PTZ Cameras › IPC6622SR-X25-VF

2MP 25X LightHunter Network PTZ Dome Camera IPC6622SR-X25-VF

2MP 25X LightHunter Network PTZ Dome Camera IPC6622SR-X25-VF — view 1

2MP 25X LightHunter Network PTZ Dome Camera IPC6622SR-X25-VF — view 2

2MP 25X LightHunter Network PTZ Dome Camera IPC6622SR-X25-VF — view 3

Uniview (UNV) · PTZ CameraLightHunter · 25X PTZ Dome

2MP 25X LightHunter PTZ Dome · Smart IR 150 m

IPC6622SR-X25-VF

Name: IPC6622SR-X25-VF
Brand: Uniview
SKU: IPC6622SR-X25-VF

A 2MP 25× optical-zoom LightHunter network PTZ dome camera: a 1/2.8" CMOS sensor with 120 dB WDR handles harsh light, smart intrusion prevention tracks people and vehicles across the scene, and Smart IR up to 150 m keeps the image usable after dark — in an IP66 housing rated -40 °C to 70 °C.

1920×1080 · main stream @60fps5-125 mm · motorized lens, F1.5-F4.0Smart Intrusion · with classification filteringPeople Counting · + crowd densityIP66 · outdoor-rated housing-40~70°C · wide temp range, heater

Get Best Price on WhatsApp

Lead time · In stock: at your forwarder’s China warehouse 3 days after payment · Not in stock: 7–15 working days · Then air 5–10 days / sea 25–45 days to your port

Terms · Sample orders welcome · Quotation / PI fixes models, prices, Incoterms (typically FOB Shenzhen), lead time and T/T payment · Defective units: free spare units agreed per order (quantity depends on order size) and written into the quotation · Warranty: up to 5 years on Zhongxin Shutong industrial switches, manufacturer warranty on other brands · Full terms, warranty & RMA

Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your forwarder's warehouse in China after payment · Out-of-stock: 7–15 working days · then air 5–10 days or sea 25–45 days to your port

Sample quantities are welcome — testing one or two units first is the normal way to start.

Compliance:ONVIF Profile SONVIF Profile GONVIF Profile T

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

2 MP1920×1080 main stream

25×Optical zoom (16× digital)

150 mSmart IR distance

120 dBWide dynamic range

The IPC6622SR-X25-VF is a 2MP 25× optical-zoom (16× digital) LightHunter network PTZ dome camera built around a 1/2.8" CMOS sensor (5 to 125 mm motorized lens, F1.5-F4.0), streaming 1920×1080 up to 60 fps in Ultra 265, H.265, H.264 or MJPEG. LightHunter low-light processing holds color down to 0.001 Lux (F1.5, AGC ON) and continues at 0 Lux with IR, while 120 dB WDR and a 52 dB S/N ratio keep the image clean in mixed light. Onboard smart intrusion prevention (cross line, intrusion, enter/leave area, with false-alarm filtering and human / non-motor / motor vehicle classification) and people counting with crowd-density monitoring run alongside a 150 m Smart IR illuminator, all in an IP66, -40 °C to 70 °C housing powered by AC 24 V, DC 24 V or PoE+ (IEEE 802.3at).

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

Perimeter with long-range identifySmart intrusion prevention (cross line, intrusion, enter/leave area) with false-alarm filtering; the 25× lens reaches an Identify distance of 170.7 m (560.0 ft.) at full zoom, so a distant intruder can be confirmed, not just spotted.

Mixed traffic at intersectionsSmart intrusion prevention classifies human, non-motor vehicle and motor vehicle to cut false alarms from swaying trees or passing traffic; 120 dB WDR handles headlight glare and mixed light at dusk.

Low light and after darkLightHunter processing holds color to 0.001 Lux (F1.5, AGC ON); once it goes fully dark, Smart IR up to 150 m and 0 Lux imaging take over so the camera keeps working through the night.

