 7–15 working days · Then air 5–10 days / sea 25–45 days to your port

Terms · Sample orders welcome · Quotation / PI fixes models, prices, Incoterms (typically FOB Shenzhen), lead time and T/T payment · Defective units: free spare units agreed per order (quantity depends on order size) and written into the quotation · Warranty: up to 5 years on Zhongxin Shutong industrial switches, manufacturer warranty on other brands · Full terms, warranty & RMA

Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your forwarder's warehouse in China after payment · Out-of-stock: 7–15 working days · then air 5–10 days or sea 25–45 days to your port

Sample quantities are welcome — testing one or two units first is the normal way to start.

Compliance:ONVIF Profile SONVIF Profile GONVIF Profile T

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

4 MP1/2.8" CMOS, 2688×1520

25×Optical zoom, 4.8–120 mm

100 mSmart IR distance

-40~70°CIP67 · IK10 wide-temp housing

The IPC6424SR-X25-VF is a 4MP 25× optical-zoom LightHunter PTZ dome camera built around a 1/2.8-inch CMOS sensor delivering 2688×1520 at up to 30 fps, with a 4.8–120 mm motorized lens (16× digital zoom on top of the optical range). Auto tracking classifies human, non-motor vehicle and vehicle targets, smart intrusion prevention covers cross-line / intrusion / area enter-leave with false-alarm filtering by classification, and people counting reports flow and crowd density. LightHunter low-light processing plus Smart IR up to 100 m keep images usable after dark; the housing is IP67 and IK10 rated for -40 °C to 70 °C operation, powered by DC 12 V or PoE+ (IEEE 802.3at).

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

City road checkpoints25× optical zoom (4.8–120 mm) reaches deep into an intersection while auto tracking classifies human, non-motor vehicle and vehicle targets — built for reading plate and lane detail from a checkpoint pole.

Transportation hubs & interchangesSmart intrusion prevention (cross line, intrusion, enter/leave area) with false-alarm filtering by classification covers ramps and platform edges, while people counting reports flow and crowd density across a busy hub.

Mixed traffic at intersectionsTarget-classification filtering separates cars, non-motor vehicles and pedestrians so alarms stay meaningful in dense mixed traffic; the 0.1–200°/s tilt and 0.1–288°/s pan give the operator fast manual pursuit when needed.

Night patrol on expressways & ring roadsLightHunter low-light processing plus Smart IR up to 100 m keep the scene visible after dark, and heatwave reduction stops summer road heat from smearing long-zoom footage on straight expressway stretches.

Crowd flow at transit stationsPeople counting reports flow statistics and crowd-density monitoring suited to different statistical scenarios — useful for gate queues and platform crowding without a dedicated people-counting camera.

Harsh outdoor pole mountsIP67 sealing, IK10 vandal resistance, -40 °C to 70 °C operation and 6 kV surge protection let it sit on an exposed road-side or overpass pole through heat, cold and storms.

Not the right pick if you need…

No built-in mic or speaker and no Wi-Fi (all N/A per datasheet) — audio and wireless connectivity need an external device or a different model.
No on-device face-recognition library — auto tracking classifies human / non-motor / vehicle targets but does not match faces against a watch list; a panoramic-linkage model is the pick for face-DB requirements.
Network port is 10 M/100 M Base-TX, not Gigabit — plan bandwidth accordingly if you run high-bitrate triple streams to a distant NVR.
Illuminator is Smart IR only (850 nm, up to 100 m) — there is no warm-light option on this model; for full-color night capture at range, a dual-light PTZ is the better fit.

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

Verified Project PriceDistributor, integrator or end user with a real project? Send the BOQ — project pricing plus free system design. Partner projects are protected: we never quote your end customer behind you

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Key Features

Complete list from the official datasheet.

High quality image with 4 MP, 1/2.8" CMOS sensor

2688 × 1520 @30 fps in the main stream

Ultra 265, H.265, H.264, MJPEG

Triple streams

25X optical zoom

Smart intrusion prevention, supports false alarm filtering, including cross line, intrusion, enter area, leave area detection

Automatic selection of best snapshots, supports face detection masked area (as stated in manufacturer datasheet)

People counting, supports people flow counting and crowd density monitoring, suitable for different statistical scenarios

LightHunter technology ensures ultra-high image quality in low illumination environment

Smart IR, up to 100 m (328 ft) IR distance

DC 12 V±25%, PoE+ (IEEE 802.3at)

Alarm I/O: 2/1, audio I/O: 1/1

IP67 ingress protection

IK10 vandal resistant

Two Standout Capabilities: 25× Zoom + Smart IR Tracking

What this single-lens PTZ actually does, from the official datasheet.

