PTZ Cameras › IPC94144SFW-X25-F40C
Uniview (UNV) · Panoramic PTZLightHunter · Dual-lens Linkage
4MP+4MP LightHunter Dual-lens Network PTZ Camera · 25× Linkage Tracking
IPC94144SFW-X25-F40C
A fixed wide-angle channel keeps watch over the whole scene while the 25× PTZ channel zooms in on demand — when the fixed channel's intrusion detection triggers, the PTZ channel automatically links to and tracks the target, day or night.
2688×1520 · fixed channel @25fps2688×1520 · PTZ channel @30fpsLinkage Tracking · fixed→PTZ handoverIR 100 m + Warm 30 m · dual illuminationIP66 · weatherproof housing-40~65°C · wide operating range
One unit, two channels
Both channels stream simultaneously from a single IP address — the spec table below shows Panorama and Detail values side by side.
Get Best Price on WhatsApp
Lead time · In stock: at your forwarder’s China warehouse 3 days after payment · Not in stock: 7–15 working days · Then air 5–10 days / sea 25–45 days to your port
Terms · Sample orders welcome · Quotation / PI fixes models, prices, Incoterms (typically FOB Shenzhen), lead time and T/T payment · Defective units: free spare units agreed per order (quantity depends on order size) and written into the quotation · Warranty: up to 5 years on Zhongxin Shutong industrial switches, manufacturer warranty on other brands · Full terms, warranty & RMA
Need the PDF datasheet? Get it on WhatsApp →In-stock models: 3 days to your forwarder's warehouse in China after payment · Out-of-stock: 7–15 working days · then air 5–10 days or sea 25–45 days to your port
Sample quantities are welcome — testing one or two units first is the normal way to start.
Compliance:ONVIF Profile SONVIF Profile GONVIF Profile TONVIF Profile M
Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.
The IPC94144SFW-X25-F40C integrates a fixed wide-angle channel (4 MP, 4.0 mm lens, 94.9° horizontal field of view) with a 25× optical-zoom PTZ channel (4 MP, 4.8-120 mm, 55.46° to 3.09° horizontal field of view) in one housing with single-IP dual-channel output. When the fixed channel's smart intrusion prevention detects a cross-line, intrusion, or area enter/leave event, it triggers the PTZ channel to link, zoom in and track the target automatically. LightHunter low-light technology plus a 100 m IR illuminator on the PTZ channel and a 30 m warm-light illuminator on the fixed channel keep both channels working around the clock. The camera also supports people counting, crowd density detection, face detection with masked-area filtering, and audio-visual warning, in an IP66-rated housing rated -40 °C to 65 °C.
Is this the right camera for you?
Plain-language guide for buyers and installers — based only on what this camera actually does.
Unlit roads & rural patrol routesNo streetlights? The fixed channel's 30 m warm light keeps a full-color view of the road at night, while the PTZ channel's 100 m IR extends detection range further out — useful on roads or rural patrol routes without fixed lighting.
Night construction sitesNighttime intrusion at a site with no lighting installed yet: the fixed channel's smart intrusion prevention (cross line / area entry) detects the event and automatically links the PTZ channel, which zooms in and tracks the person while the warm light keeps evidence in full color.
Perimeter with linkage trackingSet a cross-line or intrusion rule on the fixed channel with human / vehicle classification; the moment it triggers, the 25× PTZ channel links automatically, zooms to the target and keeps tracking it.
Parking lots & logistics yardsThe fixed channel's 94.9° view keeps watch over the whole lot while the PTZ channel zooms in 25× on any vehicle or gate of interest without needing a second camera.
People flow & crowd density monitoringBoth channels support people-flow counting and crowd-density detection across multiple statistical scenarios — from a single entrance to a wide plaza covered by the fixed channel.
Harsh outdoor mountsIP66 sealing, 4 kV surge protection and -40 °C to 65 °C working range make it suitable for outdoor poles and rooftops that see extreme heat or cold.
Not the right pick if you need…
- The fixed channel's field of view is 94.9° horizontal — not a full 360° panorama. If you need a single camera to cover an entire intersection or plaza with no blind spot, choose a true panoramic-linkage model instead.
- Network interface is 10 M/100 M Base-TX, not Gigabit — plan bandwidth accordingly if this camera shares a switch port with other heavy-bitrate devices.
