PTZ Cameras › IPC6624SR-X33-VF
Uniview (UNV) · PTZ CameraLightHunter Series
4MP 33X LightHunter Network PTZ Dome Camera
IPC6624SR-X33-VF
A 33× optical zoom PTZ dome built for LightHunter low-light imaging: WDR 120 dB and Smart IR reach 150 m after dark, while auto tracking with human/vehicle classification keeps moving targets in frame.
2688×1520 · main stream @30fps33× / 16× · optical / digital zoomAuto-Track · human/vehicle classificationWDR 120 dB · LightHunter low-lightIP66 · outdoor housing-40~70°C · with heater support
Get Best Price on WhatsApp
Lead time · In stock: at your forwarder’s China warehouse 3 days after payment · Not in stock: 7–15 working days · Then air 5–10 days / sea 25–45 days to your port
Terms · Sample orders welcome · Quotation / PI fixes models, prices, Incoterms (typically FOB Shenzhen), lead time and T/T payment · Defective units: free spare units agreed per order (quantity depends on order size) and written into the quotation · Warranty: up to 5 years on Zhongxin Shutong industrial switches, manufacturer warranty on other brands · Full terms, warranty & RMA
Need the PDF datasheet? Get it on WhatsApp →In-stock models: 3 days to your forwarder's warehouse in China after payment · Out-of-stock: 7–15 working days · then air 5–10 days or sea 25–45 days to your port
Sample quantities are welcome — testing one or two units first is the normal way to start.
Compliance:ONVIF Profile SONVIF Profile GONVIF Profile T
Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.
The IPC6624SR-X33-VF is a 4MP network PTZ dome camera built around a 1/2.8-inch CMOS sensor and a 4.5-148.5 mm motorized lens with 33× optical zoom plus 16× digital zoom, delivering a 2688×1520 main stream at up to 30 fps. LightHunter low-light processing holds color down to 0.003 Lux with WDR 120 dB, and Smart IR extends visibility to 150 m at night. Onboard intelligence covers auto tracking with human/vehicle/non-motor-vehicle classification, smart intrusion prevention (cross line, intrusion, enter/leave area) with false-alarm filtering, and people counting with crowd-density monitoring, housed in an IP66-rated shell rated -40 °C to 70 °C and powered by AC 24 V, DC 24 V or PoE+.
Is this the right camera for you?
Plain-language guide for buyers and installers — based only on what this camera actually does.
Perimeter & long-approach roads33× optical zoom pulls a distant gate or fence line in close for a clear look, while smart intrusion prevention (cross line, intrusion, enter/leave area) filters out blowing leaves and small animals with human/vehicle classification.
Parking lots & vehicle yardsAuto tracking follows a moving vehicle across the lot with vehicle/non-motor/human classification, and people counting with crowd-density monitoring helps manage entry flow at busy hours.
Night surveillance on a budget poleLightHunter imaging keeps color down to 0.003 Lux and Smart IR reaches 150 m once it's fully dark — enough for many perimeter and yard jobs without the weight or cost of a heavy-duty dual-channel unit.
Warehouses & logistics yards1024 presets and 16 patrols (up to 64 presets each) let one dome cycle through loading bays, gates and aisles on a schedule, with object-removed and object-left-behind detection watching stored goods.
Mixed-traffic street cornersAdaptive glare suppression tames headlights at night, heat-haze reduction keeps summer asphalt from smearing the telephoto image, and digital defog helps on misty mornings.
Harsh outdoor mountsIP66 sealing, -40 °C to 70 °C operation, 6 kV surge protection and heater support are built for exposed poles in extreme heat or cold, without the added weight of a vandal-rated IK10 shell.
Not the right pick if you need…
- No built-in microphone or speaker (Built-in Mic: N/A, Built-in Speaker: N/A) — only 1 audio input / 1 audio output are provided, so plan an external audio kit if you need onboard voice alarms.
