PTZ Cameras › IPC6622SR-X33-VD2

2MP 33× Optical Zoom Lighthunter IR PTZ Dome Camera IPC6622SR-X33-VD2

2MP 33× Optical Zoom Lighthunter IR PTZ Dome Camera IPC6622SR-X33-VD2 — view 1

2MP 33× Optical Zoom Lighthunter IR PTZ Dome Camera IPC6622SR-X33-VD2 — view 2

2MP 33× Optical Zoom Lighthunter IR PTZ Dome Camera IPC6622SR-X33-VD2 — view 3

Uniview (UNV) · PTZ CameraLightHunter · Intelligent PTZ

2MP 33× Lighthunter IR Intelligent PTZ Camera

IPC6622SR-X33-VD2

Name: IPC6622SR-X33-VD2
Brand: Uniview
SKU: IPC6622SR-X33-VD2

A 2MP PTZ dome camera with 33× optical zoom that finds a target anywhere in range and locks on: UNV's AI Large Model tracks motor vehicles, non-motor vehicles and pedestrians through occlusion and fast motion, with 200 m smart IR carrying the view into full darkness.

1920×1080 · main stream @60fps33× · optical zoom, 4.5–148.5 mmUNV Large Model · AI auto-tracking200 m · smart IR illuminationIP67 · IK10 · vandal-proof housing-40~70°C · wide operating range

Get Best Price on WhatsApp

Lead time · In stock: at your forwarder’s China warehouse 3 days after payment · Not in stock: 7–15 working days · Then air 5–10 days / sea 25–45 days to your port

Terms · Sample orders welcome · Quotation / PI fixes models, prices, Incoterms (typically FOB Shenzhen), lead time and T/T payment · Defective units: free spare units agreed per order (quantity depends on order size) and written into the quotation · Warranty: up to 5 years on Zhongxin Shutong industrial switches, manufacturer warranty on other brands · Full terms, warranty & RMA

Need the PDF datasheet? Get it on WhatsApp →

In-stock models: 3 days to your forwarder's warehouse in China after payment · Out-of-stock: 7–15 working days · then air 5–10 days or sea 25–45 days to your port

Sample quantities are welcome — testing one or two units first is the normal way to start.

Compliance:ONVIF Profile SONVIF Profile GONVIF Profile TONVIF Profile M

Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.

2 MPResolution, main stream

33×Optical zoom, 4.5–148.5 mm

200 mSmart IR illumination distance

288°/sMax pan / tilt speed

The IPC6622SR-X33-VD2 is a 2MP PTZ dome camera built around a 1/2.8" CMOS sensor with 33× optical zoom (4.5-148.5 mm) plus 8× digital zoom, 120 dB true WDR and ColorHunter low-light imaging with Wise-ISP. UNV LM-Auto Tracking (UNV Large Model) identifies and continuously tracks motor vehicles, non-motor vehicles and pedestrians through occlusion, multi-target crossing or high-speed motion, backed by smart intrusion prevention (cross line / enter area / leave area / intrusion) with classification-based false-alarm filtering, and people-flow counting with crowd-density monitoring. A 200 m smart-IR illuminator, heatwave reduction, adaptive defog and adaptive highlight compensation keep images usable day and night, inside an IP67 / IK10 housing rated -40 °C to 70 °C.

Is this the right camera for you?

Plain-language guide for buyers and installers — based only on what this camera actually does.

Perimeter with vehicle/pedestrian classificationCross line, enter-area, leave-area and intrusion detection classify motor vehicles, non-motor vehicles and pedestrians before raising an alarm, filtering out the false alarms that plain motion detection can't.

Long approach roads with auto-trackingUNV LM-Auto Tracking locks onto a vehicle or person and keeps following it with adaptive bounding boxes, even through occlusion, multi-target crossing or high-speed motion — useful on a long straight road a fixed camera can't cover alone.

Parking lots & entrances33× optical zoom (4.5-148.5 mm) reads a plate or a face across a large lot without a second camera, while people-flow counting and crowd-density monitoring track occupancy.

City streets, high-contrast light120 dB true WDR and adaptive highlight compensation tame headlights and shopfront glare at night, while adaptive defog and heatwave reduction keep the image clear in haze or summer heat shimmer.