- No built-in microphone and no analog video output — audio capture relies on the external audio input, and there is no local monitor output for this model.
- The PTZ channel's supplemental light is infrared only (100 m) — full-color warm-light illumination is limited to the fixed channel's 30 m range, so don't expect full-color zoom shots much beyond that distance in total darkness.
Worried about counterfeits? Order under your own company name.
For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.
1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site
Using your own freight forwarder? No problem.
For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.
EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order
Note: manufacturer order registration (left) is available via the corporate purchase channel.
How to get a better price
Volume Discount50+ units of a single model
CONTACT USMix & Match DiscountMix any categories & models storewide in one order — no quantity limit
BETTERVerified Project PriceDistributor, integrator or end user with a real project? Send the BOQ — project pricing plus free system design. Partner projects are protected: we never quote your end customer behind you
BESTAll discounts are quoted personally — message me on WhatsApp ↑
Key Features
Complete list from the official datasheet.
Fixed camera and PTZ camera integration, dual-channel with one IP, provides overall view and detailed view at the same time
Ultra 265, H.265, H.264, MJPEG
25X optical zoom of PTZ channel allows for closer viewing of subjects
Smart intrusion prevention, supports false alarm filtering, including cross line, intrusion, enter area, leave area detection
Automatic selection of best snapshots, supports face detection masked area
People counting, supports people flow counting and crowd density monitoring, suitable for different statistical scenarios
PTZ channel can be linked to fixed channel's smart intrusion prevention to track the objects triggering the rule
Supports sound and light warning, makes warning and alarming more noticeable
LightHunter technology ensures ultra-high image quality in low illumination environment
IR and warm light illumination to deal with different scenes and achieve full-color illumination
DC 12 V, PoE+ (IEEE 802.3at) power supply
Alarm I/O: 2/1, audio I/O: 1/1
One Body, Two Channels: Panorama + Detail PTZ
Both channels stream simultaneously from a single IP address.
PANORAMA CHANNEL
4MP fixed wide-angle channel (94.9° H) watches the whole scene continuously — with smart intrusion prevention, people counting and crowd density detection
undefined
DETAIL CHANNEL
4MP 25× PTZ channel links automatically when the fixed channel's intrusion prevention triggers — zooms in, centers and tracks the target, with 1024 presets and up to 16 patrols
undefined
How far can it see? (DORI — Optical Channel)
How far can it actually see? DORI distances for both channels, from the official datasheet.
Detectsomething is there
90 m295.3 ft
Observewhat is happening
36 m118.1 ft
Recognizesomeone you know
18 m59.1 ft
Identifybeyond doubt
9 m29.5 ft
How wide a view at each distance
Scene width covered at typical mounting distances — the number you need to work out how many cameras a wall, yard or aisle takes.
| Distance | AMA · 94.9° | 3.1° tele |
|---|---|---|
| 5 m16 ft | 10.9 m35.7 ft | 0.3 m0.9 ft |
| 10 m33 ft | 21.8 m71.5 ft | 0.5 m1.8 ft |
| 15 m49 ft | 32.7 m107 ft | 0.8 m2.7 ft |
| 20 m66 ft | 43.6 m143 ft | 1.1 m3.5 ft |
| 30 m98 ft | 65.4 m214 ft | 1.6 m5.3 ft |
Calculated from the horizontal field of view in the specifications below: width = 2 × distance × tan(FOV ÷ 2). Lens distortion and mounting angle are not included.
Full Specifications
Complete official specifications from the manufacturer's datasheet (technical values in English).