- No Wi-Fi (WIFI: N/A) — this is a wired network camera only; plan Ethernet cabling to the pole before ordering.
- Network port is 10M/100M Fast Ethernet, not Gigabit — if you are streaming many high-bitrate channels through the same switch port budget, confirm bandwidth against your other cameras.
- 5.28 kg dome: it needs the dedicated ceiling/wall/pole brackets listed below, not a light indoor camera arm.
Worried about counterfeits? Order under your own company name.
For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.
1 · Company name2 · Corporate bank payment3 · Order registered in your name4 · Verify SN on Uniview's site
Using your own freight forwarder? No problem.
For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.
EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order
Note: manufacturer order registration (left) is available via the corporate purchase channel.
How to get a better price
Volume Discount50+ units of a single model
CONTACT USMix & Match DiscountMix any categories & models storewide in one order — no quantity limit
BETTERVerified Project PriceDistributor, integrator or end user with a real project? Send the BOQ — project pricing plus free system design. Partner projects are protected: we never quote your end customer behind you
BESTAll discounts are quoted personally — message me on WhatsApp ↑
Key Features
Complete list from the official datasheet.
4 MP 1/2.8-inch CMOS sensor; main stream 2688×1520 @30fps; Ultra 265, H.265, H.264, MJPEG compression
33× optical zoom (4.5-148.5 mm) plus 16× digital zoom; auto/manual iris F1.5 to F4.0
LightHunter low-light imaging: color 0.003 Lux (F1.5, AGC ON), 0 Lux with IR; WDR 120 dB
Smart intrusion prevention: cross line, intrusion, enter/leave area detection with false-alarm filtering and human/non-motor/vehicle classification
Auto tracking with target filtering: human, non-motor vehicle, vehicle
People counting: flow statistics and crowd-density monitoring for different scenarios
Smart IR up to 150 m (850 nm); heater support and digital defog for harsh weather
AC 24 V / DC 24 V / PoE+ (802.3at) power, max. 25 W; IP66 housing rated -40 °C to 70 °C; 6 kV surge protection
How far can it see? (DORI — Optical Channel)
DORI (EN 62676-4) is the industry standard for what a camera can do at distance. Bars below show distances at full 33× telephoto (148.5 mm); at the 4.5 mm wide end the same four distances scale down to roughly 105.8 / 42.3 / 21.2 / 10.6 m.
Detectsomething is there
3172.5 m10408.5 ft
Observewhat is happening
1269 m4163.4 ft
Recognizesomeone you know
634.5 m2081.7 ft
Identifybeyond doubt
317.3 m1041.0 ft
How wide a view at each distance
Scene width covered at typical mounting distances — the number you need to work out how many cameras a wall, yard or aisle takes.
| Distance | 51.4° wide | 2.5° tele |
|---|---|---|
| 5 m16 ft | 4.8 m15.8 ft | 0.2 m0.7 ft |
| 10 m33 ft | 9.6 m31.6 ft | 0.4 m1.4 ft |
| 15 m49 ft | 14.4 m47.4 ft | 0.7 m2.1 ft |
| 20 m66 ft | 19.3 m63.2 ft | 0.9 m2.9 ft |
| 30 m98 ft | 28.9 m94.7 ft | 1.3 m4.3 ft |
Calculated from the horizontal field of view in the specifications below: width = 2 × distance × tan(FOV ÷ 2). Lens distortion and mounting angle are not included.
Full Specifications
Complete official specifications from the manufacturer's datasheet (technical values in English).
