IPC6824ER-X42-W-VH2
42× optical zoom reaches out to a 4310 m DORI detect distance while Wise-ISP low-light processing, auto-tracking and a wiper keep the image clear and stable in the harshest weather.
Lead time · In stock: at your forwarder’s China warehouse 3 days after payment · Not in stock: 7–15 working days · Then air 5–10 days / sea 25–45 days to your port
Terms · Sample orders welcome · Quotation / PI fixes models, prices, Incoterms (typically FOB Shenzhen), lead time and T/T payment · Defective units: free spare units agreed per order (quantity depends on order size) and written into the quotation · Warranty: up to 5 years on Zhongxin Shutong industrial switches, manufacturer warranty on other brands · Full terms, warranty & RMA
Need the PDF datasheet? Get it on WhatsApp →Sample quantities are welcome — testing one or two units first is the normal way to start.
The IPC6824ER-X42-W-VH2 is a 4MP 42× optical-zoom Wise-ISP IR wiper network PTZ dome camera built around a 1/1.8-inch CMOS sensor with 150 dB WDR and a DORI detect distance up to 4310.3 m. Auto tracking with human / vehicle / non-motor classification, smart intrusion prevention (cross line, intrusion, enter/leave area) with false-alarm filtering, people counting with crowd density detection, and face recognition with up to 16 libraries and 100,000 faces run on the same channel. Gyroscopic image stabilization keeps the long zoom steady, a wiper clears the front window in rain, and the IP67 / IK10 housing runs from -40 °C to 70 °C with a built-in heater.
Is this the right camera for you?
Plain-language guide for buyers and installers — based only on what this camera actually does.
- Multi-target detection is not supported (N/A per datasheet) — if you need to track several independent targets at once, choose a model with that capability.
- This is a single-channel PTZ — one view at a time. If you need simultaneous 360° overview plus zoomed detail from one unit, choose a panoramic-linkage PTZ instead.
- Network interface is 10M/100M only (not Gigabit) — plan bandwidth accordingly for multi-stream, high-bitrate deployments.
- 6.9 kg and PTZ mechanics need a dedicated pole/wall/ceiling bracket rated for the weight and wind load — not a light fixed-camera arm.
Worried about counterfeits? Order under your own company name.
For corporate buyers: we support submitting the purchase order to Uniview under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer. Models carrying the anti-counterfeit label can also be self-verified on Uniview's official Anti-Counterfeiting Query page — enter the unit's SN plus the scratch-off code.
Using your own freight forwarder? No problem.
For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.
Key Features
Complete list from the official datasheet.
Two Core Intelligent Functions
Run together on the same channel, from the official datasheet.
Locks onto and follows people, vehicles and non-motor targets automatically, with classification filtering
undefined
Cross line, intrusion, enter/leave area detection with false-alarm filtering and human/vehicle/non-motor classification
undefined
How far can it see? (DORI — Optical Channel)
DORI (EN 62676-4) is the industry standard for what a camera can do at distance — the values below show the full optical zoom range from wide to full telephoto.
How wide a view at each distance
Scene width covered at typical mounting distances — the number you need to work out how many cameras a wall, yard or aisle takes.
| Distance | 59.5° | 2.2° |
|---|---|---|
| 5 m16 ft | 5.7 m18.7 ft | 0.2 m0.6 ft |
| 10 m33 ft | 11.4 m37.5 ft | 0.4 m1.3 ft |
| 15 m49 ft | 17.1 m56.2 ft | 0.6 m1.9 ft |
| 20 m66 ft | 22.8 m75.0 ft | 0.8 m2.5 ft |
| 30 m98 ft | 34.3 m112 ft | 1.2 m3.8 ft |
Calculated from the horizontal field of view in the specifications below: width = 2 × distance × tan(FOV ÷ 2). Lens distortion and mounting angle are not included.
Full Specifications
Complete official specifications from the manufacturer's datasheet (technical values in English).