Highlighted rows are channel-specific:PANORAMA = 4MP fixed wide-angle channelDETAIL = 4MP 25× PTZ channel
Camera
| Sensor | PANORAMA · 1/1.8" CMOSDETAIL · 1/2.7" CMOS |
| Min. Illumination | PANORAMA · Color: 0.0005 Lux (F1.0, AGC ON), 0 lux with IRDETAIL · Color: 0.003 Lux (F1.5, AGC ON), 0 lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, 1 to 1/100000 s |
| WDR | 120 dB |
| S/N | > 56 dB |
Lens & Field of View
| Focal Length | PANORAMA · 4.0 mmDETAIL · 4.8 to 120 mm |
| Optical Zoom | PANORAMA · N/ADETAIL · 25× |
| Iris | PANORAMA · F1.0DETAIL · F1.5 to F3.8 |
| Field of View (H) | PANORAMA · 94.9°DETAIL · 55.46° to 3.09° |
| Field of View (V) | PANORAMA · 51.5°DETAIL · 32.94° to 1.73° |
| Field of View (D) | PANORAMA · 112.3°DETAIL · 68.22° to 3.65° |
Illuminator
| Light On/Off Control | Auto/Manual |
| Wavelength | PANORAMA · N/ADETAIL · 850 nm |
| Illumination Distance (IR) | PANORAMA · N/ADETAIL · 100 m (328.1 ft.) |
| Illumination Distance (Warm Light) | PANORAMA · 30 m (98.4 ft.)DETAIL · N/A |
| Supplemental Light | Warm light |
Video
| Privacy Mask | PANORAMA · Up to 4 areasDETAIL · 24 areas, up to 4 areas per scene |
| Main Stream | PANORAMA · 4 MP (2688×1520) @25 fps (Default)DETAIL · 4 MP (2688×1520), max. 30 fps |
| Sub Stream | PANORAMA · 720P (1280×720), max. 30 fpsDETAIL · 1080P (1920×1080), max. 30 fps |
| Third Stream | D1 (720×576), max. 30 fps |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Video Bit Rate | 128 Kbps to 16 Mbps |
| U-code | Support |
| ROI | Support |
| Video Stream | Triple streams |
| OSD | Up to 8 OSDs |
| White Balance | Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2 |
| Digital Noise Reduction | 2D/3D DNR |
| Flip | Normal, Flip vertical, Flip horizontal, 180° |
| HLC | Support |
| BLC | Support |
| Smart IR | Support |
| Defog | Digital defog |
| Heatwave Reduction | Support |
Events
| Basic Detection | Motion detection, Audio detection, Tampering alarm |
| General Function | Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output |
| UMD (Ultra Motion Detection) | Support |
Intelligent
| Linkage Function | PANORAMA · Support. Triggered by fixed lens via smart intrusion prevention function to track targetDETAIL · N/A |
| Smart Intrusion Prevention | Cross line detection, intrusion detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) |
| People Counting | Support people flow counting and crowd density detection |
| Exception Detection | PANORAMA · Object Left Behind, Object removed, Scene changeDETAIL · Object Left Behind, Object removed |
Audio
| Audio Compression | G.711U, G.711A |
| Audio Bitrate | 128 Kbps |
| Two-way Audio | Support |
| Suppression | Support |
| Sampling Rate | 16 kHz |
Storage
| Edge Storage | MicroSD, up to 512 GB |
| Network Storage | ANR |
Network & Security
| Protocols | SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK |
| User/Host | Up to 32 users. 3 user levels: administrator, common user and operator |
| Security | PANORAMA · TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIFDETAIL · Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF, TLS 1.3 |
| Client | EZStation, UNV-Link, UNV-Link Pro |
| Web Browser | Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+ |
PTZ
| Number of Presets | PANORAMA · N/ADETAIL · 1024 |
| Preset Patrol | PANORAMA · N/ADETAIL · 16 patrols, up to 64 presets for each patrol |
| Route Patrol | PANORAMA · N/ADETAIL · 16 patrols, up to 32 actions for each patrol |
| Recorded Patrol | PANORAMA · N/ADETAIL · 16 patrols, up to 128 actions for each patrol |
| Patrol Stay Time | 15 s to 1800 s |
| Preset Image Freeze | N/A |
| Home Position | PANORAMA · N/ADETAIL · Support |
| Number of Presets (IPC) | PANORAMA · N/ADETAIL · 1024 |
| Pan Range | PANORAMA · N/ADETAIL · 360° |
| Tilt Range | PANORAMA · 18°±5°DETAIL · -15° to 90° |
| Pan Speed | PANORAMA · N/ADETAIL · 0.1°/s to 80°/s |