Industrial yards & rail sidingsIP67 sealing, IK10 vandal resistance and -40 °C to 70 °C operation with 6 kV surge protection suit an unattended outdoor pole; 1024 presets and 16 route/pattern patrols cover a wide perimeter on a fixed schedule.

Night patrol, long rangeColorHunter low-light imaging with Wise-ISP keeps detail visible after dusk; once it's fully dark, 200 m smart IR takes over automatically and adjusts to the scene rather than blowing out nearby objects.

Not the right pick if you need…

No panoramic / wide-angle overview — this is a single 33× tele-zoom PTZ (4.5-148.5 mm), not a fixed wide-angle camera; pair it with a fixed camera if you also need a permanent wide shot.
No built-in microphone or speaker in this datasheet — the audio I/O (1 input, 1 output) needs an external mic, speaker or amplifier wired in for two-way audio or an audio alarm.
No face recognition or face database in this datasheet — auto tracking classifies motor vehicles, non-motor vehicles and pedestrians but does not identify individual faces; choose a face-recognition PTZ if that's a requirement.
Weight is not published in this datasheet — check the Ø227 × 390 mm housing against your pole/bracket load rating before ordering mounting accessories.

Worried about counterfeits? Order under your own company name.

For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.

1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site

Using your own freight forwarder? No problem.

For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.

EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order

Note: manufacturer order registration (left) is available via the corporate purchase channel.

How to get a better price

Volume Discount50+ units of a single model

Mix & Match DiscountMix any categories & models storewide in one order — no quantity limit

BETTER

Verified Project PriceDistributor, integrator or end user with a real project? Send the BOQ — project pricing plus free system design. Partner projects are protected: we never quote your end customer behind you

BEST

All discounts are quoted personally — message me on WhatsApp ↑

Key Features

Complete list from the official datasheet.

Wise-ISP image processing engine with intelligent noise reduction for clear low-light imaging

Smart intrusion prevention (SIP): cross line, enter area, leave area and intrusion detection; detects and captures motor vehicles, non-motor vehicles and pedestrians and raises alarms

UNV LM-Auto Tracking: accurately identifies and continuously tracks motor vehicles, non-motor vehicles and pedestrians — even through occlusion, multi-target crossing or high-speed motion — with real-time adaptive bounding boxes

People counting: people-flow counting and crowd-density monitoring for various scenarios

Automatic selection of best snapshots; supports face detection masked area

120 dB true WDR meets the image requirements in high-contrast scenes

Heatwave reduction effectively mitigates the heatwave effect in high-temperature outdoor environments

Adaptive defog automatically adjusts the defog level according to fog and haze intensity

200 m smart-IR illumination distance, automatically adjusts image settings for natural, realistic night-time images

Adaptive highlight compensation (HLC) automatically adjusts image brightness at night when moving vehicles are detected on the road

Advanced H.265 and SVC video compression technologies for higher compression efficiency and flexible application

ROI (region of interest) preserves image quality in areas of interest at low bandwidth

Picture overlay and custom OSD with various custom effects (size, color, background, style)

Two Standout Capabilities: AI Tracking + Smart IR

Both work automatically once enabled, from the official datasheet.

AI AUTO-TRACKING

UNV Large Model locks onto vehicles, two-wheelers and pedestrians

Continues tracking through occlusion, multi-target crossing or high-speed motion with real-time adaptive bounding boxes.

SMART IR 200 M

200 m smart infrared adapts automatically to the scene

Automatically adjusts image settings for natural, realistic night images, paired with adaptive HLC for oncoming headlights.

How far can it see? (DORI Standard)

DORI (EN 62676-4) is the industry standard for what a camera can do at distance. Values shown are at full 33× optical zoom (148.5 mm); the datasheet also lists 72.9-218.8 m at the 4.5 mm wide end.

Detectsomething is there

2187.9 m7178.3 ft

Observewhat is happening

875.2 m2871.3 ft

Recognizesomeone you know

437.6 m1435.7 ft

Identifybeyond doubt

218.8 m717.8 ft

How wide a view at each distance

Scene width covered at typical mounting distances — the number you need to work out how many cameras a wall, yard or aisle takes.