Camera
| Sensor | 1/1.8" CMOS |
| Min. Illumination | Color: 0.0003 Lux (F1.2, AGC ON), 0 Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, 1 to 1/100000 s |
| WDR | 150 dB |
| S/N | > 56 dB |
Lens & Field of View
| Focal Length | 6 to 252 mm |
| Optical Zoom | 42X |
| Digital Zoom | 8X |
| Iris | F1.2 to F4.6 |
| Field of View (H) | 59.47° (W) to 2.20° (T) |
| Field of View (V) | 35.62° (W) to 1.24° (T) |
| Field of View (D) | 73.14° (W) to 2.59° (T) |
Illuminator
| Wavelength | 850 nm |
| IR On/Off Control | Auto/Manual |
| Illumination Distance (IR) | 500 m (1640.4 ft.) |
Video
| Video Compression | H.265, H.264, MJPEG, Ultra 265 |
| Main Stream | 4 MP (2688 × 1520), max. 60 fps |
| Sub Stream | 1080P (1920 × 1080), max. 60 fps |
| Third Stream | D1 (720 × 576), max. 60 fps |
| Video Bit Rate | 128 Kbps to 16 Mbps |
| U-code | Support |
| ROI | Up to 8 areas |
| Video Stream | Triple streams |
| Privacy Mask | 24 areas, up to 8 areas per scene |
| OSD | Up to 10 OSDs |
Events
| Basic Detection | Motion detection, Ultra motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind |
| General Function | Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output |
Audio
| Audio Bitrate | 128 Kbps |
| Two-way Audio | Support |
| Suppression | Support |
| Audio Compression | G.711U, G.711A |
| Sampling Rate | 8 kHz, 16 kHz |
Storage
| Edge Storage | MicroSD, up to 512 GB |
| Network Storage | ANR, NAS (NFS) |
Network & Security
| User/Host | Up to 32 users. 3 user levels: administrator, common user and operator |
| Protocols | SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS, FTP |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T, Profile M), SDK, API |
| Security | Strong Password, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, TLS 1.3, WSSE and Digest Authentication for ONVIF, Password protection, HTTPS encryption, Export operation logs |
| Client | EZStation, UNV-Link, UNV-Link Pro |
| Web Browser | Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+ |
Intelligent
| Auto Tracking | Support, target filtering: human, non-motor vehicle and vehicle |
| People Counting | Support people flow counting and crowd density detection |
| Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) |
| Recognition | Face Recognition: Max support 16 face libraries, Max supports 100000 faces in face library |
PTZ
| Route Patrol | 16 patrols, up to 32 actions for each patrol |
| Recorded Patrol | 16 patrols, up to 128 actions for each patrol |
| Preset Image Freeze | Support |
| Preset Patrol | 16 patrols, up to 64 presets for each patrol |
| Patrol Stay Time | 15 s to 1800 s |
| Home Position | Support |
| Tilt Range | -15° to 90° (Upward tilt is negative) |
| Pan Speed | 0.1°/s to 300°/s |
| Pan Range | 0° to 360° (endless) |
| 3D Positioning | Support |
| Tilt Speed | 0.1°/s to 180°/s |
| Number of Presets | 1024 |
| BLC | Support |
| White Balance | Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2, Area white balance |
| Digital Noise Reduction | 2D/3D DNR |
| Flip | Normal, Flip horizontal, Flip vertical, 180° |
| HLC | Support |
| Defog | Digital defog, Optical defog |
| Image Stabilization | EIS (Gyroscope) |
Interface
| Audio I/O | 1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p] |
| Alarm I/O | 7/2 |
| Network | 1 × RJ45 10 M/100 M Base-TX Ethernet |
| Serial Port | 1 × RS485 |
| Video Output | 1 BNC |
Certification
| Safety | CE LVD (EN IEC 62368-1+ A11), UL (UL 62368-1), CUL (CAN/CSA C22.2 No. 62368-1) |
| EMC | CE-EMC (EN 55032; EN IEC 61000-3-2; EN 61000-3-3; EN 50130), FCC SDoC (47 CFR Part 15; Subpart B) |
| Environment | CE ROHS (2011/65/EU; (EU)2015/863) |
| Protection | IP67 (IEC 60529+ AMD1+ AMD2), IK10 (IEC 62262, Anti-Vandalism Except for the Front Window) |
General
| Power | DC 24 V±25%, AC 24 V±25%, PoE (IEEE802.3bt) |
| Power Consumption | ≤ 65.5W |
| Power Interface | Wires with cold-pressed terminal |
| Weight | 6.9 kg |
| Storage Environment | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Surge Protection | 6 KV |
| Reset Button | Support |
| Working Environment | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Heater | Support |
| Compliance | NDAA Compliant: Support |
Dimensions
Engineering drawing reproduced 1:1 from the official datasheet.
| Dimensions | Ø227 mm × 414 mm (Ø8.94" × 16.30") (Ø × H) |
| Weight | 6.9 kg |
| Power | DC 24 V (±25%), AC 24 V (±25%), PoE (IEEE802.3bt) |
| Working Environment | -40 °C to 70 °C (-40 °F to 158 °F), ≤95% RH non-condensing |
| Protection | IP67 (IEC 60529+AMD1+AMD2) · IK10 (IEC 62262, except front window) |
| Wiper | [object Object] |