Plazas and transit hubsPeople counting with flow statistics and crowd-density monitoring runs continuously while the PTZ head is free to zoom in on any point of interest — 1024 presets and 16 preset patrols keep a fixed patrol route running unattended.

Continuous zoom patrolEndless 360° pan, -15° to 90° auto-reverse tilt, pan and tilt speed up to 200°/s, plus 16 preset patrols with up to 64 presets each let one dome cover a wide perimeter on a fixed schedule.

Cold-climate outdoor mountsIP66 sealing, a built-in heater, -40 °C to 70 °C operation and 6 kV surge protection keep the dome running through winters and lightning-prone sites alike — not a vandal-rated (IK10) housing, so pair with a protective cage on exposed street-level poles.

Not the right pick if you need…

No built-in mic or speaker (both listed N/A on the datasheet) — audio I/O is 1 input / 1 output for an external mic and speaker, not an all-in-one talk unit.
No WiFi (listed N/A) — this is a wired network camera; plan an Ethernet run to the pole.
Not IK10 vandal-rated — the datasheet lists IP66 ingress protection only, with no impact-resistance certification. Choose an IK10 model for exposed, tamper-prone street-level mounts.
Single 25× zoom lens only — there is no separate wide fixed panorama channel, so it cannot watch the whole scene and hold a tight zoom at the same time. Pair with a fixed camera if you need simultaneous full-scene overview.

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

Verified Project PriceDistributor, integrator or end user with a real project? Send the BOQ — project pricing plus free system design. Partner projects are protected: we never quote your end customer behind you

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Key Features

Complete list from the official datasheet.

High quality image with 1080P, 1/2.8" CMOS sensor

1920×1080@60fps in the main stream

Ultra 265, H.265, H.264, MJPEG

25X optical zoom

Smart intrusion prevention, supports false alarm filtering, including cross line, intrusion, enter area, leave area detection

Automatic selection of best snapshots, supports face detection masked area

People counting, supports people flow counting and crowd density monitoring, suitable for different statistical scenarios

LightHunter technology ensures ultra-high image quality in low illumination environment

Smart IR, up to 150 m (492.1 ft) IR distance

AC 24 V±25%, DC 24 V±25%, PoE+ (IEEE 802.3at) power supply

Alarm I/O: 2/1, audio I/O: 1/1

IP66 ingress protection

Zoom & Low-Light: Two Capabilities, One Dome

The values below are drawn directly from the official datasheet.

OPTICAL ZOOM

25× optical / 16× digital zoom, 5-125 mm motorized lens, F1.5-F4.0

undefined

LOW-LIGHT & IR

LightHunter low-light imaging to 0.001 Lux color, plus Smart IR up to 150 m for 0 Lux operation

undefined

How far can it see? (DORI Standard)

DORI (EN 62676-4) is the industry standard for what a camera can do at distance. The datasheet gives DORI as a range across the 5-125 mm zoom; the bars below show the long-end (125 mm, full telephoto) values — the wide-angle end starts at 85.3 m Detect / 34.1 m Observe / 17.1 m Recognize / 8.5 m Identify. Note: the datasheet's own Observe figure (382.8 m / 2240.0 ft) does not internally reconcile between its metric and imperial values — printed here exactly as stated, unadjusted.

Detectsomething is there

1706.9 m5600.1 ft

Observewhat is happening

382.8 m2240.0 ft

Recognizesomeone you know

341.4 m1120.1 ft

Identifybeyond doubt

170.7 m560.0 ft

How wide a view at each distance

Scene width covered at typical mounting distances — the number you need to work out how many cameras a wall, yard or aisle takes.

Distance	54.4° wide	2.7° tele
5 m16 ft	5.1 m16.9 ft	0.2 m0.8 ft
10 m33 ft	10.3 m33.7 ft	0.5 m1.5 ft
15 m49 ft	15.4 m50.6 ft	0.7 m2.3 ft
20 m66 ft	20.5 m67.4 ft	0.9 m3.1 ft
30 m98 ft	30.8 m101 ft	1.4 m4.6 ft

Calculated from the horizontal field of view in the specifications below: width = 2 × distance × tan(FOV ÷ 2). Lens distortion and mounting angle are not included.

