PTZ Cameras › IPC6325LFW-AX5C-VG

5MP Active Deterrence Mini PTZ Camera, 5× Auto-Tracking IPC6325LFW-AX5C-VG

5MP Active Deterrence Mini PTZ Camera, 5× Auto-Tracking IPC6325LFW-AX5C-VG — view 1

5MP Active Deterrence Mini PTZ Camera, 5× Auto-Tracking IPC6325LFW-AX5C-VG — view 2

5MP Active Deterrence Mini PTZ Camera, 5× Auto-Tracking IPC6325LFW-AX5C-VG — view 3

Uniview (UNV) · PTZ CameraLightHunter · Active Deterrence

5MP Active Deterrence Mini PTZ · 5× Auto-Tracking

IPC6325LFW-AX5C-VG

Name: IPC6325LFW-AX5C-VG
Brand: Uniview
SKU: IPC6325LFW-AX5C-VG

A compact PTZ that zooms 5× into any corner of the yard and speaks up when something is wrong: built-in mic and speaker back the smart intrusion alarm, while LightHunter low-light imaging keeps color detail after dark.

2880×1620 · main stream @30fpsAuto Tracking · human-only filteringActive Deterrence · built-in mic + speakerIP66 · weatherproof housingPoE · IEEE 802.3at / DC 12V512 GB · MicroSD edge storage

Get Best Price on WhatsApp

Lead time · In stock: at your forwarder’s China warehouse 3 days after payment · Not in stock: 7–15 working days · Then air 5–10 days / sea 25–45 days to your port

Terms · Sample orders welcome · Quotation / PI fixes models, prices, Incoterms (typically FOB Shenzhen), lead time and T/T payment · Defective units: free spare units agreed per order (quantity depends on order size) and written into the quotation · Warranty: up to 5 years on Zhongxin Shutong industrial switches, manufacturer warranty on other brands · Full terms, warranty & RMA

Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your forwarder's warehouse in China after payment · Out-of-stock: 7–15 working days · then air 5–10 days or sea 25–45 days to your port

Sample quantities are welcome — testing one or two units first is the normal way to start.

Compliance:ONVIF Profile SONVIF Profile GONVIF Profile TONVIF Profile M

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

5 MPResolution, 1/2.7" CMOS

5×Optical zoom, 2.7-13.5 mm

50 mSmart IR (+15 m warm light)

120 dBWDR, wide dynamic range

The IPC6325LFW-AX5C-VG is a 5 MP mini PTZ camera with a 5× optical zoom lens (2.7-13.5 mm, F1.2) giving a 106.9° to 30.6° horizontal field of view, built on LightHunter low-light technology (color 0.005 Lux, F1.2, AGC on) and up to 120 dB WDR. Smart intrusion prevention (cross line, intrusion, enter/leave area) classifies human, non-motor vehicle and vehicle with false-alarm filtering, auto tracking follows human targets, and the built-in mic and speaker support two-way audio for on-the-spot active deterrence. Smart IR reaches 50 m plus 15 m of warm light for color night views, and the IP66-rated housing runs from -30 °C to 60 °C.

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

Small business perimeterCross line, intrusion and enter/leave-area detection with human/non-motor/vehicle classification and false-alarm filtering; the built-in speaker plays a voice warning the moment someone crosses the line.

Parking lots & driveways5× optical zoom (2.7-13.5 mm) lets one pole check a plate at the far end of the lot; auto tracking keeps a moving person centered once selected.

Retail entrancesBuilt-in mic and two-way audio let staff talk to a visitor directly from the camera; LightHunter keeps skin tones and signage colors readable at 0.005 Lux.

Warehouse yards & loading docksIP66 housing and -30 °C to 60 °C operation cover open yards in most climates; at 1.32 kg the mini PTZ mounts on a wall bracket or junction box without a heavy pole arm.

Gated communitiesPeople counting and crowd density monitoring track foot traffic at a gate, and auto tracking filters for human targets only — it won't chase every car or pet that passes.

Night watch on dim corridorsICR day/night switching plus Smart IR to 50 m and 15 m of warm light keep a walkway visible after dark, with digital defog and 2D/3D DNR for damp or low-contrast nights.

