LED Display & Digital Signage › RLED · Fine-Pitch
REALLYRLED Series · Indoor Fine-Pitch
Fine-Pitch LED Video Wall · 0.78–2.5 mm · 16 Models
Fine-Pitch LED · RLED Series
Zero-bezel indoor LED wall from 0.78 mm pixel pitch — a direct replacement for LCD video walls and DLP cubes where image quality is the whole point: control rooms, broadcast studios, briefing centers.
0.78–2.5 mm · pixel pitch range≥3840 Hz · refresh (cabinet series)8000:1 · contrast (cabinet series)170°/170° · viewing angleFront · module / PSU / card access
CHOOSE YOUR MODEL — 16 MODELS IN 3 SUB-SERIES
Flexible module series · 320×160 mm
A-series cabinet · 600×337.5 mm
Cabinet series · 640×480 mm
Rule of thumb: minimum viewing distance in metres ≈ pixel pitch in mm. Pick the tightest pitch your first row of viewers actually needs — going finer than that adds cost, not visible detail. Selecting a model updates the spec tables below and the WhatsApp message.
Get Best Price on WhatsApp
Lead time · In stock: at your forwarder’s China warehouse 3 days after payment · Not in stock: 7–15 working days · Then air 5–10 days / sea 25–45 days to your port
Terms · Sample orders welcome · Quotation / PI fixes models, prices, Incoterms (typically FOB Shenzhen), lead time and T/T payment · Defective units: free spare units agreed per order (quantity depends on order size) and written into the quotation · Warranty: up to 5 years on Zhongxin Shutong industrial switches, manufacturer warranty on other brands · Full terms, warranty & RMA
Need the PDF datasheet? Get it on WhatsApp →In-stock models: 3 days to your forwarder's warehouse in China after payment · Out-of-stock: 7–15 working days · then air 5–10 days or sea 25–45 days to your port
Sample quantities are welcome — testing one or two units first is the normal way to start.
Corporate orders are registered with the manufacturer under your company name — genuine supply you can verify at the source.
This page covers the complete REALLY fine-pitch indoor family: 16 models in three sub-series. The flexible-module line (320×160 mm modules, P1.2–P2.5) bends to curved and shaped walls. The A-series (600×337.5 mm die-cast cabinets, P0.78–P1.875) is the high-density line — up to 1.64 million pixels per square metre at 14–16-bit grayscale and 8000:1 contrast. The 640×480 mm cabinet line (P1.25–P2.5) is the workhorse for flat walls at standard 16:9 build-ups. All three share ≥3840 Hz-class refresh for camera-safe operation, dual power and signal inputs, and full front maintenance: any module, PSU or receiving card swaps from the front, so the wall can sit flush against the building wall.
Is this the right display for your project?
Plain-language guide — based only on what this product actually does.
Command & control roomsOperators sit 1.5–4 m from the wall and stare at it all shift. A-series P0.8–P1.2 gives dense pixels, 7×24-oriented redundancy and no LCD grid lines cutting through your map.
Broadcast & studios≥3840 Hz refresh means no banding on camera. Low-brightness high-grayscale drive keeps dark scenes clean at studio light levels.
Curved & shaped wallsThe flexible-module line bends around columns, arcs and corner wraps in lobbies and exhibition halls — same control chain as the flat series.
Not the right pick if you need…
- An outdoor screen — this family is IP20/IP30 indoor-only; see our Outdoor LED Display page (P3–P10, up to 6,500 nits)
- Touchable, close-contact surfaces in public spaces — the COB series takes knocks and cleaning much better than SMD lamps
- A single meeting-room screen on a modest budget — an LCD video wall or a large signage display usually does that job for less
Worried about the source? Order under your own company name.
For corporate buyers: we support submitting the purchase order to the manufacturer under your company's real name — your company appears on the official order, so the origin of the goods can be verified directly with the manufacturer. Just provide your company name and pay by corporate bank transfer.
1 · Company name2 · Corporate bank payment3 · Order registered in your name
Using your own freight forwarder? No problem.
For small and mid-size orders, we deliver directly to your designated forwarder's warehouse in China (EXW / FOB Guangzhou). From hand-over onward, international shipping and destination-side arrangements are handled by your forwarder — the way you already work.
EXW / FOB GuangzhouDelivery to your forwarder's warehouseNo minimum order
Note: manufacturer order registration (left) is available via the corporate purchase channel.
How to get a better price
Volume DiscountBulk quantities of a single model
CONTACT USMix & Match DiscountMix any categories & models storewide in one order — no quantity limit
BETTERVerified Project PriceDistributor, integrator or end user with a real project? Send the BOQ — project pricing plus free system design. Partner projects are protected: we never quote your end customer behind you
BESTAll discounts are quoted personally — message me on WhatsApp ↑
Key Features
The complete series capability list.