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Camera

Sensor	1/2.8" CMOS
Min. Illumination	Color: 0.001 Lux (F1.5, AGC ON), 0 Lux with IR
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 to 1/100000 s
WDR	120 dB
S/N	> 52 dB

Lens & Field of View

Focal Length	5 to 125 mm
Optical Zoom	25X
Digital Zoom	16X
Iris	F1.5 to F4.0
Field of View (H)	54.37° to 2.68°
Field of View (V)	32.23° to 1.51°
Field of View (D)	66.88° to 3.16°

DORI

DORI Distance (Lens)	5 to 125 mm
DORI Distance (Detect)	85.3 m to 1706.9 m (280.0 ft. to 5600.1 ft.)
DORI Distance (Observe)	34.1 m to 382.8 m (112.0 ft. to 2240.0 ft.)
DORI Distance (Recognize)	17.1 m to 341.4 m (56.1 ft. to 1120.1 ft.)
DORI Distance (Identify)	8.5 m to 170.7 m (28.0 ft. to 560.0 ft.)

Video

Video Compression	Ultra 265, H.265, H.264, MJPEG
Frame Rate	Main Stream: 1080P (1920 × 1080), max. 60 fps · Sub Stream: 1080P (1920 × 1080), max. 60 fps · Third Stream: D1 (720 × 576), max. 60 fps
Video Bit Rate	128 Kbps to 16 Mbps
U-code	Support
ROI	Support
Video Stream	Triple streams
Privacy Mask	24 areas, up to 4 areas per scene
OSD	Up to 10 OSDs

Events

Basic Detection	Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind
General Function	Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output

Audio

Audio Compression	G.711U, G.711A
Audio Bitrate	128 Kbps
Two-way Audio	Support
Suppression	Support
Sampling Rate	16 KHz

Storage

Edge Storage	MicroSD, up to 512 GB
Network Storage	ANR, NAS (NFS)

Illuminator

IR On/Off Control	Auto/Manual
Wavelength	850 nm
Illumination Distance (IR)	150 m (492.1 ft.)

Network

User/Host	Up to 32 users. 3 user levels: administrator, common user and operator
Protocols	SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible Integration	ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK
Security	TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client	EZStation, UNV-Link, UNV-Link Pro
Web Browser	Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+

Intelligent

Exception Detection	Object removed, Object Left Behind
Smart Intrusion Prevention	Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting	Support people flow counting and crowd density monitoring

PTZ

Route Patrol	16 patrols, up to 32 actions for each patrol
Recorded Patrol	16 patrols, up to 128 actions for each patrol
Number of Presets	1024
Preset Image Freeze	Support
Preset Patrol	16 patrols, up to 64 presets for each patrol
Patrol Stay Time	15 s to 1800 s
Home Position	Support
Pan Range	360° (endless)
Pan Speed	0.1°/s to 200°/s
Tilt Range	-15° to 90° (auto reverse)
Tilt Speed	0.1°/s to 200°/s


White Balance	Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2
Digital Noise Reduction	2D/3D DNR
Flip	Normal, Flip vertical, Flip horizontal, 180°
HLC	Support
BLC	Support
Smart IR	Support
Defog	Digital defog
Heatwave Reduction	Support

Interface

Audio I/O	1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
WIFI	N/A
Alarm I/O	2/1
Serial Port	1 × RS485
Built-in Mic	N/A
Built-in Speaker	N/A
Network	1 × RJ45 10 M/100 M Base-TX Ethernet
Video Output	1 BNC (for debugging)