Not the right pick if you need…

No face recognition or face database on this model — the Intelligent feature set here covers tracking, intrusion detection and people counting only. If face ID matters, pick a model whose datasheet lists a face database.
This is a single-channel zoom PTZ, not a panorama-plus-detail linkage unit — it won't give you a simultaneous full-scene overview and a zoomed-in view. For that, look at our panoramic-linkage PTZ models.
Smart IR reaches 50 m and warm light 15 m — modest ranges for a PTZ. For long, open perimeters beyond 100 m at night, a longer-throw IR or laser PTZ is the better fit.

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

Verified Project PriceDistributor, integrator or end user with a real project? Send the BOQ — project pricing plus free system design. Partner projects are protected: we never quote your end customer behind you

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Key Features

Complete list from the official datasheet.

High quality image with 5 MP, 1/2.8" CMOS sensor

Ultra 265, H.265, H.264, MJPEG

Smart intrusion prevention, supports false alarm filtering, including cross line, intrusion, enter area, leave area detection

LightHunter technology ensures ultra-high image quality in low illumination environment

Up to 120 dB WDR (wide dynamic range)

Built-in mic and speaker

Smart IR, up to 50 m (164.0 ft) IR distance and 15 m (49.2 ft) warm light distance

MicroSD, up to 512 GB

IP66 protection

DC 12 V, PoE (IEEE 802.3at) power supply

Two Things It Does Well: Zoom-In Detail + Active Deterrence

What the 5× zoom and the built-in alarm each bring to the table.

OPTICAL ZOOM

5× optical zoom (2.7-13.5 mm) with human-only auto tracking and DORI Detect distance up to 247.5 m at full telephoto

undefined

ACTIVE DETERRENCE

Smart intrusion prevention with classification and false-alarm filtering, backed by a built-in mic and speaker for on-the-spot two-way audio warnings

undefined

How far can it see? (DORI — Optical Channel)

DORI (EN 62676-4) is the industry standard for what a camera can do at distance. Values shown are for the 5× zoom channel at full telephoto, per the official datasheet.

Detectsomething is there

247.5 m812.0 ft

Observewhat is happening

99 m324.8 ft

Recognizesomeone you know

49.5 m162.4 ft

Identifybeyond doubt

24.8 m81.4 ft

How wide a view at each distance

Scene width covered at typical mounting distances — the number you need to work out how many cameras a wall, yard or aisle takes.

Distance	106.9° wide	30.6° tele
5 m16 ft	13.5 m44.3 ft	2.7 m9.0 ft
10 m33 ft	27.0 m88.5 ft	5.5 m18.0 ft
15 m49 ft	40.5 m133 ft	8.2 m26.9 ft
20 m66 ft	54.0 m177 ft	10.9 m35.9 ft
30 m98 ft	80.9 m266 ft	16.4 m53.9 ft

Calculated from the horizontal field of view in the specifications below: width = 2 × distance × tan(FOV ÷ 2). Lens distortion and mounting angle are not included.

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Camera

Sensor	1/2.7" CMOS
Max Resolution	5 MP
Min. Illumination	Color: 0.005 Lux (F1.2, AGC ON), 0 Lux with IR
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 to 1/100000 s
WDR	120 dB
S/N	> 56 dB

Lens & Field of View

Focal Length	2.7 to 13.5 mm
Optical Zoom	5×
Iris	F1.2
Field of View (H)	106.9° to 30.6°
Field of View (V)	56° to 17.7°
Field of View (D)	131.5° to 36.1°

Illuminator

Light On/Off Control	Auto/Manual
Wavelength	850 nm
Illumination Distance (IR)	50 m (164.0 ft.)
Illumination Distance (Warm Light)	15 m (49.2 ft.)


White Balance	Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2
Digital Noise Reduction	2D/3D DNR
Flip	Normal, Flip vertical, Flip horizontal, 180°
HLC	Support
BLC	Support
Smart IR	Support
Defog	Digital defog

Video

Privacy Mask	Up to 4 areas
Video Compression	Ultra 265, H.265, H.264, MJPEG
Main Stream	5 MP (2880 × 1620), max. 30 fps
Sub Stream	720P (1280 × 720), max. 30 fps
Third Stream	D1 (720 × 576), max. 30 fps
Video Bit Rate	128 Kbps to 16 Mbps
U-code	Support
ROI	Support
Video Stream	Triple streams
OSD	Up to 8 OSDs