Seamless splicing — cabinet gaps micro-adjust via the connection hardware for a visually continuous canvas
Full front maintenance — modules, PSUs and receiving cards swap from the front; walls can be mounted flush
Dual signal and dual power inputs for 7×24 operation
Low-brightness high-grayscale drive — dark content stays clean at comfortable indoor brightness
Fanless, silent cabinet design with aluminium heat dissipation — suitable for occupied rooms
Die-cast aluminium cabinets, sealed against dust; anti-static, moisture-resistant component coating
170°/170° viewing angle on cabinet series — consistent color from every seat in the room
Color temperature adjustable 2000–12500 K (flexible series) to match house lighting
Full Specifications
Series specifications — technical values in English.
Highlighted column = the model selected above. Values are series data — confirm the final configuration with us before ordering.
Flexible module series — 320×160 mm
| Item | RLED-P1.5 | RLED-P1.2 | RLED-P1.8 | RLED-P2 | RLED-P2.5 |
|---|---|---|---|---|---|
| Pixel pitch | 1.538 mm | 1.25 mm | 1.86 mm | 2 mm | 2.5 mm |
| Module size | 320×160 mm | 320×160 mm | 320×160 mm | 320×160 / 240×120 mm | 320×160 mm |
| Module resolution | 208×104 px | 256×128 px | 172×86 px | 160×80 / 120×60 px | 128×64 px |
| Pixel structure | 1R1G1B | ||||
| Pixel density | 422,753 px/m² | 640,000 px/m² | 289,050 px/m² | 250,000 px/m² | 160,000 px/m² |
| White-balance brightness | ≥600 cd/m² | ||||
| Grayscale | 12–14 bit | ||||
| Contrast | ≥5000:1 | ||||
| Refresh rate | ≥1920–3840 Hz | ||||
| Drive method | High-grayscale constant-current driver IC | ||||
| Color temperature | 2000–12500 K adjustable | ||||
| Viewing angle (H / V) | ≥160° / ≥140° | ||||
| Ingress protection | IP20 | ||||
| Brightness uniformity | ≥97% | ||||
| Brightness adjustment | 0–100, stepless | ||||
| Signal processing | 16-bit ×3 | ||||
| Continuous operation | ≥72 h | ||||
| Typical lifespan | 50,000 h | ||||
| Operating temperature | −20 °C to 50 °C | ||||
| Operating humidity | 10–80% RH, non-condensing | ||||
| Storage temperature | −20 °C to 60 °C | ||||
| Max / average power (per m²) | 650 / 270 W | ||||
| Recommended viewing distance | ≥3 m | ≥2.5 m | ≥3.5 m | ≥4 m | ≥5 m |
| Working voltage | DC 4.2–5 V | ||||
| AC supply | 220 V ±10%, 50 Hz ±5% | ||||
| Control distance | Cat5e < 100 m · single-mode fiber < 10 km | ||||
A-series cabinet — 600×337.5 mm
| Item | RLED-P0.9A | RLED-P0.8A | RLED-P1.2A | RLED-P1.5A | RLED-P1.8A |
|---|---|---|---|---|---|
| Pixel pitch | 0.9375 mm | 0.78125 mm | 1.25 mm | 1.5625 mm | 1.875 mm |
| Module size | 300×168.75 mm | ||||
| Module resolution | 320×180 px | 384×216 px | 240×135 px | 192×108 px | 160×90 px |
| Pixel structure | 1R1G1B | ||||
| LED package / driver | SMD 4-in-1 | SMD 4-in-1 | SMD 1010 | SMD 1212 | SMD 1515 |
| Cabinet size | 600×337.5 mm | ||||
| Cabinet resolution | 640×360 px | 768×432 px | 480×270 px | 384×216 px | 320×180 px |
| Cabinet material | Die-cast aluminium | ||||
| Cabinet weight | 4.5 kg | ||||
| Pixel density | 1,137,778 px/m² | 1,638,440 px/m² | 640,000 px/m² | 409,600 px/m² | 284,444 px/m² |
| Brightness | 600 cd/m² | 500 cd/m² | 600 cd/m² | 600 cd/m² | 600 cd/m² |
| Grayscale | 14–16 bit | ||||
| Contrast | 8000:1 | 4000:1 | 8000:1 | 8000:1 | 8000:1 |
| Refresh rate | ≥3840 Hz | ||||
| Viewing angle (H / V) | 170° / 170° | ||||
| Ingress protection | IP30 | ||||
| Max / average power (per m²) | 400 / 140 W | 400 / 140 W | 460 / 175 W | 460 / 175 W | 380 / 140 W |
| Operating temperature | −20 °C to 50 °C | ||||
| Operating humidity | 10–95% RH | ||||
| Input voltage | 100–220 V AC | ||||
| Recommended viewing distance | ≥1.5 m | ≥1.5 m | ≥2.5 m | ≥3 m | ≥3.5 m |
| Control distance | Cat5e < 100 m · single-mode fiber < 10 km | ||||