Certification

EMC	CE-EMC (EN 55032:2015+A11:2020; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55035:2017+A11:2020); FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Safety	CE LVD (EN 62368-1:2014+A11:2017); UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment	CE-ROHS (2011/65/EU;(EU)2015/863)
Protection	IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)

General

Power	AC 24 V±25%, DC 24 V±25%, PoE+ (IEEE 802.3 at)
Power Consumption	Max. 25 W
Power Interface	Wires with cold-pressed terminal
Dimensions	Ø227 mm × 384.8 mm (Ø 8.9" × 15.1") (Ø × H)
Weight	5.28 kg (11.64 lb.)
Working Environment	-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing)
Storage Environment	-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing)
Surge Protection	6 KV
Reset Button	Support
Web Client Language	22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak
Heater	Support

Dimensions

Engineering drawing reproduced 1:1 from the official datasheet.

unit: mm (in.)

Dimensions	Ø227 mm × 384.8 mm (Ø8.9" × 15.1") (Ø × H)
Weight	5.28 kg (11.64 lb.)
Power	AC 24 V (±25%) / DC 24 V (±25%) · PoE+ (IEEE 802.3at) · max. 25 W
Working Environment	-40 °C to 70 °C (-40 °F to 158 °F), ≤95% RH non-condensing
Protection	IP66 · 6 kV surge · built-in heater

Optional Mounting Accessories

Order together with the camera to save shipping.

TR-UF45-A-INDome indoor ceiling mounting pedestal

TR-SE45-A-INDome ceiling mounting pole 500

TR-SE45-INDome ceiling mounting pole 200

TR-CE45-INDome indoor ceiling mounting bracket

TR-WE45-INDome wall mounting bracket

TR-WE45-A-INLong wall mounting bracket for dome

TR-JB12-INDome junction box

TR-WE45-B-INDome gooseneck bracket

TR-UP08-A-INDome pole mounting bracket

TR-UP08-B-INAluminium alloy pole mounting bracket

TR-UC08-A-INDome corner mounting bracket

TR-UC08-B-INAluminium alloy corner mounting bracket

2MP 25x PTZ Camera FAQ — IPC6622SR-X25-VF

Will the IPC6622SR-X25-VF work with my existing third-party NVR?

Yes. It integrates over ONVIF Profile S, G, T and M plus RTSP, so third-party NVRs and VMS platforms can pull its streams. Uniview's EZStation, UNV-Link and UNV-Link Pro clients are supported too, and an API/SDK is available if you need custom integration for a project.

What is the infrared range at night?

IR illumination at 850 nm reaches 150 m with automatic or manual on/off control. In color mode the LightHunter sensor works down to 0.001 lux (F1.5, AGC on), and at 0 lux the camera switches to IR black-and-white — so unlit roads, yards and fence lines stay visible all night.

How far can I identify a person with the 25x zoom?

The 5–125 mm motorized lens gives 25x optical zoom, extended by 16x digital. At full telephoto the DORI figures are 1706.9 m for detection, 341.4 m for recognition and 170.7 m for identification — enough to confirm who is standing at the far end of a large compound or along a fence line.

What happens to recordings if the network goes down?

The camera takes a microSD card up to 512 GB and supports ANR: during a network outage it records to the card, then backfills the recorder automatically when the link returns, so power or fiber cuts do not leave gaps in the archive. NAS (NFS) network storage is also supported.

Is the housing suitable for outdoor pole mounting?

Yes. The housing is IP66-rated and the camera operates from -40 to 70 °C, so it handles heavy rain, dust and direct sun on a pole or wall mount without an extra enclosure. Digital defog and 120 dB WDR keep backlit gates and hazy mornings readable.

How much bandwidth and how many users does it support?

Triple streams: main and sub at 1080p up to 60 fps plus a D1 third stream, with bit rate adjustable from 128 Kbps to 16 Mbps in Ultra 265, H.265, H.264 or MJPEG. Up to 32 users across three permission levels can connect, and TLS 1.3 with HTTPS secures remote access.