Distance	58.9° wide	2.9° tele
5 m16 ft	5.7 m18.5 ft	0.2 m0.8 ft
10 m33 ft	11.3 m37.1 ft	0.5 m1.6 ft
15 m49 ft	17.0 m55.6 ft	0.7 m2.4 ft
20 m66 ft	22.6 m74.2 ft	1.0 m3.3 ft
30 m98 ft	33.9 m111 ft	1.5 m4.9 ft

Calculated from the horizontal field of view in the specifications below: width = 2 × distance × tan(FOV ÷ 2). Lens distortion and mounting angle are not included.

Full Specifications

Complete official specifications from the manufacturer's datasheet (technical values in English).

Camera

Max Resolution	2 MP
Sensor	1/2.8" CMOS
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 to 1/100000 s
WDR	120 dB
Min. Illumination	Color: 0.001 Lux (F1.5, AGC ON), 0 Lux with Light

Lens & Field of View

Focal Length	4.5 to 148.5 mm
Optical Zoom	33X
Digital Zoom	8X
Iris	F1.5 to F4.0
Field of View (H)	58.94° to 2.85°
Field of View (V)	33.18° to 1.60°
Field of View (D)	72.50° to 3.36°

Illuminator

IR On/Off Control	Auto/Manual
Illumination Distance (IR)	200 m (656.2 ft.)


BLC	Support
Digital Noise Reduction	2D/3D DNR
Flip	Normal, Flip vertical, Flip horizontal, 180°
HLC	Support
Defog	Digital defog
[object Object]	ColorHunter with Wise-ISP
Heatwave Reduction	Support
Image Stabilization	DIS

Video

Video Compression	H.265, H.264, MJPEG, Ultra 265
[object Object]	Main Stream Max: 1080P (1920×1080), 60 fps; Main Stream Default: 1080P, 25 fps; Sub Stream Max: 1080P, 60 fps; Third Stream Max: D1 (720×576), 60 fps; Fourth Stream Max: D1, 60 fps; Fifth Stream Max: D1, 60 fps
Video Bit Rate	128 Kbps to 16 Mbps
U-code	Support
Privacy Mask	24 areas, up to 8 areas per scene
[object Object]	Support
ROI	Up to 8 areas
Video Stream	Five streams
OSD	Up to 10 OSDs
[object Object]	1080P@60fps + 1080P@60fps + D1@60fps + D1@60fps + D1@60fps

Audio

Audio I/O	1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
Two-way Audio	Support
Audio Compression	G.711U, G.711A
Suppression	Support
Sampling Rate	8 kHz, 16 kHz

Intelligent

[object Object]	UNV Large Model
Smart Intrusion Prevention	Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)
People Counting	Support people flow counting and crowd density detection
Exception Detection	Object removed, Object Left Behind

PTZ

Pan Range	360° (endless)
Pan Speed	0.1°/s to 288°/s
Tilt Range	-15° to 90° (auto flip)
Tilt Speed	0.1°/s to 288°/s
Number of Presets	1024
Route Patrol	16 patrols, up to 32 actions for each patrol
Patrol Stay Time	15 s to 1800 s
Preset Image Freeze	Support
Home Position	Support

Events

General Function

Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output, HTTP authentication

Network & Security

User/Host	Up to 32 users. 3 user levels: administrator, common user and operator
Protocols	SSH, IGMP, RTP, RTMP, RTCP, IPv4, SSL/TLS, QoS, 802.1x, HTTPS, HTTP, UPnP, NTP, DDNS, DNS, RTSP, DHCP, UDP, TCP, ARP, ICMP, IPv6, SMTP, PPPoE, SNMP
Compatible Integration	ONVIF (Profile S, Profile G, Profile T, Profile M), SDK, API
Security	Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF, TLS 1.3
Client	EZStation, UNV-Link, UNV-Link Pro
Web Browser	Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+; Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+
Edge Storage	MicroSD, up to 512 GB
Network Storage	NAS (NFS)
Web Client Language	22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak
[object Object]	Support