OPTICAL ZOOM

25× optical zoom (4.8–120 mm) plus 16× digital zoom reaches deep into a scene for plate- and face-level detail at distance

undefined

SMART IR + TRACKING

100 m Smart IR paired with auto tracking (human / non-motor / vehicle classification) keeps subjects lit and locked after dark

undefined

How far can it see? (DORI — EN 62676-4)

DORI (EN 62676-4) is the industry standard for what a camera can do at distance. Values shown are at full 25× telephoto (4.8–120 mm lens); the full-manual DORI range for the whole zoom is in the spec table below.

Detectsomething is there

2475 m8120.1 ft

Observewhat is happening

990 m3248.0 ft

Recognizesomeone you know

495 m1624.0 ft

Identifybeyond doubt

247.5 m812.0 ft

How wide a view at each distance

Scene width covered at typical mounting distances — the number you need to work out how many cameras a wall, yard or aisle takes.

Distance	52.2° wide	2.7° tele
5 m16 ft	4.9 m16.1 ft	0.2 m0.8 ft
10 m33 ft	9.8 m32.1 ft	0.5 m1.6 ft
15 m49 ft	14.7 m48.2 ft	0.7 m2.4 ft
20 m66 ft	19.6 m64.3 ft	1.0 m3.1 ft
30 m98 ft	29.4 m96.4 ft	1.4 m4.7 ft

Calculated from the horizontal field of view in the specifications below: width = 2 × distance × tan(FOV ÷ 2). Lens distortion and mounting angle are not included.

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Camera

Sensor	1/2.8" CMOS
Min. Illumination	Color: 0.003 Lux (F1.5, AGC ON), 0 Lux with IR
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 ~ 1/100000s
WDR	120 dB
S/N	> 56 dB

Lens & Field of View

Focal Length	4.8 to 120 mm
Optical Zoom	25X
Digital Zoom	16X
Iris	F1.5 to F3.8
Field of View (H)	52.20° to 2.74°
Field of View (V)	30.81° to 1.54°
Field of View (D)	64.20° to 3.23°

DORI

DORI Distance (Lens)	4.8 to 120 mm
DORI Distance (Detect)	119.3 m to 2475.0 m (391.2 ft. to 8120.1 ft.)
DORI Distance (Observe)	47.7 m to 990.0 m (156.5 ft. to 3248.0 ft.)
DORI Distance (Recognize)	23.9 m to 495.0 m (78.2 ft. to 1624.0 ft.)
DORI Distance (Identify)	11.9 m to 247.5 m (39.1 ft. to 812.0 ft.)

Illuminator

IR On/Off Control	Auto/Manual
Wavelength	850 nm
Illumination Distance (IR)	100 m (328.1 ft.)

Video

Privacy Mask	24 areas, up to 4 areas per scene
Video Compression	Ultra 265, H.265, H.264, MJPEG
Frame Rate	Main Stream: 4 MP (2688 × 1520), max. 30 fps · Sub Stream: 1080P (1920 × 1080), max. 30 fps · Third Stream: D1 (720 × 576), max. 30 fps
Video Bit Rate	128 Kbps to 16 Mbps
U-code	Support
ROI	Support
Video Stream	Triple streams
OSD	Up to 10 OSDs

Intelligent

Auto Tracking	Support, target filtering: human, non-motor vehicle and vehicle
Smart Intrusion Prevention	Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting	Support people flow counting and crowd density monitoring


White Balance	Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2
Digital Noise Reduction	2D/3D DNR
Flip	Normal, Flip vertical, Flip horizontal, 180°
HLC	Support
BLC	Support
Smart IR	Support
Defog	Digital defog
Heatwave Reduction	Support

Events

Basic Detection	Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind
General Function	Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output

Audio

Audio Compression	G.711U, G.711A
Audio Bitrate	128 Kbps
Two-way Audio	Support
Suppression	Support
Sampling Rate	16 kHz

Storage

Edge Storage	MicroSD, up to 512 GB
Network Storage	ANR, NAS (NFS)

Network

Protocols	SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible Integration	ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK
User/Host	Up to 32 users. 3 user levels: administrator, common user and operator
Security	TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client	EZStation, UNV-Link, UNV-Link Pro
Web Browser	Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+