Cabinet series — 640×480 mm
| Item | RLED-P1.6 | RLED-P1.8 | RLED-P1.2 | RLED-P1.5 | RLED-P2 | RLED-P2.5 |
|---|---|---|---|---|---|---|
| Pixel pitch | 1.667 mm | 1.86 / 1.839 mm | 1.25 mm | 1.538 mm | 2 mm | 2.5 mm |
| Module size | 320×160 mm | |||||
| Module resolution | 192×96 px | 172×86 / 174×87 px | 256×128 px | 208×128 px | 160×80 px | 128×64 px |
| Pixel structure | 1R1G1B | |||||
| LED package / driver | SMD 1212 | SMD 1515 | SMD 1010 | SMD 1212 | SMD 1515 | SMD 2121 |
| Cabinet size | 640×480 mm | |||||
| Cabinet resolution | 384×288 px | 344×258 / 384×261 px | 512×384 px | 416×312 px | 320×240 px | 256×192 px |
| Cabinet material | Die-cast aluminium | |||||
| Cabinet weight | 6.5 kg | |||||
| Pixel density | 359,856 px/m² | 289,050 / 295,690 px/m² | 640,000 px/m² | 422,754 px/m² | 250,000 px/m² | 160,000 px/m² |
| Brightness | 600 cd/m² | |||||
| Grayscale | 14–16 bit | |||||
| Contrast | 8000:1 | |||||
| Refresh rate | ≥3840 Hz | |||||
| Drive method | High-grayscale constant-current driver IC | |||||
| Viewing angle (H / V) | 170° / 170° | |||||
| Ingress protection | IP20 | |||||
| Max / average power (per m²) | 350 / 120 W | 350 / 120 W | 460 / 175 W | 350 / 120 W | 350 / 120 W | 680 / 270 W |
| Operating temperature | −20 °C to 50 °C | |||||
| Operating humidity | 10–80% RH | |||||
| Input voltage | 220 V AC ±10% | |||||
| Recommended viewing distance | ≥2.5 m | ≥3 m | ≥2 m | ≥2.5 m | ≥3 m | ≥3.5 m |
| Control distance | Cat5e < 100 m · single-mode fiber < 10 km | |||||
Engineering note: P1.2-class and finer walls are demanding on installation flatness and heat management. Before we ship, we will go through your site conditions with you — wall structure, ambient temperature, ventilation and service access — and flag anything that needs fixing first.
Fine-Pitch Indoor LED Wall FAQ — RLED Series P0.78–P2.5
How do I match pixel pitch to viewing distance?
The series spans 16 models from 0.78 mm to 2.5 mm pitch. As a documented reference, the 1.538 mm build lists a recommended viewing distance of 3 m or more; tighter pitches such as the 0.9375 mm cabinet suit viewers standing even closer. Tell us your room depth and we match the pitch.
Can I use this LED wall outdoors?
No — this is an indoor series. Protection is IP20 on the flexible-module build and IP30 on the 600×337.5 mm cabinets, with white-balance brightness around 600 cd/m², which suits control rooms, studios and lobbies. For billboards and facades use our outdoor P3–P10 line with IP65 fronts instead.
How far can the controller be from the screen?
Over Cat5e copper the control run can reach up to 100 m; with single-mode fiber it extends to 10 km. That lets you keep the sending equipment in a rack room far from the wall — common in government control centers where the screen and the operators sit in different rooms.
What is the power consumption per square meter?
It depends on the build: the 1.538 mm module version lists 650 W/m² maximum and 270 W/m² average, while the 0.9375 mm SMD 4-in-1 cabinet runs 400 W/m² maximum and 140 W/m² average. AC supply is 220 V ±10% at 50 Hz. Size your breakers on the maximum figure.
Is the wall serviceable from the front after installation?
Yes, the series is built for front maintenance, so cabinets can go flush against a wall with no rear corridor — a space saver in small control rooms. Cabinet formats include 600×337.5 mm A-series units (4.5 kg, die-cast aluminium) and 640×480 mm cabinets, plus flexible modules.
Can it run day and night without image degradation?
The series is validated for at least 72 hours of continuous operation with a typical lifespan of 50,000 hours. Grayscale is 12–16 bit depending on the build, refresh is 1920–3840 Hz, brightness adjusts steplessly 0–100, and the operating range is −20 °C to 50 °C at 10–95% RH.