Interface

Network	1 × RJ45 10 M/100 M Base-TX Ethernet
Alarm I/O	2/1
Serial Port	1 × RS485
[object Object]	Wires with cold-pressed terminal

Certification

Safety	UL (UL 62368-1); CUL (CAN/CSA C22.2 No. 62368-1); CE-LVD (EN IEC 62368-1)
EMC	CE-EMC (EN 55032; EN IEC 61000-3-2; EN 61000-3-3; EN 50130); FCC SDoC (47 CFR Part 15; Subpart B)
Protection	IP67 (IEC 60529); IK10 (IEC 62262; Anti-Vandalism Except for the Front Window)
[object Object]	NDAA Compliant: Support

General

[object Object]	-40 °C to 70 °C (-40 °F to 158 °F), ≤95% RH non-condensing
[object Object]	Support

Dimensions

Engineering drawing reproduced 1:1 from the official datasheet.

unit: mm (in.)

Dimensions	Ø227 mm × 390 mm (Ø8.9" × 15.4") (Ø × H)
Power	DC 24 V±25%, AC 24 V±25%, PoE (IEEE 802.3at)
Working Environment	-40 °C to 70 °C (-40 °F to 158 °F), ≤95% RH non-condensing
Protection	IP67 (IEC 60529) · IK10 (IEC 62262, except front window) · 6 kV surge

Optional Mounting Accessories

Order together with the camera to save shipping.

TR-UF45-A-INDome indoor ceiling mounting pedestal

TR-SE45-A-INDome ceiling mounting pole 500

TR-SE45-INDome ceiling mounting pole 200

TR-CE45-INDome indoor ceiling mounting bracket

TR-WE45-INDome wall mounting bracket

TR-WE45-A-INLong wall mounting bracket for dome

TR-JB12-INDome junction box

TR-WE45-B-INDome gooseneck bracket

TR-UP08-A-INDome pole mounting bracket

TR-UP08-B-INAluminium alloy pole mounting bracket

TR-UC08-A-INDome corner mounting bracket

TR-UC08-B-INAluminium alloy corner mounting bracket

2MP 33x Auto Tracking PTZ FAQ — IPC6622SR-X33-VD2

What targets can the IPC6622SR-X33-VD2 track automatically?

The UNV Large Model locks onto vehicles, two-wheelers and pedestrians, and keeps tracking through occlusion, multi-target crossing and high-speed motion with real-time adaptive bounding boxes. That means one operator-free PTZ can follow a motorbike weaving through traffic or a person cutting across a yard at night.

How does it handle headlights and total darkness at night?

Smart infrared reaches 200 m and adjusts image settings automatically for natural night images, while adaptive HLC suppresses oncoming headlights so plates and drivers are not lost in glare. In low ambient light, ColorHunter with Wise-ISP holds full color down to 0.001 lux (F1.5, AGC on).

What area can one camera cover with the 33x zoom and PTZ?

Pan is 360° endless at 0.1–288°/s and tilt runs -15° to 90° with auto flip, so the camera sweeps a full circle around its pole. The 4.5–148.5 mm lens goes from a 58.94° wide view of the whole scene down to a 2.85° telescope on a distant gate or fence corner.

Is it tough enough for outdoor city installations?

The camera carries IP67 dust/water protection and an IK10 vandal-resistant rating, and operates from -40 to 70 °C — suitable for exposed poles in tropical rain, harmattan dust or desert heat. Digital defog, heatwave reduction and DIS stabilization keep the long-zoom image steady in wind and haze.

What video streams does it deliver for recording and live view?

Five simultaneous streams: main stream up to 1080p at 60 fps (25 fps default), with a recommended split of 1080p@60 + 1080p@60 + three D1@60 for recorder, video wall and mobile clients. Bit rate is adjustable from 128 Kbps to 16 Mbps in Ultra 265, H.265, H.264 or MJPEG.

Does it support audio for talk-down to intruders?

Yes. Two-way audio is supported with one audio input (1 kΩ impedance, 2.5 V p-p) and one output (600 Ω, 2.5 V p-p), plus G.711U/G.711A compression at 8 or 16 kHz sampling. Connect a microphone and an amplified speaker and the control room can challenge intruders in real time.