Camera
| Sensor | 1/2.8" CMOS |
| Min. Illumination | Color: 0.003 Lux (F1.5, AGC ON), 0 Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, 1 to 1/100000 s |
| WDR | 120 dB |
| S/N | > 56 dB |
Lens & Field of View
| Focal Length | 4.5 to 148.5 mm |
| Optical Zoom | 33X |
| Digital Zoom | 16X |
| Iris | F1.5 to F4.0 |
| Field of View (H) | 51.4° to 2.5° |
| Field of View (V) | 30.3° to 1.4° |
| Field of View (D) | 63.2° to 3.0° |
DORI
| DORI Distance (Lens) | 4.5 to 148.5 mm |
| DORI Distance (Detect) | 105.8 m to 3172.5 m (346.9 ft. to 10408.5 ft.) |
| DORI Distance (Observe) | 42.3 m to 1269.0 m (138.8 ft. to 4163.4 ft.) |
| DORI Distance (Recognize) | 21.2 m to 634.5 m (69.4 ft. to 2081.7 ft.) |
| DORI Distance (Identify) | 10.6 m to 317.3 m (34.8 ft. to 1041.0 ft.) |
Video
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Frame Rate | Main Stream: 4 MP (2688 × 1520), max. 30 fps · Sub Stream: 1080P (1920 × 1080), max. 30 fps · Third Stream: D1 (720 × 576), max. 30 fps |
| Video Bit Rate | 128 Kbps to 16 Mbps |
| U-code | Support |
| ROI | Support |
| Video Stream | Triple streams |
| Privacy Mask | 24 areas, up to 4 areas per scene |
| OSD | Up to 10 OSDs |
Events
| Basic Detection | Motion detection, tampering alarm, audio detection, object removed, object left behind |
| General Function | Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, alarm input, alarm output |
Audio
| Audio Compression | G.711U, G.711A |
| Audio Bitrate | 128 Kbps |
| Two-way Audio | Support |
| Suppression | Support |
| Sampling Rate | 16 kHz |
Storage
| Edge Storage | MicroSD, up to 512 GB |
| Network Storage | ANR, NAS (NFS) |
Network
| User/Host | Up to 32 users. 3 user levels: administrator, common user and operator |
| Protocols | SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK |
| Security | TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF |
| Client | EZStation, UNV-Link, UNV-Link Pro |
| Web Browser | Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+ |
Intelligent
| Exception Detection | Object removed, Object Left Behind |
| Auto Tracking | Support, target filtering: human, non-motor vehicle and vehicle |
| Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) |
| People Counting | Support people flow counting and crowd density monitoring |
PTZ
| Route Patrol | 16 patrols, up to 32 actions for each patrol |
| Recorded Patrol | 16 patrols, up to 128 actions for each patrol |
| Number of Presets | 1024 |
| Preset Image Freeze | Support |
| Preset Patrol | 16 patrols, up to 64 presets for each patrol |
| Patrol Stay Time | 15 s to 1800 s |
| Home Position | Support |
| Pan Range | 360° (endless) |
| Pan Speed | 0.1°/s to 200°/s |
| Tilt Range | -15° to 90° (auto reverse) |
| Tilt Speed | 0.1°/s to 200°/s |
| White Balance | Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2 |
| Digital Noise Reduction | 2D/3D DNR |
| Flip | Normal, Flip vertical, Flip horizontal, 180° |
| HLC | Support |
| BLC | Support |
| Smart IR | Support |
| Defog | Digital defog |
| Heatwave Reduction | Support |
Interface
| Audio I/O | 1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p] |
| WIFI | N/A |
| Alarm I/O | 2/1 |
| Serial Port | 1 × RS485 |
| Built-in Mic | N/A |
| Built-in Speaker | N/A |
| Network | 1 × RJ45 10 M/100 M Base-TX Ethernet |
| Video Output | 1 BNC (for debugging) |
Illuminator
| Illumination Distance (IR) | 150 m (492.1 ft.) |
| IR On/Off Control | Auto/Manual |
| Wavelength | 850 nm |
Certification
| EMC | CE-EMC (EN 55032:2015+A11:2020; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55035:2017+A11:2020), FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) |
| Safety | CE LVD (EN 62368-1:2014+A11:2017), UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) |
| Protection | IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013) |
General
| Power | AC 24 V±25%, DC 24 V±25%, PoE+ (IEEE 802.3 at) |
| Power Consumption | Max. 25 W |
| Power Interface | Wires with cold-pressed terminal |
| Dimensions | Ø227 mm × 384.8 mm (Ø 8.9" × 15.1") (Ø × H) |
| Weight | 5.28 kg (11.64 lb.) |
| Working Environment | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Storage Environment | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Surge Protection | 6 KV |
| Reset Button | Support |
| Web Client Language | 22 languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak |
| Heater | Support |
Dimensions
Engineering drawing reproduced 1:1 from the official datasheet.