Intelligent

Auto Tracking	Support, target filtering: human only
Smart Intrusion Prevention	Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting	Support people flow counting and crowd density monitoring
Exception Detection	Object removed, Object Left Behind, Scene change, Defocus detection

Audio

Audio Compression	G.711U, G.711A
Audio Bitrate	128 Kbps
Two-way Audio	Support
Suppression	Support
Sampling Rate	16 kHz

Storage

Edge Storage	MicroSD, up to 512 GB
Network Storage	ANR, NAS (NFS)

Events

Basic Detection	Motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind, Scene change, Defocus detection
General Function	Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication

PTZ

Number of Presets	1024
Preset Patrol	16 patrols, up to 64 presets for each patrol
Patrol Stay Time	120 s to 1800 s
Home Position	Support
Pan Range	0° to 345°
Tilt Range	-10° to 100°
Pan Speed	1°/s to 50°/s
Tilt Speed	1°/s to 40°/s

Network & Security

Protocols	TLS1.3, SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible Integration	ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK
Security	Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client	EZStation, UNV-Link, UNV-Link Pro
Web Browser	Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
Web Client Language	22 languages

Interface

Audio I/O	1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
Alarm I/O	1/1
Built-in Mic	Support
Built-in Speaker	Support
Network	1 × RJ45 10 M/100 M Base-TX Ethernet

Certification

EMC	CE-EMC (EN 55032: 2015+A11: 2020+A1: 2020, EN 50130-4: 2011+A1: 2014, EN 61000-3-3: 2013+A1: 2019+A2: 2021, EN IEC 61000-3-2: 2019+A1: 2021)
Safety	CE LVD (EN 62368-1: 2020+A11: 2020); UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment	CE-ROHS (2011/65/EU; (EU) 2015/863)
Protection	IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)

General

Power Consumption	18 W
Power Interface	Ø5.5 mm coaxial power plug
Storage Environment	-40 °C to 70 °C (-40 °F to 158 °F), ≤95% RH non-condensing
Surge Protection	2 KV
Reset Button	Support
Heater	Support
Configurable P/N	Support

Dimensions

Engineering drawing reproduced 1:1 from the official datasheet.

unit: mm (in.)

Dimensions	185 mm × 133 mm × 286 mm (7.3" × 5.2" × 11.3") (L × W × H)
Weight	1.32 kg (2.91 lb.)
Power	DC 12 V (±25%), PoE (IEEE 802.3at)
Working Environment	-30 °C to 60 °C (-22 °F to 140 °F), ≤95% RH non-condensing
Protection	IP66

Optional Mounting Accessories

Order together with the camera to save shipping.

TR-JB07-D-INBullet junction box (supports wiring from behind)

TR-CM06-DAlarm ball machine hoisting bracket

TR-A01-INNPT 3/4'' waterproof cable gland

TR-UP06-C-INPole mounting bracket for bullet junction box only

TR-UP06-B-INBullet pole mounting bracket

5MP PTZ Camera FAQ — IPC6325LFW-AX5C-VG

What resolution does the IPC6325LFW-AX5C-VG record at?

The main stream is 5 MP (2880×1620) at up to 30 fps, with a 720p sub stream and a D1 third stream for mobile viewing. Bit rate is adjustable from 128 Kbps to 16 Mbps, and Ultra 265 / H.265 with U-code keeps typical scenes far below the ceiling.

How does it perform after dark?

The F1.2 lens holds color down to 0.005 lux with AGC on. In full darkness, 850 nm IR reaches 50 m (164 ft) with Smart IR exposure control, while a warm light keeps full color within 15 m. 120 dB WDR handles backlit gates and headlights.

Does it track and deter intruders on its own?

Yes. Auto tracking locks onto human targets only and the listing includes an active deterrence alarm. Detection rules cover cross-line, intrusion, enter-area and leave-area with false-alarm filtering, so the camera follows a person crossing your perimeter instead of waiting for someone to watch the feed.

What storage options does it have?

Three: a MicroSD slot for cards up to 512 GB, ANR to backfill the recorder automatically after a network outage, and NAS (NFS) network storage for recording to a shared drive. That combination keeps footage safe even on sites with unstable networks.

Can it count people entering my premises?

Yes. It supports people flow counting and crowd density monitoring, which shops, halls and depots use for both security and operations. Exception detection also flags object removed, object left behind, scene change and defocus, and two-way audio lets an operator speak through the camera.