| Tilt Speed | PANORAMA · N/ADETAIL · 0.1°/s to 80°/s |
Interface
| Audio I/O | 1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p] |
| Alarm I/O | 2/1 |
| Serial Port | 1 × RS485 |
| Built-in Mic | N/A |
| Built-in Speaker | Support |
| WIFI | N/A |
| Network | 1 × RJ45 10 M/100 M Base-TX Ethernet |
| Video Output | N/A |
Certification
| EMC | CE-EMC (EN 55032: 2015+A1: 2020, EN 61000-3-3: 2013+A1: 2019, EN IEC 61000-3-2: 2019+A1: 2021, EN 55035: 2017+A11: 2020); FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) |
| Safety | CE LVD (EN 62368-1: 2014+A11: 2017); UL (UL 62368-1, 2nd Ed, Issue Date: 2014-12-01) |
| Environment | CE-RoHS (2011/65/EU; (EU) 2015/863) |
| Protection | IP66 (IEC 60529: 1989+AMD1: 1999+AMD2: 2013) |
General
| Power | DC 12 V (±25%), PoE+ (IEEE 802.3at) |
| Power Consumption | Max. 24 W |
| Power Interface | Ø5.5 mm coaxial power plug |
| Dimensions | 304 mm × 195 mm × 163 mm (12.0" × 7.7" × 6.4") (L × W × H) |
| Weight | 2.27 kg (5.00 lb.) |
| Working Environment | -40 °C to 65 °C (-40 °F to 149 °F), Humidity: ≤95% RH (non-condensing) |
| Storage Environment | -40 °C to 70 °C (-40 °F to 158 °F), Humidity: ≤95% RH (non-condensing) |
| Surge Protection | 4 KV |
| Reset Button | Support |
| Web Client Language | 22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak |
Dimensions
Engineering drawing reproduced 1:1 from the official datasheet.
unit: mm (in.)
| Dimensions | 304 mm × 195 mm × 163 mm (12.0" × 7.7" × 6.4") (L × W × H) |
| Weight | 2.27 kg (5.00 lb.) |
| Power | DC 12 V (±25%), PoE+ (IEEE 802.3at) · max. 24 W |
| Working Environment | -40 °C to 65 °C (-40 °F to 149 °F), ≤95% RH non-condensing |
| Protection | IP66 (IEC 60529) · 4 kV surge |
| Power Interface | Ø5.5 mm coaxial power plug |
Optional Mounting Accessories
Order together with the camera to save shipping.
TR-UF45-A-INDome indoor ceiling mounting pedestal
TR-SE45-A-INDome ceiling mounting pole 500
TR-SE45-INDome ceiling mounting pole 200
TR-CE45-INDome indoor ceiling mounting bracket
TR-WE45-INDome wall mounting bracket
TR-WE45-A-INLong wall mounting bracket for dome
TR-WE45-B-INDome gooseneck bracket
TR-JB12-INDome junction box
TR-UP08-A-INDome pole mounting bracket
TR-UP08-B-INAluminium alloy pole mounting bracket
TR-UC08-A-INDome corner mounting bracket
TR-UC08-B-INAluminium alloy corner mounting bracket
Dual-Lens 25x PTZ FAQ — IPC94144SFW-X25-F40C
What do the two 4MP channels each do?
The fixed 4 mm channel holds a constant 94.9° wide view at 2688×1520, 25 fps default, while the 4.8–120 mm detail channel zooms 25x down to 3.09° for close-ups. When intrusion rules trigger on the wide channel, the zoom channel tracks the target automatically.
How far can the 25x zoom channel see?
The detail lens runs 4.8–120 mm with a field of view from 55.46° down to 3.09°, backed by 100 m of 850 nm IR for night reach. Minimum illumination is 0.003 lux colour on the detail channel and 0.0005 lux on the F1.0 wide channel.
How does it light the scene at night?
Two systems: the detail channel uses 850 nm IR to 100 m for long reach, while the panorama channel uses a 30 m warm light so the wide view keeps colour detail at night. Light control is automatic or manual, with Smart IR to avoid overexposure.
Which analytics run inside the camera?
Smart intrusion prevention — cross line and intrusion detection with human, non-motor and motor vehicle classification and false alarm filtering — plus people flow counting, crowd density detection, ultra motion detection, tampering and audio detection, and object left behind or removed events.
Does it support audio and alarm wiring?
Yes. Two-way audio uses G.711U/A at 128 Kbps, and the camera provides alarm input and output contacts for sirens or gate sensors. Heatwave reduction and digital defog protect image quality on hot, dusty sites, and the IP66 body handles outdoor mounting.