unit: mm (in.)
| Dimensions | Ø227 mm × 384.8 mm (Ø8.9" × 15.1") (Ø×H) |
| Weight | 5.28 kg (11.64 lb.) |
| Power | AC 24 V±25%, DC 24 V±25%, PoE+ (IEEE 802.3at) · max. 25 W |
| Working Environment | -40 °C to 70 °C (-40 °F to 158 °F), ≤95% RH non-condensing |
| Protection | IP66 · 6 kV surge |
Optional Mounting Accessories
Order together with the camera to save shipping.
TR-UF45-A-INDome indoor ceiling mounting pedestal
TR-SE45-A-INDome ceiling mounting pole 500
TR-SE45-INDome ceiling mounting pole 200
TR-CE45-INDome indoor ceiling mounting bracket
TR-WE45-INDome wall mounting bracket
TR-WE45-A-INLong wall mounting bracket for dome
TR-JB12-INDome junction box
TR-WE45-B-INDome gooseneck bracket
TR-UP08-A-INDome pole mounting bracket
TR-UP08-B-INAluminium alloy pole mounting bracket
TR-UC08-A-INDome corner mounting bracket
TR-UC08-B-INAluminium alloy corner mounting bracket
4MP 33x Auto Tracking PTZ FAQ — IPC6624SR-X33-VF
How far can the IPC6624SR-X33-VF monitor with 33x zoom?
The 4.5–148.5 mm lens with 33x optical and 16x digital zoom yields DORI distances of 3172.5 m for detection, 1269.0 m for observation, 634.5 m for recognition and 317.3 m for identification at full telephoto — one pole can oversee a port yard, mine boundary or long farm fence.
Which targets can the auto tracking follow?
Auto tracking supports target filtering for humans, non-motor vehicles and vehicles, so the PTZ follows what matters and ignores stray animals or foliage. It works with smart intrusion prevention — cross-line, intrusion, enter and leave area with false-alarm filtering — plus people flow counting and crowd density monitoring.
What night vision range does it have?
Smart IR reaches 150 m, and the LightHunter sensor holds color down to 0.003 lux (F1.5, AGC on), switching to 0 lux with IR in full darkness. 120 dB WDR and digital defog handle high-contrast entrances and hazy conditions along the zoom range.
Can I integrate it with a non-Uniview NVR or VMS?
Yes. ONVIF Profile S, G, T and M plus RTSP make it compatible with third-party recorders and management platforms, and the API/SDK covers project-specific integration. TLS 1.3, HTTPS encryption and digest authentication protect the link, and EZStation or UNV-Link remain available on the Uniview side.
What happens to footage during network outages?
Edge storage on a microSD card up to 512 GB plus ANR means the camera records locally through an outage and automatically backfills the recorder afterwards — no gaps in evidence after power cuts or fiber breaks. NAS (NFS) network storage is also supported.
Is it suitable for hot and cold outdoor climates?
Yes — the IP66-rated housing works from -40 to 70 °C, covering desert sites, tropical coasts and cold highlands with the same unit. The main stream records 4 MP (2688 × 1520) at up to 30 fps over three streams, with bit rate control from 128 Kbps to 16 Mbps for constrained uplinks.