PTZ

Number of Presets	1024
Preset Patrol	16 patrols, up to 64 presets for each patrol
Route Patrol	16 patrols, up to 32 actions for each patrol
Recorded Patrol	16 patrols, up to 128 actions for each patrol
Patrol Stay Time	15 s to 1800 s
Preset Image Freeze	Support
Home Position	Support
Pan Range	360° (endless)
Tilt Range	-15° to 90° (auto flip)
Pan Speed	0.1°/s to 200°/s
Tilt Speed	0.1°/s to 120°/s

Interface

Audio I/O	1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
Alarm I/O	2/1
Serial Port	1 × RS485
Built-in Mic	N/A
Built-in Speaker	N/A
WIFI	N/A
Network	1 × RJ45 10 M/100 M Base-TX Ethernet
Video Output	1 BNC (for debugging)

Certification

EMC	CE-EMC (EN 55032: 2015+A1:2020, EN 61000-3-3: 2013+A1: 2019, EN IEC 61000-3-2: 2019+A1: 2021, EN 55035: 2017+A11:2020) · FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Safety	CE LVD (EN 62368-1:2014+A11:2017) · UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment	CE-ROHS (2011/65/EU; (EU)2015/863)
Protection	IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) · IK10 (IEC 62262:2002)

General

Surge Protection	6 KV
Reset Button	Support
Configurable P/N	Support

Dimensions

Engineering drawing reproduced 1:1 from the official datasheet.

unit: mm (in.)

Dimensions	Φ162 mm × 293 mm (Φ6.4" × 11.5") (Φ × H)
Weight	3.05 kg (6.72 lb.)
Power	DC 12 V (±25%, 3 A), PoE+ (IEEE 802.3at) · max. 21 W
Working Environment	-40 °C to 70 °C (-40 °F to 158 °F), ≤95% RH non-condensing
Protection	IP67 (IEC 60529) · IK10 (IEC 62262) · 6 kV surge
Power Interface	Ø5.5 mm coaxial power plug

Optional Mounting Accessories

Order together with the camera to save shipping.

TR-UF45-A-INDome indoor ceiling mounting pedestal

TR-SE45-A-INDome ceiling mounting pole 500

TR-SE45-INDome ceiling mounting pole 200

TR-CE45-INDome indoor ceiling mounting bracket

TR-WE45-INDome wall mounting bracket

TR-WE45-A-INLong wall mounting bracket for dome

TR-WE45-B-INDome gooseneck bracket

TR-JB12-INDome junction box

TR-UP08-A-INDome pole mounting bracket

TR-UP08-B-INAluminium alloy pole mounting bracket

TR-UC08-A-INDome corner mounting bracket

TR-UC08-B-INAluminium alloy corner mounting bracket

4MP 25x PTZ Camera FAQ — IPC6424SR-X25-VF

What range does the IPC6424SR-X25-VF cover with 25x zoom?

The 4.8–120 mm lens (25x optical, 16x digital, F1.5–F3.8) posts DORI figures of detect up to 2475 m, observe up to 990 m, recognize up to 495 m and identify up to 247.5 m at the tele end. That is genuine long-range coverage for perimeters, farms and industrial estates.

How far does the IR reach at night?

The 850 nm illuminator reaches 100 m (328 ft), with Smart IR exposure control so close targets are not overexposed. Before switching to IR, LightHunter color imaging holds to 0.003 lux (F1.5, AGC on), and 120 dB WDR plus digital defog and heatwave reduction keep the picture clean.

Can it track vehicles as well as people?

Yes. Auto tracking filters for humans, non-motor vehicles and vehicles, so it follows a person, motorbike or car through the scene. Smart intrusion prevention adds cross-line, intrusion, enter-area and leave-area detection with false-alarm filtering, plus people flow counting and crowd density monitoring.

How do I power and mount it?

The listing specifies PoE+, so one Cat5e/Cat6 run from a PoE+ switch carries power and video to the pole — no separate mains feed needed at the camera. The IP67/IK10 housing, per the listing, is built for dusty, wet and rough outdoor locations.

What video quality does it record?

The main stream is 4 MP (2688×1520) at up to 30 fps, with a 1080p sub stream and a D1 third stream. Bit rate is adjustable from 128 Kbps to 16 Mbps using Ultra 265, H.265, H.264 or MJPEG, and two-way audio via G.711 lets an operator speak through the camera.
